Hantek 1008 Manuel utilisateur
Hantek 1008
DIGITAL OSCILLOSCOPE
USER’S MANUAL
Hantek1008
Hantek1008
0.0)(Version 1.
Hantek 1008
X
DIGITAL OSCILLOSCOPE
USER’S MANUAL
The Display System..................................................
Taking Cursor Measurements..................................
Y
Content
General Safety Summary ……..………………………….…...3
CHAPTER 1: Getting Started…...………………………….... 4
System Requirement..……………………………
…
.....5
Install Software........…………………….…………....…6
Install Driver............………………………..……….
....
.11
General Features....……………………..……….........16
General Check............…………………..……...
…..
....17
Probe Compensation.................………..…...…….....17
Functional Check..................................................
..
..19
Seft Calibration..........................................................21
Accessaries...............................................................22
CHAPTER 2: Operating Basics……………………………...23
The User’s Interface………………………............
..
...24
The Vertical System…...........…………………
…......
.30
The Horizontal System…………………….....…...
....
.32
The Trigger System............................…………….....33
Input Connectors..……………….………
…………..
...35
CHAPTER 3: Understanding Function..………………
…....36
S
et Ocsilloscope.......................................................37
Set Vertical System...................................................38
Set Horizontal System...............................................46
Set Trigger System....................................................48
Save/Load.................................................................50
Utility Function...........................................................52
Measure Signal.........................................................55
63
Print...........................................................................69
CHAPTER 4: Application Example......……………….….....71
Simple Measurement................................................
Capturing a Single Shot Signal................................
The Application of The X-Y.......................................74
77
CHAPTER 5: Appendix..............…………………...........….81
Appendix A............................................................... 82
Appendix B............................................................. ..84
72
73
Hantek1008
ZGeneral Safety Summary
Review the following safety precautions carefully before operating the device to avoid
any personal injuries or damages to the device including any products connected to it.
To avoid any potential hazards use the device as specified by this user’s guide only.
■ To Avoid Fire or Personal Injury.
■ Use Proper Power Cord. Use only the power cord specified for this product and
certified for the correct country of use.
■ Connect and Disconnect Properly. Do not connect or disconnect probes or test
leads while they are connected to a voltage source.
■ Connect and Disconnect Properly. Connect the probe output to the measurement
device before connecting the probe to the circuit under test. Disconnect the probe
input and the probe reference lead from the circuit under test before disconnecting
the probe from the measurement device.
■ Observe All Terminal Ratings. To avoid fire or shock hazard, observe all ratings
and markings on the product. Consult the product manual for further ratings informa-
tion before making connections to the product.
■ Use Proper Probe. To avoid shock hazard, use a properly rated probe for your mea-
surement.
■ Avoid Circuit or Wire Exposure. Do not touch exposed connections and compo-
nents when power is on.
■ Do Not Operate With Suspected Failures. If suspected damage occurs to the
device, have it inspected by qualified service person before further operations.
■ Provide Proper Ventilation. Refer to the installation instructions for proper ventilation
of the device.
■ Do Not Operate in Wet/Damp Conditions.
■ Do Not Operate in an Explosive Atmosphere.
■ Keep Product Surfaces Clean and Dry.
Hantek 1008
DIGITAL OSCILLOSCOPE
Self calibration
Probe compensation
Install driver [
Chapter 1 Getting Started
The oscilloscope is small, compact, portable oscillo-scopes! The oscilloscope is ideal for
production test, research and design and all of the applications involving analog circuits
test and troubleshooting, as well as education and training.
In addition to the list of general features on the next page, this chapter describes how to
do the following tasks:
■ System requirement
■ Install software
■ General features
■ Function check
■
■
■ Accessories
■
■ General check
Hantek1008
\System Requirement
To run oscilloscope software, the needs of computer configuration are as follows:
Minimum System Requirement
Operating System
Window NT/2000/XP/VISTA/Win7
Processor
Upwards of 1.00G processor
Memory
256M byte
Disk Space
500M disk free space
Screen Resolution
800 x 600 pixel
Recommended Configuration
Operating System
Windows XP SP3 System
Processor
2.4G Processor
Memory
1G Byte
Disk Space
80G Disk Space
Screen Resolution
1024 x 768 or 1280 x 1024 pixel
DPI Setting
Normal Size (96DPI)
Hantek 1008
DIGITAL OSCILLOSCOPE
]Install Software
Note: Do not connect the USB connection until the software installation is complete.
1. While in Windows, insert the installation CD into the CD-ROM drive.
2. The installation should start up automatically. Otherwise in Windows Explorer, switch
to the CD-ROM drive and run Setup.exe.
3. The software Installation is started. Click 'Next' to continue.
Hantek1008
^
4. Choose a destination directory. Click 'Next' to continue.
Hantek 1008
DIGITAL OSCILLOSCOPE
_
5. Check the setup information. Click Next to start copying files.
Hantek1008
`
7. Updating Your System Configuration.
6. This Status dialog is displayed during files copying.
Hantek 1008
DIGITAL OSCILLOSCOPE
