Harman JBL Quantum 400 Manuel utilisateur
OWNER’S MANUAL
400
TABLE OF CONTENTS
INTRODUCTION ........................................................................................................... 1
WHAT’S IN THE BOX..................................................................................................... 2
PRODUCT OVERVIEW ................................................................................................. 3
Controls on headset.....................................................................................................................................3
GETTING STARTED....................................................................................................... 5
Wearing your headset.................................................................................................................................5
First-time setup (for PC only)...................................................................................................................6
USING YOUR HEADSET............................................................................................... 8
With USB connection...................................................................................................................................8
With 3.5mm audio connection..............................................................................................................9
PRODUCT SPECIFICATIONS..................................................................................... 10
TROUBLESHOOTING ................................................................................................. 11
- 1 -
Introduction
Congratulations on your purchase! This manual includes information on the JBL
QUANTUM400 gaming headset. We encourage you to take a few minutes to read
this manual, which describes the product and includes step-by-step instructions to
help you to set up and get started. Read and understand all the safety instructions
before using your product.
If you have any questions about this product or its operation, please contact your
retailer or customer service, or visit us at www.JBLQuantum.com
- 2 -
What’s in the box
01 02 03 04
05
01 JBL QUANTUM400 headset
02 USB cable (USB-A to USB-C)
03 3.5mm audio cable
04 QSG, warranty card and safety sheet
05 Windshield foam for boom microphone
- 3 -
PRODUCT OVERVIEW
Controls on headset
01
02
03
04
05
06
07
08
09
10
01 / dial
• Balances the chat volume in relation to the game audio volume.
02 Volume +/- dial
• Adjusts headset volume.
03 Detachable windshield foam
04 Mic mute / unmute LED
• Lights up when the microphone is muted.
05 RGB-lit JBL logo
06 3.5mm audio jack
07 Voice focus boom microphone
• Flip up to mute, or flip down to unmute the microphone.
- 4 -
08 Flat-fold ear cup
09 button
• Press to mute or unmute the microphone.
• Hold for more than 5 seconds to turn the RGB light on or off.
10 USB-C port
- 5 -
Getting started
Wearing your headset
1. Put the side marked Lonto your left ear and the side marked Ronto your right
ear.
2. Adjust the earpads and headband for a comfortable fit.
3. Adjust the microphone as necessary.
- 6 -
First-time setup (for PC only)
Download from jblquantum.com/engine to gain full
access to features on your JBL Quantum headset - from headset calibration to
adjusting 3D audio to suit your hearing, from creating customized RGB lighting
effects to determining how the boom microphone side-tone works.
Software requirements
Platform: Windows 7 / Windows 10 (64 bit) only
500MB of free hard drive space for installation
TIP:
• QuantumSURROUND and DTS Headphone:X V2.0 available on Windows only.
Software installation required.
1. Connect the headset to your PC via USB connection (See “With USB
connection”).
2. Go to “Sound Settings” -> “Sound Control Panel”.
3. Under “Playback” highlight “JBL QUANTUM400 GAME“ and select “Set Default”
-> “Default Device”.
4. Highlight “JBL QUANTUM400 CHAT“ and select “Set Default” -> “Default
Communication Device”.
5. Under “Recording” highlight “JBL QUANTUM400 CHAT“ and select “Set
Default” -> “Default Device”.
- 7 -
6. Follow the onscreen instructions to personalize your sound settings.
JBL Quantum400
Game
JBL Quantum400
Chat
- 8 -
Using your headset
With USB connection
1. Connect the orange connector (USB-A) of the USB cable to a USB-A port on your
PC, Mac or PS4.
2. Connect the black connector (USB-C) to the USB-C port on your headset.
Basic operation
Controls Operation
Volume dial Adjust master volume.
Rotate towards to increase game volume.
Rotate towards to increase chat volume.
button Press to mute or unmute the microphone.
Hold for more than 5 seconds to turn on or off the RGB light.
TIP:
• Depending on your device configuration, you can also use a USB-C to USB-C
cable (not supplied). USB-C connectivity with all devices is not guaranteed.
