Harman Martin M-Touch Guide de configuration
Martin M-Touch
Safety and Installation Guide
Table of Contents
Dimensions 3
Introduction 4
Technical Support 5
Safety Information 6
Electromagnetic Compatibility 6
Included Items 7
Software 7
Setup and Powering Up 8
USB 8
DMX 8
Connection without a USB hub 9
Connection with a USB hub 9
Connections 10
Side 10
Maintenance11
Specifications 12
Control and Programming 12
Playback 12
Physical 12
Connections 12
Electrical 12
Included Items 12
Ordering Information 12
Dimensions
All dimensions are in millimeters
Introduction
Thank you for purchasing the Martin™M-Touch Lighting Control System.
The system offers a powerful control surface when it is connected to a computer
running Martin M-PCTM software.
Please read this "Safety and Installation Guide" carefully. Visit the Martin™ website
www.martin.com for further documentation including the software user manual and
access to our online community.
Technical Support
Martin™ operates a complete network of support services around the world.
Experts in programming and operating Martin™ control systems can be found in
every time zone and on every continent.
Contact by email
The best way to get questions answered or to report a problem is to email us at
controllersupport@martin.dk
Contact by phone
In an emergency, call the dedicated 24-hour controller support hotline
+45 8740 0015
Fixture Type Requests
The Martin M-Series™ contains an extensive fixture library. However, new fixtures
are constantly appearing on the market and a specific fixture may not be available in
the fixture library yet.
You can make a fixture request at http://www.martin.com/en-US/Fixtures-Request
We may have already created a fixture profile and included it in the library update
package. You can find a list of all available fixture profiles on the support page for
your Martin™ product and we recommend that you check the page before you fill
out a request form.
The support pages offer help in installing fixture updates on your system.
Controller Support website
Up-to-date software, manuals and training documentation is available at
controllersupport.martin.com
User Forums
The Martin™ controller user forums are a helpful resource to communicate with
other users around the world. Many questions may already be answered in the
forums and it is a great way to interact with other programmers and users.
forum.martin.com
Safety Information
This product is for professional use only. It is not for household use. It presents risks
of lethal or severe injury due to electric shock. Read this document before powering
or installing the console, follow the safety precautions listed below and observe all
warnings in this document and printed on the product.
If you have questions about how to operate the product safely, please contact your
Martin™ supplier or call the Martin™ 24-hour service hotline on +45 8740 0000.
This product is for indoor use ONLY.
Do not expose the product to rain or moisture.
Operate the product only on a stable and solid surface.
Do not use the product if the ambient temperature exceeds 40°C (104° F)
Refer any service operation not described in this manual to a qualified
technician.
Do not modify the product or install other than genuine Martin parts.
Transportation damage is not covered under warranty.
Risk of fire and electrical shock. Use only in dry locations.
Do not operate the product in a manner not specified in its user
documentation. Product misuse can result in a hazard. You can compromise
the safety protection built into the product if the product is damaged in any
way. If the product is damaged, stop using it immediately and return it to
Martin Professional for repair.
Electromagnetic Compatibility
This product has been tested and complies with the regulatory requirements and
limits for electromagnetic compatibility (EMC) stated in the product specifications.
These requirements and limits provide reasonable protection against harmful
interference when the product is operated in the intended operational
electromagnetic environment.
Included Items
Each Martin M-Touch controller contains the following items:
Martin M-Touch Controller
USB cable
Safety and Installation Manual
Software
The Martin M-Touch requires a Windows PC running Martin M-PC software. The
software is available from the support website controllersupport.martin.com
Please check periodically for new releases that may add new functionality or
improvements.
We recommend that you update to the latest software release before using the
Martin M-Touch for the first time.
Setup and Powering Up
USB
The Martin M-Touch does not have a separate power connector. It draws power
from the connected computer via USB.
If you use a USB hub to connect the Martin M-Touch to a PC, it must be powered
type. If you use an unpowered USB hub, the Martin M-Touch will fail to connect to
the PC.
When the Martin M-Touch is connected to a PC running M-PC software for the first
time, a driver will be installed on the PC. As soon as the driver is loaded and
initialized, the M-Touch is ready to be used.
DMX
Connect some fixtures to the DMX port of the Martin M-Touch controller.
Use only cable that is certified for DMX. Do not use microphone cable or other cable
types, as unsuitable cable impedance may cause signal disruption.
Use a 5-pin male DMX plug on the M-Touch side.
Always use DMX termination on the last fixture on the DMX link.
Damage to the controller due to faulty DMX wiring is not covered under warranty.
Connection without a USB hub
Connection with a USB hub
Connections
Side
USB
A USB-B 2.0 connector is placed on the right-hand side of the Martin M-Touch for
connection to a host PC. The M-Touch can draw a maximum of 500 mA. If you use
a USB hub, make sure that it is powered.
DMX
5-pin female XLR DMX Output
Pin configuration:
Pin 1 Signal ground
Pin 2 Cold
Pin 3 Hot
Pin 4-5 Not in use
