Hanwha Vision XNB-6000 Manuel utilisateur

XNB-6000/XNB-8000

NETWORK CAMERA

Quick Guide

COMPONENT

As for each sales country, accessories are not the same.

~XNB-6000/XNB-8000

Options (not included)

~Not Included : SD CARD

INSTALLATION

1-1

INSTALLATION

1-2

1-3

INSTALLATION

1-4

INSTALLATION

1-5

AUDIO

OUT

MICRO

USB

VIDEO

NETWORK

ACT LINK

DC 12V

AC 24V

FOCUS

123456

RESET

ALARM IN : 1

ALARM OUT : 2

GND:3 NC : 4

RS-485+ : 5

RS-485- : 6

PWR

AUDIO

OUT

MICRO

USB

VIDEO

NETWORK

ACT LINK

DC 12V

AC 24V

FOCUS

123456

RESET

ALARM IN : 1

ALARM OUT : 2

GND:3 NC : 4

RS-485+ : 5

RS-485- : 6

PWR

IN micro USB

1-6

~Not included: WiFi dongle, OTG adapter

INSTALLATION

1-7

Installation

1-8

PASSWORD SETTING

When you access the product for the first time, you

must register the login password.

When the “Password change” window appears,

enter the new password.

`For a new password with 8 to 9 digits, you

must use at least 3 of the following: uppercase/

lowercase letters, numbers and special

characters. For a password with 10 to 15

digits, you must use at least 2 types of those

mentioned.

-Special characters that are allowed. :

~`!@#$%^*()_-+=|{}[].?/

`For higher security, you are not recommended

to repeat the same characters or consecutive

keyboard inputs for your passwords.

`If you lost your password, you can press the

[RESET] button to initialize the product. So,

don’t lose your password by using a memo pad

or memorizing it.

Whenever you access the camera, the login

window appears.

Enter the User ID and password to access the

camera.

aEnter “admin” in the <User Name> input

box.

bEnter the password in the <Password>

input field.

cClick [OK].

CONNECTING TO WiFi

Camera setting

aConnect OTG adapter (5-pin) and WiFi

dongle to the micro USB terminal.

Smartphone setting

aInstall the Wisenet Installation application.

bSelect the camera SSID after turning on

the WiFi.

cRun the Wisenet Installation application.

dWhen you log in to the camera, the video

will be connected. (initial password: 4321)

`The video will be played without being logged in

during the initial connection.

eYou can adjust angle of view while

watching the video through smartphone.

Correct disposal of batteries in this product

(Applicable in the European Union and other European countries with separate battery return systems.)

This marking on the battery, manual or packaging indicates that the batteries in this product should not be disposed of with other

household waste at the end of their working life. Where marked, the chemical symbols Hg, Cd or Pb indicate that the battery contains

mercury, cadmium or lead above the reference levels in EC Directive 2006/66. If batteries are not properly disposed of, these

substances can cause harm to human health or the environment.

To protect natural resources and to promote material reuse, please separate batteries from other types of waste and recycle them

through your local, free battery return system.

Hanwha Vision cares for the environment at all product manufacturing stages, and is taking measures to

provide customers with more environmentally friendly products.

The Eco mark represents Hanwha Vision’s devotion to creating environmentally friendly products, and indicates

that the product satisfies the EU RoHS Directive.

Correct Disposal of This Product (Waste Electrical & Electronic Equipment)

(Applicable in the European Union and other European countries with separate collection systems)

This marking on the product, accessories or literature indicates that the product and its electronic accessories

(e.g. charger, headset, USB cable) should not be disposed of with other household waste at the end of

their working life. To prevent possible harm to the environment or human health from uncontrolled waste

disposal, please separate these items from other types of waste and recycle them responsibly to promote the

sustainable reuse of material resources.

Household users should contact either the retailer where they purchased this product, or their local

government office, for details of where and how they can take these items for environmentally safe recycling.

Business users should contact their supplier and check the terms and conditions of the purchase contract.

This product and its electronic accessories should not be mixed with other commercial wastes for disposal.
