HAMPTON BAY FTS80721 Manuel utilisateur

THANK YOU

quality products designed to enhance your home. Visit us online to see our full line of products available for your home improvement needs.

Thank you for choosing Hampton Bay!

Item # 1000 246 933

Model # FTS80721

USE AND CARE GUIDE

BELLEVILLE COFFEE TABLE

1-855-HD-HAMPTON

HAMPTONBAY.COM

Questions, problems, missing parts? Before returning to the store,

call Hampton Bay Customer Service

8 a.m. - 7 p.m., EST, Monday - Friday, 9 a.m. - 6 p.m., EST, Saturday

Table of Contents

Table of Contents..........................................................2

Safety Information .......................................................2

Product Caution ...................................................................... 2

Safety Information .................................................................. 2

Pre-Assembly ................................................................3

Planning Assembly .................................................................. 3

Hardware Included .................................................................. 3

Care and Cleaning........................................................ 8

Warranty

2 YEAR FRAME LIMITED WARRANTY

WHAT IS COVERED

We warrant the frames tobe free of manufacturing defectstothe original purchaser for two years.

WHAT IS NOT COVERED

Contact theCustomerService Team at 1-855-HD-HAMPTON or visit www.HamptonBay.com.

Safety Information

It remainsthecustomer’sresponsibility for freight and packaging charges to and from our servicecenter. This warranty does not cover

reserve the right to make substitutions with similar merchandise, if the model in question isno longer in production.

Assembly ....................................................................... 5

Package Contents ................................................................... 4

PRODUCT CAUTION

This coffee table was made for the explicit purpose of providing outdoor functions and is not to be used as atoy. This productis not

intended for inclement / severe weather in any form including, but not limitedto: rain, hail, sleet, snow and / orwind. The manufacturer

e. Do

not use product asasupport. Do not shake, lean or climb on product. Children under the age of 10, near the product, should be supervised

by a competent adult at all times. This product is NOT intended for commercial use and will void the warranty.

SAFETY WARNINGS

WARNING: This coffee table unit is heavy, and may

requiretwo adults for safe assembly.

WARNING: Do not place heavy objects on the table.

CAUTION: Do notlocate the product near any

heat source.

CAUTION: Never usethis product as a support.

Do not shake, lean, or climb on either the chair

or the tableatanytime.

Warranty ........................................................................2

What is Covered ...................................................................... 2

What is Not Covered ................................................................ 2

Pre-Assembly

PLANNING ASSEMBLY

Read all instructions before assembly.

To avoid damaging this product, assemble it on a soft, non-abrasive surface such as carpet or cardboard.

NOTE: More than one person may be required to

assemble this product.

Part Description Quantity

CC Hex wrench

8+1

M6x15 combination bolt

M6x20 combination bolt

AA BB CC

HARDWARE INCLUDED

NOTE: Hardware not shown to actual size.

HAMPTONBAY.COM

Please contact 1-855-HD-HAMPTON for further assistance.

Pre-Assembly(continued)

Part Description Quantity

A Tile 6

B Table rim 1

C Leg connector 1

D Table leg 4

PACKAGE CONTENTS

Assembly

1Connecting the table leg

Place the table rim (B) upside down on a soft surface.

Attach each of the table legs (D) to the table rim (B) using M6x20 combination bolts (BB).

NOTE: Loosely tighten all the bolts using the hex wrench (CC).

HAMPTONBAY.COM

Please contact 1-855-HD-HAMPTON for further assistance.

BB BB

Assembly (continued)

Connecting the leg connector to the table legs

NOTE: Loosely tighten all the bolts using the hex wrench (CC).

Align the holes on the leg connector (C) with the holes on the inside of each table leg (D).

Attach the leg connector (C) to the table legs (D) using M6x15 combination bolts (AA).

Assembly (continued)

Adding the tiles

Turn the tablerightside up.

Ensureall connections are secure.

Carefullyplacethe tiles(A) onto the table rim (B).



HAMPTONBAY.COM

Please contact 1-855-HD-HAMPTON for further assistance.

Assembly (continued)

Securing the table

Tighten all the bolts.

Check and ensure the table is tightly assembled and stable before use.

Care and Cleaning

For best results, clean the frames with a damp cloth and dry thoroughly. This will help prevent mildew by removing dirt particles that

may accumulate.

Do not clean with abrasive materials, bleach, or solvents.

Store the table in a dry, sheltered place when not in use.

ng conditions, and inclement weather such as rain, hail, sleet, snow, or wind.

1-855-HD-HAMPTON

HAMPTONBAY.COM

Retain this manual for future use.

Questions, problems, missing parts? Before returning to the store,

call Hampton Bay Customer Service

8 a.m. - 7 p.m., EST, Monday - Friday, 9 a.m. - 6 p.m., EST, Saturday
