Harmonic MediaGrid ContentStore 3160 Manuel utilisateur
Harmonic MediaGrid ContentStore 3160
Quick Reference Guide
28-0335 Rev. D
15
OPEN
0
OPEN
14
10
9
3
2
1
4
8
7
5
6
11
12
13
1
2
15
OPEN
0
OPEN
14
10
9
3
2
1
4
8
7
5
6
11
12
13
3
12
1 Left Control Panel
(for Controller B)
2 Disk Drives
3 Power Button
4 Right Control Panel
(for Controller A)
1
2
1 Power Indicator
2 Air Vents
Controller A
1 Power Supply
Module
2 Serial Attached SCSI
(SAS) Ports (2)
Left port: Input
Right port: Output
Controller B
4
ContentStore 3160
MediaGrid
+7 495 926 4608 (Russia, CIS), +81 3 5565 6737 (Japan), +86 10 6569 5580 (China, mainland)
Harmonic Technical Support: +888 673 4896 (Americas), +65 6542 0050 (Asia Pacific), + 44 1252 555 450 (EMEA),
Rear Panel Components
Front Panel Components
28-0335 Rev. D
Disk Drive LEDs
LED State Description
OPEN
Activity
Green Solid Drive is powered on.
(Activity)
Rapid blink
(4 per second)
LED State Description
Slow blink
(1 per second)
Two rapid blinks Drive is being rebuilt or repaired.
then pause
Off Drive state is normal. Drive is being
used by the ContentStore.
Off No power is being provided to the drive.
Red Solid
(Status)
Blinking Drive activity.
*This LED applies only to fans controlled by the chassis.
Drive has failed.
Drive is not being used by the
ContentStore.
Drive is being winked.
Status
1 Power
2 SAS-Out
3 Power Fail
4 Heartbeat
5 SAS-In
6 Overheat/
Fan Fail*
Solid
Solid
Solid
Unused
Solid
Flashing
Solid
Power is being supplied to the
power supply units.
SAS output port is connected
A power supply module has
failed.
Unused
SAS input port is connected
Fan failure has occurred.
Requires immediate attention.
Indicates overheat condition.
NOTE: For descriptions of all ContentStore 3160 LEDs, refer to the Harmonic MediaGrid Installation and Configuration Guide.
Left Control Panel
15
OPEN
0
OPEN
Right Control Panel
1
2
3
4
5
6
+7 495 926 4608 (Russia, CIS), +81 3 5565 6737 (Japan), +86 10 6569 5580 (China, mainland)
Harmonic Technical Support: +888 673 4896 (Americas), +65 6542 0050 (Asia Pacific), + 44 1252 555 450 (EMEA),
Control Panel LEDs
