Installation and Setting up Instructions for the

Type 900

Dual Channel Trip Amplifier

Hawker Electronics Limited O&M 85

57 The Avenue, Issue E

Rubery Industrial Estate, October 2018

Birmingham, B45 9AL

Tel: +44(0)121-453-8911 Fax: +44(0)121-453-3777

www.hawker-electronics.co.uk

e-mail: info@hawker-electronics.co.uk

This product has been designed and complies to the relevant standards as listed in its certificate of conformity. The installer/user must ensure systemcompliance.

The Crossed-out bin symbol, placed on the product, reminds you of the need to dispose of the product correctly at the end of its life.

1.0 General Description

The Type 900 is a dual channel trip amplifier which accepts a signal from a vessel

mounted sensor and operates individual relays anywhere over its input range. When in

‘run’ mode the 4 digit LCD gives a real time reading of the signal from the

transmitter. When in ‘Programme’ mode the LCD provides the user with a menu

system to precisely set the relay ON/OFF points and other parameters. Programming

is achieved via 4 facia push buttons.

Applications include Alarm, Control, Pumping IN and Pumping OUT, fail safe HIGH

and/or fail safe LOW. The Type 900 provides DC power for the input sensor which is

current limited. The input signal is normally a mA current direct from a sensor.

Important Information

This equipment should only be specified, installed and commissioned by suitably

qualified persons. This product contains no user serviceable parts, removing the

product from its enclosure, modification or using other than outlined in the

manufacturers guidelines in any way invalidates the warranty and safety features. The

electrical installation should comply with local regulations. Ensure the correct

instructions are used for the version fitted.

2.0 Mounting, Electrical Installation and Connection

The Type 900 can be mounted using the snap fastener DIN rail or by a screw

fastenings using the hole slots on the lower left and upper right external corners of the

enclosure. The product is intended to be mounted with the power terminals at the

bottom of the enclosure. An air gap of 10mm minimum should be available around

the enclosure perimeter for proper air circulation to prevent overheating.

The Type 900 should not be mounted close to heat sources; electrical noisy apparatus

e.g. welding machines and inverter drives; locations subject to strong vibrations or

shocks; dusty or corrosive gas environments; outdoors in direct sunlight or high

humidity areas.

The crossed out bin symbol placed on the product reminds you of the need to dispose

of the product correctly at the of its life.

Maintenance is not required for this product other than periodic testing if demanded

by the application. External cleaning can be preformed using a mild detergent care

should be taken not to clean the product with aggressive substances they may damage

the enclosure, terminals or label. Cleaning should be performed with the power to live

connections disconnected by means of isolation.

2.1 Connection

The Type 900 is available as a DC or AC version (factory set). The lower terminal block is

for connection of the users power supply input to the product and the Type 900 volt free

relay contacts outputs. The upper terminal is the connection to the input sensor.

The power and relay cables can be either single cores or multi core, this product does not

require an earth connection. All cables should be rated electrically suitable (see data

specifications) and mechanically robust enough for the application. The input sensor cable

will normally be pre-fitted to the sensor itself. If this cable is screened the screen can be

connected to the signal 0V terminal if required. The screen should be connected at one end

only and if possible at the controller end.

The power supply to the 900 should be via a local external isolator and fuse. This is also

applicable to the relay contacts especially when switching hazardous voltages. This

enables the 900 to be safely disconnected if required, as well as providing over current

protection.

Caution risk of danger symbol. This symbol if shown on the product label indicates the terminals

marked 'supply' and 'relay' may contain hazardous voltages, depending on the model and users application.

Identify and Isolate before connecting or disconnecting.

The installation should comply with local regulations.

Fig 1 Wiring Connections

Always confirm the connections with the products terminal block label before connecting

as positions may vary depending on model. The Type 900 is available as a DC or AC

powered version which is specified on order.

Multi Type 900’s can be used for more demanding applications that require additional

relay outputs by connecting the transmitter loop in series as follows.

4. Programming the Type 900

On some models when initially powered the LCD may briefly display the software revision

number. e.g. r1.0

There are two modes of operation

Run Mode This operation identified by the decimal point blinking periodically,

ON for approx 4 seconds then OFF for 1 sec.

Prog Mode Programme mode is entered to set the user adjustable options.

Programming is simple with only 5 user configurable options and an exit.

Display Description

‘r1on’ Relay 1 ON point This is the value that relay 1 will energise.

‘r1of’ Relay 1 OFF point This is the value that relay 1 will de-energise.

‘r2on’ Relay 2 ON point This is the value that relay 2 will energise.

‘r2of’ Relay 2 OFF point This is the value that relay 2 will de-energise.

‘LSD’ LSD ON or OFF Least significant digit for the LCD only.

The default is ON.

‘Fin’ Finished programming, press enter, exits programme mode and returns to

run mode.

Programming the Type 900

1. Enter programme mode by pressing the ‘M’ key for approx 5 seconds. Each of the

6 menus can be accessed in the order above by pressing and releasing the ‘M’ key.

This is an example of setting Relay 1 ON point

Enter programme mode as in (1) above.

The LCD will display ‘r1on’, press ‘E’, the current value will be displayed, use the up and

down keys to enter the new value, press ’E’ when done to enter new value, the LCD will

briefly display ‘done’ then go back to the main menu and display ‘r1on’. Press and release

‘M’ until the LCD reads ‘Fin’, press ‘E’ this will exit programme mode and return to ‘run’

mode.

This can be repeated for each relay as necessary.

The LSD menu option (least significant digit)

The real time input signal display default is 4 digits and when the relay ON/OFF points are

programmed it is always 4 digits. This gives the best possible resolution and control of the

relays, i.e. their ON/OFF operation will be exactly as programmed to the least significant

digit (00.01mA). However sometimes due to application turbulence it may be less of a

distraction to display only 3 digits, this is achieved by turning the LSD OFF (UP key

toggles in the programme menu). Under these conditions it must be remembered that the

relays will operate at the programmed values and not the 3 digit value. This only effects

the display and not the relay set points.

Additional Notes on Programming

When adjusting the ON/OFF points the counter rolls from min to max and vice verse this

saves time.

The counter use’s a speed key function that increases the speed it is counting at if the UP or

DOWN button is continually pressed for a few seconds or more. When the counter is

getting close to the desired value release the key and then use individual presses and

releases for precision adjustment.

User parameters are stored in non volatile memory so will be retained if the Type 900 loses

power.

If power is lost during a cycle reapplying power will be treated as an initial power up i.e.

the input will be compared with the relay set points and the cycle restarted.

The fail safe of the Type 900 is automatically determined by the relay set points. If the ON

point is greater then the OFF point it is failsafe LOW, if the OFF point it is greater than the

ON point it is fail safe HIGH.

Errors

‘Err’ message This is only displayed when in run mode and there is a problem with

the relays. The most common cause is one or both of the relays ON and

OFF points are the same.

dp not blinking If the decimal point is not blinking the unit may have been

unintentionally left in program mode. Press the ‘M’ key repeat until

‘Fin’ is displayed the press the ‘E’ key, this will exit programme mode

Alternatively momentarily turn the power OFF and then back ON.

Power Backup System

Uninterrupted systems can be implemented using a backup battery, If a backup system is

required it would be normal to specify a DC model. The normal configuration is to use

18VDC to 24VDC derived from an AC power supply and a 12VDC external battery. When

mains AC is present the Type 900 operates from the DC output from the mains AC power

supply, when the mains AC fails the Type 900 operates from the battery. It is essential to

put a diode such as a IN4001 in series with each of the +V supplies to the 900, see diagram

below. Optionally a solar panel could be used as well as a recharging system.

NOTE: If power falls then it may be the case where the relay contacts lose their voltage

too. Backup systems are useful where supplies are from different sources or the Type 900

relays are used to drive other relays for control and indication.
