Harman Kardon AVR 245 Manuel utilisateur

AVR 245 WORKSHEETS

Default settings, worksheets, remote product codes

Table A1 – Source Input Setting Defaults

Source DVD HDMI 1 HDMI 2 Video 1 Video 2 Video 3 Video 4 The Bridge/ CD Tape Tuner 6-/8- XM

DMP Channel

Title I

NT.TUNER

Component Comp V 1 Convert* Convert* Comp V 2 Comp V 3 Convert* Convert* Convert* Convert* Convert* Convert* Convert* Convert*

Video Input

Audio Input Coax 1 Coax 2 Optical 2 Analog Optical 1 Analog Analog The Bridge/ Analog Analog Tuner 6-/8- Analog

DMP Channel

Auto Poll On Off Off On On On On --- On On --- --- Off

Surround Logic 7 Logic 7 Logic 7 Logic 7 Logic 7 Logic 7 Logic 7 Logic 7 Logic 7 Logic 7 Logic 7 Logic 7 Logic 7

Mode†

7CH Music 7CH Music 7CH Music 7CH Music 7CH Music 7CH Music 7CH Music 7CH Music 7CH Music 7CH Music 7CH Music 7CH Music 7CH Music

The default video input for this source is either the composite or S-video input associated with the source.The signal will be transcoded to component video and available at the

Component Video Monitor Outputs for use with a compatible video display, but it will not be upscaled.

The default shown is the preferred surround mode for PCM and Analog audio sources.

Table A2 – Speaker/Channel Setting Defaults

Source DVD HDMI 1 HDMI 2 Video 1 Video 2 Video 3 Video 4 The Bridge/ CD Tape Tuner 6-/8- XM

DMP Channel

Bass Manager: Global

Left/Right Speaker Size Small Small Small Small Small Small Small Small Small Small Small Large Small

Center Speaker Size Small Small Small Small Small Small Small Small Small Small Small Large Small

Surround Speaker Size Small Small Small Small Small Small Small Small Small Small Small Large Small

Surround Back Speaker Size Small Small Small Small Small Small Small Small Small Small Small Large Small

Subwoofer Sub Sub Sub Sub Sub Sub Sub Sub Sub Sub Sub Sub Sub

Left/Right Speaker Crossover 100Hz 100Hz 100Hz 100Hz 100Hz 100Hz 100Hz 100Hz 100Hz 100Hz 100Hz N/A 100Hz

Center Speaker Crossover 100Hz 100Hz 100Hz 100Hz 100Hz 100Hz 100Hz 100Hz 100Hz 100Hz 100Hz N/A 100Hz

Surround Speaker Crossover 100Hz 100Hz 100Hz 100Hz 100Hz 100Hz 100Hz 100Hz 100Hz 100Hz 100Hz N/A 100Hz

Subwoofer Crossover Left/Right Left/Right Left/Right Left/Right Left/Right Left/Right Left/Right Left/Right Left/Right Left/Right Left/Right N/A Left/Right

Table A3 – Delay Setting Defaults

Speaker Position Distance From Speaker to Listening Position Your Delay Settings

Front Left 10 Feet

Center 10 Feet

Front Right 10 Feet

Surround Right 10 Feet

Surround Left 10 Feet

Subwoofer 10 Feet

A/V Sync Delay 0mS

†

AVR 245 WORKSHEETS

Table A4 – Source Input Settings

Source DVD HDMI 1 HDMI 2 Video 1 Video 2 Video 3 Video 4 The Bridge/DMP CD Tape Tuner 6-/8-Channel XM

Title

Int.Tuner

Video Input

Component Video Input

Audio Input The Bridge/DMP Tuner 6-Channel

Auto Poll --- --- ---

Surround Mode

Table A5 – Speaker/Channel Settings

Source DVD HDMI 1 HDMI 2 Video 1 Video 2 Video 3 Video 4 The Bridge/DMP CD Tape Tuner 6-/8-Channel†† XM

Bass Manager:

Global/Independent N/A

Left/Right Speaker Size N/A

Center Speaker Size N/A

Surround Speaker Size N/A

Subwoofer N/A

Left/Right Speaker Crossover

N/A

Center Speaker Crossover

N/A

Surround Speaker Crossover

N/A

Subwoofer Crossover N/A

Left/Right Channel Level†††

Center Channel Level†††

Surround Channel Level†††

Subwoofer Channel Level†††

The 6-/8-Channel Inputs are “direct” inputs, meaning their signals are passed directly to the volume control without any bass management processing.Thus, the speaker sizes are always full range,

and it isn’t possible to adjust speaker size or crossover.

Note: Channel levels vary by surround mode rather than source input.

††

†††

AVR 245 WORKSHEETS

Table A6 – Remote Control Codes

Source Input Product Type (circle one or fill in) Remote Control Code

Video 1 VCR, PVR

Video 2 Cable, Satellite

Video 3 TV

Video 4

DVD DVD

CD CD, CDR

Tape Cassette

HDMI 1

HDMI 2

Table A7 – System Settings

Feature Default Setting Your Setting

VFD Fade Time-Out Off

Volume Default Off

Default Vol Set –25dB

Semi-OSD Time-Out 5 Seconds

Full-OSD Time-Out 20 Seconds

Default Surr Mode On

OSD Background Blue
