Harrod CRK-059 Manuel utilisateur

CRK-059

Free Standing Cricket Single Bay

INS515

22/03/07

Harrod UK Limited©

Code:

Product:

Pack Contents:

View of Product

Assembly time for two persons, approx 2 hours

1. M51-6 (167BM) Kee-Clamp Double Male x 2 (KCL202)

2. M50-6 (173BM) Kee-Clamp Single Male x 4 (KCL203)

3. 25-6 (104B) Kee-Clamps Long Tee x 2 (KCL-116)

4. 35-6 (176B) Kee-Clamps Side Outlet Tee x 2 (KCL-113)

5. 15-6 (125B) Kee-Clamp 90 Elbow x 2 (KCL-120)

6. 20-6 (128B) Kee-Clamp 3 Way 90 Elbow x 6 (KCL-118)

7. M52-6 (168BM) Kee-Clamp 90 corner male x 2 (KCL201)

8. M10 Wingnut BZP x 12 (BOL203)

9. Washer Spring 10mm S/Steel x 12 (BOL713)

10. M10 x 30 Cap Screw BZP x 12 (BOL333)

11. 1/4” Allen Key x 1 (BOL792)

12. Hanging Hooks x 70 (HKS059)

13. 4000mm Diagonal Brace x 6 (SPE583)

14. 3660mm Centre Rail x 1 (PEQ161)

15. 3581mm Rail x 6 (PEQ160)

16. 2667mm Upright x 6 (PEQ159)

Fig 1.

400mm

Tools Required:

1 x Spirit Level

2 x High Ladders

950mm

Diagonal Brace

Fixing Start

Point.

IMPORTANT: PLEASE READ THE

ASSEMBLY INSTRUCTIONS

CAREFULLY BEFORE STARTING TO

ASSEMBLE YOUR CRICKET CAGE.

Approx Hook Allocation.

5 per top rail.

3 per upright.

3 per bottom rail.

CRK-155

Premier Aluminium Portable Cricket Cage.

Code:

Product:

Lacing Start

Point.

Assembly Instructions

1Using the pack contents list on previous page, identify the parts required for the assembly of this cricket

cage. Read all the instructions through first to familiarize yourself with the best order of assembly and

remember the key points. It is advised that two or more persons assemble this cricket cage.

2Lay all the bottom parts of the cage on the ground and fit together with the necessary key clamps from

the parts contents. (Use Fig.1 for reference).

3Then start to insert the uprights into the key clamps used on the bottom part of the cage. Fit the Key

Clamps that will be needed for the diagonal braces, these need to be hand tightened only at this point at

the approx positions shown in Fig 1.

4Retrieve the top rods and key clamps that are used on the roof of the cage and assemble. Once you have

the structure of the cage, go back and check that all of the Key Clamps the you have fitted to the cage are

secure.

5Next the diagonal braces have to be fitted, start at the point indicated on Fig 1, 400mm up from bottom

of cage. Using a spirit level to ensure that the square and secure the other end of the diagonal brace.

Continue around the cage fitting each diagonal brace.

Hanging the net. Before hanging the net, it is recommended that two people stretch the net and pull it

into shape. Hang the surround on the hanging hooks inside the frame. Lace the roof to the surround

netting with the twine provided starting at point shown on fig 2.

6Fit the top brace as shown in Fig 1.

Fig 2.

Tip. Slide on required hanging before fixing key clamps (see Fig.1 for quantities).
