NAUTIZ X8
QUICK START GUIDE
The pictures shown below may differ from the actual
products. To purchase additional or optional products,
contact our customer center.
Standard Battery
Adaptor Hand Strap
Stylus Pen
Nautiz X8 Main Body
USB Cable
WHAT´S IN THE BOX
1
Octant key font_141027
NAUTIZ X8
Power Button
Receiver
LED
Touch Screen Display
Volume Keys
Camera
Speaker
Hand Strap Holder
Hand Strap Holder
Battery
Battery Lock
YOUR NAUTIZ X8
2
Octant key font_141027
NAUTIZ X8
0 0 0
To remove the battery
1. Power off the PDA.
2. Open the battery
cover by slidig the
door’s lock left and
lift up the cover.
3. Remove the battery.
To insert the battery
1. Remove the battery
cover by sliding the
door’s lock left and
lift up the cover.
2. Insert the battery.
3. Close the battery
cover.
INSERT/REMOVE BATTERY
3
Battery door unlock
1
2
1
2
This is how you insert and remove the SIM/micro SD.
INSERTING/EXRTRACTING
SIM/MICRO SD CARD
4
SIM card
SD card
Press the [Power] button at the bottom of the keypad to
turn the Nautiz X8 unit on/off.
Power Button
POWERING ON/OFF
5
Octant key font_141027
NAUTIZ X8
Use supplied power adapter and USB cable to charge
the Nautiz X8. Charge the unit for five hours before
using the phone for the first time.
BATTERY CHARGING
6
Octant key font_141027
NAUTIZ X8
Please go to www.handheldgroup.com/knowledgebase
to download more information.
Nautiz X8 is in compliance with the essential requirements and other relevant
provisions of Directive 1999/5/EC. The declaration of conformity may be consulted at
www.handheldgroup.com/nautiz-x8/#tab=manuals
3.5mm Ear Jack
(stereo & mic)
DB9 RS-232
USB micro
(PC sync & charging)
USB A host
BOTTOM PANEL LAYOUT
7
