Hamworthy TYNEHAM AHP60 Guide de l'utilisateur

IMPORTANT NOTE

THESE INSTRUCTIONS MUST BE READ

AND UNDERSTOOD BEFORE INSTALLING,

COMMISSIONING, OPERATING OR

SERVICING EQUIPMENT

INSTALLATION, COMMISSIONING AND

SERVICING INSTRUCTIONS

Air/water monobloc

heat pump

TYNEHAM AHP60

Models: 50 and 70 kW

Technical Enquiries

To supplement the detailed technical brochures, technical advice on the application and use of products in the Hamworthy

Heating range is available from our technical team in Poole and our accredited agents.

Site Assembly

Hamworthy o󰀨er a service of site assembly for many of our products in instances where plant room area is restricted.

Using our trained sta󰀨 we o󰀨er a higher quality of build and assurance of a boiler built and tested by the manufacturer.

Commissioning

Commissioning of equipment by our own engineers, accredited agents or specialist sub-contractors will ensure the

equipment is operating safely and e󰀩ciently.

Maintenance Agreements

Regular routine servicing of equipment by Hamworthy service engineers inspects the safety and integrity of the plant,

reducing the risk of failure and improving performance and e󰀩ciency. Maintenance agreements enable our customers to

plan and budget more e󰀩ciently.

Breakdown service, repair, replacement

Hamworthy provide a rapid response breakdown, repair or replacement service through head o󰀩ce at Poole and

accredited agents throughout the UK.

Spare Parts

A comprehensive spare parts service is operated from our factory in Poole, providing replacement parts for both current

and discontinued products. Delivery of parts and components is normally from stock within seven days. However, a next

day delivery service is available for breakdowns and emergencies.

Telephone: 0845 450 2866 E-mail: [email protected] Fax: 01202 662522

Customer After Sales Services

01.07.2022 3 / 78

AHP60-50/70 - Installation, Use and Maintenance

CONTENTS

REGULATIONS, RECOMMENDATIONS AND WARNINGS..............................................................5

1.1. Applicable regulations and standards ........................................................................................................... 5

1.2. Recommendations and warnings................................................................................................................. 5

2. DESCRIPTION OF THE EQUIPMENT ..............................................................................15

2.1. Designations and scope.............................................................................................................................. 15

2.2. Packaging ................................................................................................................................................... 15

2.3. Denitions ................................................................................................................................................... 15

2.4. Technical data ............................................................................................................................................. 16

2.5. Description .................................................................................................................................................. 20

2.6. Operating principle ...................................................................................................................................... 22

3. INSTALLATION ...................................................................................................................24

3.1. Lifting and handling ..................................................................................................................................... 24

3.2. Installation ................................................................................................................................................... 25

3.3. Installing the outdoor unit ............................................................................................................................ 25

3.4. Installing the control unit ............................................................................................................................. 32

3.5. Position of the centre of gravity and the vibration shock absorbers............................................................ 32

3.6. Hydraulic connections ................................................................................................................................. 33

3.7. Electrical connections ................................................................................................................................. 39

4. PRE-REQUISITES BEFORE COMMISSIONING .............................................................44

4.1. Verication before switching on................................................................................................................... 44

4.2. Switching On ............................................................................................................................................... 45

4.3. Commissioning ........................................................................................................................................... 45

4.4. Primary loop ow rate/cascade balance adjustment................................................................................... 45

4.5. Operating

diagram ....................................................................................................................................... 46

4.6. TYNEHAM user interface navigation .......................................................................................................... 48

5. CONTROL INTERFACE .....................................................................................................49

5.1. User interface.............................................................................................................................................. 49

5.2. “SET” setpoint menu (For manual operation only) ................................................................50

5.3. Sensor menu [TP] ....................................................................................................................................... 51

5.4. Error menu [Err] .......................................................................................................................................... 51

5.5. Operating hours menu [OHR] ..................................................................................................................... 51

5.6. Parameter menu [Par]................................................................................................................................. 51

6. TROUBLESHOOTING .......................................................................................................52

6.1. Troubleshooting of failures without error code ............................................................................................ 52

6.2. Error codes and diagnostic assistance ....................................................................................................... 52

6.3. Inverter board errors ................................................................................................................................... 59

6.4. Ohmic values of the various sensors .......................................................................................................... 61

7. MAINTENANCE OF THE OUTDOOR UNIT......................................................................62

7.1. Drainage of the outdoor unit on the water side ........................................................................................... 62

7.2. Filling the outdoor unit................................................................................................................................. 62

7.3. Prolonged shutdown ................................................................................................................................... 62

7.4. Periodic checks ........................................................................................................................................... 62

4 / 78 00U07362410-A_EN 01.07.2022 5 / 78

7.5. Cleaning the external surfaces.................................................................................................................... 65

7.6. Maintenance of the outdoor unit.................................................................................................................. 65

7.7. Residual safety risks ................................................................................................................................... 66

7.8. Heavy maintenance work............................................................................................................................ 67

7.9. “Maintenance” check list ............................................................................................................................. 68

8. END OF PRODUCT LIFE- ..................................................................................................74

9. ANNEX A - DATA FOR PRODUCTS ≤ 70KW .........................................................76

■Symbols used in this document

INFORMATION: This symbol draws attention to comments.

CAUTION: Failure to comply with these instructions may cause damage to the

installation or to other objects.

WARNING: Failure to comply with these instructions may cause electrocution.

WARNING: Failure to comply with these instructions may cause injury and serious

damage to property.

4 / 78 00U07362410-A_EN 01.07.2022 5 / 78

1. REGULATIONS, RECOMMENDATIONS AND WARNINGS

1.1. Applicable regulations and standards

This outdoor heat pump has been designed in accordance with current regulations and

must be used accordingly. See the list of standards on the back cover.

This device must be transported in compliance with the Local Laws.

This device and its refrigerant R32 must be handled in compliance with the application

orders of the F Gas regulations. Specic guidelines related to the presence of Fluorine

in the composition of the R32 uid are specied in the European Union regulation n°

517/2014.

It must be installed in compliance with local or national regulations such as the RSD (Local

sanitary Regulations), and in accordance with standard EN 378-3: 2016 concerning the

installation of heat pumps.

The electrical connection must be made in compliance with the Current I.E.E. (BS7671)

Wiring Regulations standard.

The hydraulic connection must be made in compliance with the Local Laws

Regulations covering Maintenance

The appliance must be installed and maintained by an approved professional in

accordance with the prevailing regulations and code of practice, in particular:

-The legislation on the handling of refrigerants

-Current I.E.E. (BS7671) Wiring Regulations

CAUTION:

This device must be maintained by qualied personnel with a certicate of capacity

for the handling of refrigerants.

1.2. Recommendations and warnings

1.2.1. Transport and storage

The outdoor appliance and the hydraulic station:

- must be stored in a place where the temperature is between -10°C and +50 °C with

a relative humidity between 5 and 95%.

- must not be stacked,

- must be protected from humidity.

Transport and storage must comply with the national standards in force. In particular,

according to the provisions of the ADR (see below), the maximum total quantity per

transport unit for ammable gases is 333 kg (net mass).

Handling

The outdoor unit must not be in a horizontal position during transport.

Transport in a horizontal position may damage the appliance by moving the refrigerant

and damaging the compressor's suspensions.

Damage caused by transportation in a horizontal position is not covered by the warranty.

If necessary, the outdoor unit may be tilted during manual handling (to go through a door

or use a staircase). This operation must be conducted very carefully and the appliance

must be immediately restored to the upright position.

6 / 78 00U07362410-A_EN 01.07.2022 7 / 78

1.2.2. Unpacking the appliance

Acceptance

With the carrier present, carefully check the general appearance of the packaging and the

appliances. Check that the outdoor appliance has not been placed in a horizontal position.

In the event of disagreement, write to the carrier within 48 hours mentioning all reserves

and send a copy of this letter to the After Sales Department.

Before unpacking the appliance, check that there are no refrigerant leaks using a suitable

detector. Check that there are no ignition sources near the unit.

Smoking is forbidden near to the unit.

1.2.3. Safety recommendations related to the presence of the R32 refrigerant

The handling and installation of this outdoor appliance must only be performed by

personnel that are duly trained, qualied and authorised to carry out these operations,

according to the laws, directives and standards applicable in each country.

The EN378:2016 standard denes the framework of requirements to be met to manage

each potential risk at each stage of the machine's life cycle. This standard was also used

to design this machine.

In the absence of local building codes or safety standards, the installation and maintenance

of the machine may follow the elements outlined in this standard; in particular, it is the

responsibility of the installer and personnel performing operations on this machine to

perform a risk analysis prior to any installation and work on the machine.

The elements indicated below are not exhaustive given the diversity of the possible

installations and interventions; they cannot be considered as an undertaking as

to the responsibility of Hamworthy Heating. These elements cannot replace a risk

analysis, which remains the responsibility of the installer and the personnel working

on the machines.

Designation R32.

INDICATION OF DANGERS

Main dangers: Asphyxia.

Specic dangers: The rapidity of evaporation can cause burns.

EMERGENCY MEASURES

General information Do not give anything to persons who have fainted.

Inhalation:

Take the person to fresh air.

Use oxygen or articial respiration if required.

Do not administer adrenaline or similar substances.

Contact with the eyes: Rinse thoroughly with water for at least 15 minutes and seek

medical attention.

Contact with the skin:

Rinse thoroughly with water for at least 15 minutes. Apply a sterile

gauze.

Remove contaminated clothing immediately.

FIRE PREVENTION MEASURES

Extinguishers: Water spray, dry powder.

Specic dangers: Rupture or explosion of the recipient.

Specic methods:

Cool down the recipients by spraying with water from a safe

position. If possible, stop the product from leaking. If possible, use

a water spray to hose down the smoke. Move the recipients well

clear of the re zone if possible without taking risks.

6 / 78 00U07362410-A_EN 01.07.2022 7 / 78

MEASURES IN THE EVENT OF AN ACCIDENTAL LEAK

Individual precautions:

Use personal protection equipment.

Evacuate the personnel to safe areas.

Eliminate ignition sources.

Ensure there is adequate ventilation.

Environmental precautions: Try to stop the leak.

Cleaning methods: Ventilate the area.

HANDLING AND STORAGE

Handling:

Technical measures/precautions: Ensure that the premises have adequate air renewal/extraction .

Recommendations for safe use: Do not breathe in the vapours or use aerosols.

Storage

Close tightly and store in a cool, dry, well-ventilated place.

Keep in original recipients. Incompatible products: explosives,

ammable materials, organic peroxide.

CONTROLLED EXPOSURE/INDIVIDUAL PROTECTION

Control parameters:

DNEL: Derived No-E󰀨ect-Level (workers)

long term, systemic e󰀨ects, inhalation = 7035 mg/m3.

PNEC: Predicted No E󰀨ect Concentration

Water (fresh water) = 0.142 mg/l

Aquatic, intermittent emissions = 1.42 mg/l

Sediments, fresh water = 0.534 mg/kg dry weight

Respiratory protection:

Protection of the eyes:

Not necessary.

Safety glasses.

Protection of the hands: Rubber gloves.

Hygiene measures: Do not smoke!

PHYSICAL AND CHEMICAL PROPERTIES

Colour Colourless.

Smell: Ethereal. Hardly perceptible in low concentrations.

Boiling point: -51.7 °C at atm. press.

Flash point: 648°C

Lower ammability level 13%

Upper ammability level 32%

Relative density of gas (air=1) 1.8

Relative density of liquid (water=1) 1.1

Solubility in water: 280000 mg/l.

STABILITY AND REACTIVITY

Stability: Stable in normal conditions.

Materials to be avoided:

Hazardous decomposition products

Hazardous:

Air, oxidising agents, humidity.

In normal conditions of storage and use, no hazardous

decomposition product should be generated.

8 / 78 00U07362410-A_EN 01.07.2022 9 / 78

TOXICOLOGICAL INFORMATION

High toxicity:

Local e󰀨ects:

Long term toxicity:

LD/LC50/inhalation/4 hours/rat test = 1107000 mg/m3.

No known e󰀨ects.

ENVIRONMENTAL INFORMATION

Global warming potential

GWP (R744=1): 675

Ozone damage potential ODP

(R11=1):

Of the ozone ODP (R11=1):

Disposal Considerations: Comply with the supplier’s gas collection programme. Avoid direct

emission into the atmosphere.

■ Specic warnings on the R32 refrigerant

The R32 refrigerant:

- is odourless;

- is slightly inammable (A2L), but only in the presence of ames;

- Risk of explosion at air concentrations between the lower and upper ammability levels of the

uid, see refrigerant data sheet above.

It is essential to follow the following guidelines:

- do not smoke near to the appliance ;

- put up no smoking signs near to the appliance ;

- ensure that it is installed in a well-ventilated area

- do not pierce or burn the appliance ;

- do not position the appliance near to ignition sources, such as naked ames, electric heaters,

etc.;

- any special work or repairs to the appliance must be carried out by specialised technicians or

qualied personnel;

■ R32 refrigerant load

The procedures described below must only be performed by specialised technicians or

qualied personnel:

- ensure that other types de refrigerant do not contaminate the R32;

- keep the gas bottle in a vertical position when loading it;

- put a suitable label on the unit after loading it;

- do not load more refrigerant gas than needed;

- before loading, search for leaks before carrying out an operating test. This operation has two

purposes, to control the quantity of refrigerant loaded and to check the circuit for leaks,

- after the operating test, we recommend carrying out another leak test,

■ Eliminating the R32 refrigerant

Follow the standardised procedures for collecting refrigerants, which may only be carried

out by specialised technicians or qualied personnel, and return it to the supplier.

■ Installation precaution related to the refrigerant

If local construction codes or safety standards don’t exist, the information shown below are

taken from the standard EN378: 2016 may be used for information; they may be used as a guide

for the safe use of machines that use R32 as a refrigerant.

This outdoor unit must not be installed in a place that can the general public or untrained,

qualied or approved persons can access.

It is designed to be installed outdoors, in open air. A shelter or alcove in which at least one of

the longest walls is open to the outside air by louvers having a free area of 75% and covering

8 / 78 00U07362410-A_EN 01.07.2022 9 / 78

at least 80% of the wall (or the equivalent if more than one wall is open to the outside

air), is considered to be open to the outside air.

It must be located so that no refrigerant leaks can enter the building and/or endanger

people and property. Therefore:

It must not be possible for the refrigerant to spill into a ventilation duct, under

a door, hatch or similar opening in case of a leak. For this reason, the installer

must ensure that there is a distance of at least 1m between the unit and any such

opening. When a shelter is provided for the refrigerant appliance in the open air,

this shelter must be equipped with a natural or forced ventilation device.

For refrigerant appliances which are installed outdoors at a location where a

refrigerant release may stagnate, for example, below ground level, the installation

must meet the requirements relative to gas detection and machine room ventilation.

1.2.4. Recommendations for hydraulic and electrical circuits

■Hydraulic connections

The connection must comply with good engineering practices according to the regulations

in force.

Reminder: Make the assembly seals according to good engineering practices in force

for plumbing work:

- Use suitable seals or gaskets (bre seals, O rings).

- Use Teon or hemp tape.

- Use sealant (synthetic as required).

■ Characteristics of the water for the appliance

To ensure that the appliance is working correctly, the water must be ltered correctly

(see the indications at the beginning of this section) and the quantity of dissolved must

be minimised.

Refer to chapter 3.6.4. For further recommendations.

The maximum authorised values are as follows:

Use glycol water if the room where the primary/secondary storage tank(s) is/are installed

is not frost-free; we recommend that this situation be temporary so as not to alter the

system’s

MAXIMUM AUTHORISED PHYSICAL-CHEMICAL CHARACTERISTICS AUTHORISED FOR THE INSTALLATION

WATER

PH 7.5 - 9

Electrical conductivity 100 - 500 μS/cm

Total hardness 8.0 - 15.1 °f

Temperature ˂ 65°C

Oxygen content ˂ 0.1 ppm

Max. quantity of glycol 40%

Iron (Fe) < 0.3 ppm

Chlorine ions (Cl-) < 50 ppm

10 / 78 00U07362410-A_EN 01.07.2022 11 / 78

Percentage of

glycol Freezing point [°C] Eciency cor-

recon factor

Absorbed power

correcon factor

Water ow rate

correcon factor

Loss of head cor-

recon factor

10% -3.2 0.985 1 1.02 1.08

20% -7.8 0.98 0.99 1.05 1.12

30% -14.1 0.97 0.98 1.10 1.22

40% -22.3 0.965 0.97 1.14 1.25

performance permanently. Do not forget to ush the system once the room is frost-free.

If glycol water is used, plan an annual control of the glycol quality. Use monopropylene

type glycol only. The recommended concentration should not exceed 40%.

If glycol is not used, trace the pipes electrically outside.

• In certain installations, the presence of di󰀨erent metals can cause corrosion

problems; in this case, the formation of metal particles and sludge in the

hydraulic circuit is seen.

-Please refer to the chapter “Treatment of domestic and heating water” in our price

catalogue

• It is also necessary to ensure that the treated water does not become aggressive

for the circuit.

■Electrical connections

Ensure that the general electrical power supply has been cut o󰀨 before starting any

repair work.

Characteristics of the electrical power supply

The electrical installation must be conducted in accordance with the regulations in e󰀨ect

and in particular to current I.E.E. (BS7671) Wiring Regulations

The electrical installation must be equipped with a di󰀨erential protection.

This appliance is designed to operate under a nominal voltage of 400 V +/- 10%, 50 Hz.

For installations without neutral, a galvanic isolating transformer must be used that is

earthed on the secondary side.

The electrical connections will only be made when all of the other assembly operations

(attachment, assembly,...) have been carried out.

Never use a socket for the power supply.

CAUTION:

The contract with the energy supplier must cover the maximum electrical requirement of

the installation.

The outdoor unit must be supplied directly (without external switch) by a dedicated line

protected at the start by a dedicated isolator switch. (Seer “Current source” paragraph).

Autres manuels pour TYNEHAM AHP60

Table des matières

Autres manuels Hamworthy Pompe à chaleur

Hamworthy

Hamworthy TYNEHAM AHP60 Guide de l'utilisateur

Manuels Pompe à chaleur populaires d'autres marques

MICROWELL

MICROWELL HP 1000 GREEN Manuel utilisateur

Sanyo

Sanyo SAP120FCH Manuel utilisateur

Daikin

Daikin EHYHBH05AA Manuel utilisateur

Panasonic

Panasonic WH-SDF03E3E5 Mode d’emploi

Bryant

Bryant 544B Manuel utilisateur

Airxcel

Airxcel 45000 Series Manuel

Mitsubishi Electric

Mitsubishi Electric PUZ-SWM60VAA Manuel utilisateur

Dimplex

Dimplex LI 16I-TUR Guide de l'utilisateur

Carrier

Carrier WSHP Open v3 Guide de configuration rapide

TGM

TGM CTV14CN018A Manuel utilisateur

Carrier

Carrier 38MGQ Series Manuel utilisateur

Kokido

Kokido K2O K880BX/EU Guide de dépannage

Viessmann

Viessmann VITOCAL 300-G PRO Type BW 2150 Guide rapide

Carrier

Carrier 48EZN Manuel utilisateur

Viessmann

Viessmann KWT Vitocal 350-G Pro Series Mode d'emploi

Ariston

Ariston NIMBUS Manuel utilisateur

Weishaupt

Weishaupt WWP L 7 Guide de l'utilisateur

GE Zoneline AZ85H09EAC Manuel utilisateur
