Harvest Technology NODESTREAM RiS NCMR Manuel utilisateur
®
User Manual
™
AUDIO
INTERFACE
NCMR
Please read these instructions carefully before using this product
Harvest Technology Pty Ltd
7 Turner Avenue, Technology Park
Bentley WA 6102, Australia
www.harvest.technology
Contact and Support User Resources
suppor[email protected]
Warning or caution to prevent injury or
death, or damage to property.
Extra notes on the topic or steps of the
instructions being outlined.
Further information to content outside
the scope of the user guide.
Extra pointers or suggestions in
executing instructions.
Symbols
The device should only be serviced and maintained by qualied service personnel.
Improper repair work can be dangerous. Do not attempt to service this product
yourself. Tampering with this device may result in injury, re, or electric shock.
Information for your safety
Be sure to use the specied power source for the device. Connection to an improper
power source may cause re or electric shock.
Before using the product, ensure all cables are not damaged and connected correctly.
If you notice any damage, contact the support team immediately.
• To avoid short circuits, keep metal or static objects away from the device.
• Avoid dust, humidity, and temperature extremes. Do not place the product in any
area where it may become wet.
• Operating environment temperature and humidity:
Temperature: Operating: 0 °C to 35 °C Storage: -20 °C to 65 °C
Humidity (non-condensing): Operating: 0% to 90% Storage: 0% to 95%
technical problems with the product.
Operation Safety
Disclaimer and Copyright
Whilst Harvest Technology will endeavor to keep the information in this user guide up to date, Harvest Technology
makes no representations or warranties of any kind, express or implied about the completeness, accuracy, reliability,
suitability or availability with respect to the user guide or the information, products, services or related graphics
contained in the user guide, website or any other media for any purpose.
The information contained in this document is believed to be accurate at the time of release, however, Harvest
Technology cannot assume responsibility for any consequences resulting from the use thereof.
Harvest Technology reserves the right to make changes to any of its products and associated documentation at any
time without notice. Harvest Technology does not assume any responsibility or liability arising out of the application or
use of any of its products or associated documentation.
Any decisions you make after reading the user guide or other material are your responsibility and Harvest Technology
cannot be held liable for anything you choose to do.
Any reliance you place on such material is therefore strictly at your own risk.
Harvest Technology products, including all hardware, software and associated documentation is subject to international
copyright laws. The purchase of, or use of this product convey a license under any patent rights, copyrights, trademark
rights, or any other intellectual property rights from Harvest Technology.
Warranty
The warranty for this product can be found online at:
https://harvest.technology/terms-and-conditions/
FCC Compliance Statement
NOTE: This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to part
15 of the FCC rules. These limits are designed to provide reasonable protection against harmful interference when the
equipment is operated in a commercial environment. This equipment generates, uses, and can radiate radio frequency
energy and, if not installed and used in accordance with the user manual, may cause harmful interference to radio
communications. Operation of this equipment in a residential area is likely to cause harmful interference in which case
the user will be required to correct the interference at their own expense.
Changes or modications not expressly approved by the party responsible for compliance could void the user’s authority
to operate the equipment.
CE/UKCA Compliance Statement
Marking by the (CE) and (UKCA) symbol indicates compliance of this device with the applicable directives of the
European Community and meets or exceeds the following technical standards.
• Directive 2014/30/EU - Electromagnetic Compatibility
• Directive 2014/35/EU - Low Voltage
• Directive 2011/65/EU - RoHS, restriction of the use of certain hazardous substances in electrical and electronic
equipment
Warning: Operation of this equipment is not intended for a residential environment and could cause radio interference.
Table of Contents
Overview ������������������������������������������������������������������������������������������������������������������������ 5
Ports ...................................................................................................................................................................5
Connections ������������������������������������������������������������������������������������������������������������������ 6
Typical system setup ......................................................................................................................................6
User Interface ...................................................................................................................................................6
Conguration����������������������������������������������������������������������������������������������������������������� 8
Initial Login ........................................................................................................................................................8
Dashboard .........................................................................................................................................................9
Network Conguration..................................................................................................................................10
System Settings .............................................................................................................................................13
Diagnostics......................................................................................................................................................14
Deliverer����������������������������������������������������������������������������������������������������������������������� 15
Appendix���������������������������������������������������������������������������������������������������������������������� 16
Technical Specications...............................................................................................................................16
Troubleshooting .............................................................................................................................................17
®
The RiS Nodecom (NCMR) provides a single audio channel for streaming two-way audio to other
devices on the customers RiS network
Two-way audio streaming solution
NCMR NCMR
Ports
WiFi
Antenna
Ethernet
USB-ADC in USB-A
3.5mm
Audio
HTG-TEC-GUI-019_0
Release Sep 2022 page 5 of 19
NCMR
Overview
Feature Summary
• Low latency & bandwidth
• User congurable network
topology
• Small form factor desktop
solution
• Intuitive user interface
®
The NCMR is supplied with a Quick Start Guide for installation. See the User Resources on the last
page for access.
USB audio device
Connections
Ethernet
User Interface
Status LED
Indicator Volume | Start/Stop
software with LED indicator
PTT (push to talk) button
with LED indicator
Power
Typical system setup
The following audio devices are supported:
• USB speakerphone or headset via either USB port (Jabra Speakerphone supplied)
• 3.5mm stereo/mono + mic headset or microphone & speaker via the RHS port
HTG-TEC-GUI-019_0
Release Sep 2022 page 6 of 19
NCMR
®
Status LED
PTT (Push To Talk)
VOL (Volume)
Factory Reset
Mute
Decrease volume until
LED is rotating
Increase volume
Turn clockwise
Decrease volume
Turn counter-clockwise
LED Ring
+
-
+
-
Press to toggle through
audio devices
(Blue)
(Red)
(Green)
Speaker
Microphone
Monitor
Device will reset to factory default user login and network settings
AUDIO
INTERFACE
NCMR
Press and Hold
Open Mic
Start talking
Press 3 times to
open mic
Press & hold
PTT & VOL
buttons (ashes)
LED
Red
LED
Red
PTT & VOL
LED
LED
Green
LED
Green
Press for 1
sec to mute
Release to
mute
Software not running
Software running
Audio connection active, mic muted
Audio connection active, mic open
(Off)
(Blue)
(Green)
(Red)
Power on (blue)
PTT & VOL
LED
(solid)
Release
PTT & VOL
buttons
Approximately 10 seconds
HTG-TEC-GUI-019_0
Release Sep 2022 page 7 of 19
NCMR
®
Conguration
The NCMR is congured via a web interface. The web interface allows the user to view device
information and status, congure network settings (wired and WiFi) and perform system related
tasks.
The device is shipped in a “factory default” state. Settings must be congured to enable use on the
customers RiS network.
Initial Login
Congure the IPv4 settings of a computer connected to the same network
IP 192.168.2.x
Subnet 255.255.255.0
Gateway 192.168.2.1
Due to the possibility of conicting IP addresses, only 1 device can be congured at a time. Once
network settings have changed, the device can remain connected
1
2
3
4
HTG-TEC-GUI-019_0
Release Sep 2022 page 8 of 19
NCMR
Navigate to http://192.168.2.1
from a web browser and login with
User admin
Password admin
Connect the RIS Nodecom device to your LAN via the Ethernet port and power
the device
Enter a new password
®
Dashboard
Following initial login, the user will be presented with the WebUI dashboard. The following
information and conguration is provided
Device
• Serial number & uptime
Information
• Select interface from drop down
• Current network status & information
Testing
• Network connection upload & download speed tests
• Ping a device on the network (helpful for network diagnostics)
Conguration
• See next section
Reboot
• To reboot the device, select the reboot icon from the
top right of any screen and select Conrm
HTG-TEC-GUI-019_0
Release Sep 2022 page 9 of 19
NCMR
®
Network Conguration
Ethernet
Name the interface (optional) and select enabled then Save Changes
1
2
Select the Ethernet adapter from the dropdown list in the top right of the window
RiS devices communicate over a customers “closed” network, ensuring stable and secure
transimssion of sensitive data. Device network adapters require IPv4 conguration.
Firewall Settings
The following port numbers MUST be set to open on customer network devices where applicable
Data streaming, device control & connection management
• UDP - 2100 to 2200
Device to device communication
• UDP - 2025 & 2026
• TCP - 2020
Ethernet connections will take preference over WiFi. Disable or unplug Ethernet
cable if WiFi connection is preferred
Current network settings can be viewed from LHS of the dashboard
HTG-TEC-GUI-019_0
Release Sep 2022 page 10 of 19
NCMR
