Table of Contents

222875

Thank you for purchasing our ceiling fan. This product has been

manufactured with the highest standards of safety and quality.

845952000230

CF546KR

Safety Rules · · · · · · · · · ·

Unpacking Your Fan · · · · · · · ·

Installing Your Fan · · · · · · ·

Hanging Your Fan · · · · · · · ·

Making the Electrical Connections· ·

Finishing the Installation ·····

Attaching the Fan Blades ·····

Installing without the Light Kit ···

Operating Your Transmitter ····

Care of Your Fan ·········

Troubleshooting · · · · · · · · ·

Specifications · · · · · · · · · ·

Safety Rules - Read and Save These Instructions

WARNING

To reduce the risk of electric shock, insure electricity has been

turned off at the circuit breaker or fuse box before beginning.

All wiring must be in accordance with the National Electrical

Code “ANSI/NFPA 70-1999” and local electrical codes. Electrical

installation should be performed by a qualified licensed

electrician.

WARNING: To reduce the risk of electrical shock or fire, do not

use this fan with any solid-state fan speed control device. It will

permanently damage the electronic circuitry.

CAUTION: To reduce the risk of personal injury, use only the

screws provided with the outlet box.

The outlet box and support structure must be securely mounted and

capable of reliably supporting a minimum of 35 pounds. Use only

UL Listed outlet boxes marked “FOR FAN SUPPORT”.

The fan must be mounted with a minimum of 7 feet clearance from

the trailing edge of the blades to the floor.

Avoid placing objects in path of the blades.

To avoid personal injury or damage to the fan and other items, be

cautious when working around or cleaning the fan.

Do not use water or detergents when cleaning the fan or fan blades.

A dry dust cloth or lightly dampened cloth will be suitable for most

cleaning.

After making electrical connections, spliced conductors should be

turned upward and pushed carefully up into outlet box. The wires

should be spread apart with the grounded conductor and the

equipment-grounding conductor on one side of the outlet box and

ungrounded conductor on the other side of the outlet box.

All set screws must be checked and retightened where necessary

before installation.

10.

11.

TO REDUCE THE RISK OF PERSONAL INJURY, DO NOT BEND THE

BLADE ARMS (ALSO REFERRED TO AS FLANGES), WHEN

INSTALLING THE BRACKETS, BALANCING THE BLADES OR

CLEANING THE FAN. DO NOT INSERT FOREIGN OBJECTS IN –

BETWEEN ROTATING FAN BLADES.

TO REDUCE THE RISK OF FIRE, ELECTRIC SHOCK OR PERSONAL

INJURY, MOUNT FAN TO OUTLET BOX MARKED ACCEPTABLE FOR

FAN SUPPORT WITH THE SCREWS PROVIDED WITH THE OUTLET

BOX.

9. Switch box (1)

10.

11.

12.

Receiver (1)

Transmitter (1)

11A. Mounting plate for Remove Control

Balancing kit (1)

2. Mounting bracket (1)

3. Canopy (1)

4. Canopy cover (1)

5. Ball/downrod assembly (1)

6. Coupling cover (1)

7. Fan motor assembly ( 1 )

8. Set of blades brackets (5)

Set of blades (5) (MDF blades)

WARNING

DO NOT INSTALL OR USE FAN

IF ANY PART IS DAMAGED OR MISSING.

CALL TOLL FREE 1-877-262-7511

13. Loose parts bag containing:

a . Blade attachment hardware (16 screws )

b. Mounting hardware (3 plastic wire

connectors)

c. Set of blade bracket hardware (11

screws)

d. Screw for remote control (2 PC)

Unpack your fan and check the contents. You should have the following items:

Unpacking Your Fan

11A

Installing Your Fan

WARNING

Outlet Box

Figure 2

Figure 1

Ceiling

Mounting

Plate

Provide Strong

Support

Recessed

Outlet Box

Figure 3

Figure 4

Tools Required

Mounting Options

Phillips screwdriver, straight slot

screwdriver, step ladder and wire cutters.

If there isn't an existing UL listed mounting

box, then read the following instructions.

Disconnect the power by removing fuses or

turning off circuit breakers.

Secure the outlet box directly to the building

structure. Use appropriate fasteners and

building materials. The outlet box and its

support must be able to fully support the

moving weight of the fan (at least 35 lbs). Do

not use plastic outlet boxes.

TO REDUCE THE RISK OF FIRE, ELECTRIC

SHOCK OR PERSONAL INJURY, MOUNT FAN

ONLY TO AN OULET BOX MARKED ACCEPT-

AB L E FO R FA N S U P P O RT A N D US E THE

MOUNTING SCREWS PROVIDED WITH THE

OULET BOX. OUTLET BOX COMMONLY USED

FOR THE SUPPORT OF LIGHTING FIXTURE MAY

NOT BE ACCEPTABLE FOR FAN SUPPORT AND

MAY NEED TO BE REPLACED. CONSULT A

QUALIFIED ELECTRICIAN IF IN DOUBT.

Figures 1~3 are examples of different ways to

mount the outlet box.

Note: You may need a longer downrod to

maintain proper blade clearance when

installing on a steep, sloped ceiling. The

maximum angle allowable is 18°. If the

canopy touches downrod, remove the

decorative canopy bottom cover and turn the

canopy 180° before attaching the canopy to

the mounting plate.

To hang your fan where there is an existing

fixture but no ceiling joist, you may need an

installation hanger bar as shown in Figure 4

(available at any Home Depot store).

Coupling

Cover

Motor Collar

Figure 9

Lead Wires

Ball/Downrod

Assembly

Canopy

REMEMBER to turn off the power. Follow the

steps below to hang your fan properly:

3. Remove hanger ball from downrod assembly

by loosening set screw, removing the cross pin,

and sliding ball off rod.

(Figure 7)

4. Carefully feed fan wires up through the

downrod. (Figure 8) Thread the rod into the

coupling. Next, line up holes and replace lock

pin and hitch pin. Tighten set screws.

5. Slip coupling cover, canopy cover and

canopy onto downrod. (Figure 9) Carefully

reinstall hanger ball onto downrod, make sure

that cross pin is in correct position, set screws

are tighten and wires are not twisted.

Secure the mounting bracket to the

ceiling outlet box with the screws and

washers provided with your outlet box.

(Figure 5)

2. Loosen the two set screws from the

motor assembly. (Figure 6)

Remove the hitch pin

and lock pin from the downrod assembly.

6. Now lift motor assembly into position and place

hanger ball into mounting bracket. Rotate until the

check groove

should not rotate

if this is done correctly.

drops into the registration slot and

seats firmly. (Figure 10) Downrod

Figure 6

Downrod

Supply

wires

Figure 8 Figure 10

Registration

slot

Figure 5

Cross pin

Hanger

ball

Downrod

Figure 7

Outlet box

Mounting bracket

Hitch

Lock

Set

screws

Hitch

Lock

Hanging the Fan

Figure 12

Receiver

Mounting

bracket

WARNING: To avoid possible electrical

shock, be sure electricity is turned off at

the main fuse box before wiring.

NOTE: This remote control unit is

equipped with 16 code combinations to

prevent possible interference from or to

other remote units. The frequency

switches on your receiver and transmitter

have been preset at the factory. Please

recheck to make sure the switches on

transmitter and receiver are set to the

sa me posit ion, any com bina tion of

settings will operate the fan as long as the

transmitter and receiver are set to the

same position. (Figure 11)

Step 1. Insert the receiver into the

mounting bracket with the flat side of

the receiver facing the ceiling. (Figure

12)

Step 2. Motor to Receiver Electrical

Connections: Connect the black wire

from the fan to black wire marked "TO

MOTOR L". Connect the white wire

from the fan to the white wire marked

"TO MOTOR N" from the receiver.

Connect the blue wire

from the fan to the blue wire marked "For

Light" from the receiver. Secure the wire

connections with the plastic wire nuts

provided. (Figure 13)

Step 3. Receiver to House Supply Wires

Electrical Connections: Connect the

black (hot) wire from the ceiling to the

black wire marked "AC in L" from the

receiver. Connect the white (neutral) wire

from the ceiling to the white wire marked

"AC in N" from the Receiver. Secure the

wire connections with the plastic wire

nuts provided. (Figure 13)

St e p 4 . If your outlet box has a ground

wire (green or bare copper) connect it

to the fan ground wires; otherwise

connect the hanging bracket ground wire

to the mounting bracket. Secured the wire

connection with a plastic nut provided.

After connecting the wires spread them

apart so that the green and white wires are

on one side of the outlet box and black

and blue wires are on the other side.

Carefully tuck the wire connections up

into the outlet box. (Figure 13)

Figure 11

Code switch

Rubber

cover

Making the Electrical Connections

Figure 14

Outlet box

Mounting

bracket

Canopy

Screw

Step 1. Tuck connections neatly into ceiling

outlet box.

Step 2. Remove one screw from the mounting

bracket and loosen the other screw

approximately 1/4.

Step 3. Align the canopy up to ceiling and over

the loosened screw. Place the canopy into key

hole and rotate canopy clockwise. (Figure

14)

Step 4. Secure the canopy by using

previous removed screw.

Step 5. Place the canopy over the canopy

and rotate canopy cover clockwise until

locked into right position.(Figure 14)

SUPPLY CIRCUIT

Ground

Conductor

Outlet Box

Green

Ground

Lead

Ground to

Downrod

BLACK

WHITE

BLACK

BLUE

GREEN

Figure 13

Canopy Cover

WARNING

MAKE SURE TAB AT BOTTOM OF HANGER

BRACKET IS HANGER PROPERLY SEATED IN

GROOVE OF HANGER BALL BEFORE

ATTACHING CANOPY TO BRACKET. FAILURE TO

PROPERLY SEAT TAB IN GROOVE COULD CAUSE

DAMAGE TO ELECTRICAL WIRING.

Finishing the Installation

Step 1. A ttach the blades to the blade brackets

using the screws provided as shown in Figure

15. Start a screw into the blade bracket, but do

not tighten. Repeat for the 2 remaining screws

and washers.

Step 2. Tighten each screw securely. Make

sure the blade is straight.

Step 3. Use the 10 screws from the loose parts

b a g c o n t a i n i n g ( c ) . F a s t e n t h e bl a d e

assemblies to the motor (Figure 16) then

tighten the tw o s cr e w s t o e ac h b l a d e

assemblies (Figure 16A).

Touching

ceiling

Figure 17

The following procedure should correct most

fan wobble issues. Check after each step.

Step 1. Check that all blades and blade

bracket screws are secure.

(Please

refer to the introduction provide in the blade

balancing kit, which is individually packed.)

Step2 . M ost fan wobble problems are caused

when blade levels are unequal. Check this

level by selecting a point on the ceiling above

the tip of one of the blades. Measure this

distance as shown in Figure 17. Rotate the fan

un til th e next bl ade i s posi tio ned fo r

measurement. Repeat for each blade. The

distance should be equal within 1/8".

If all blade levels are not equal, you can adjust

the blade level with the following procedure.

Step 3. Use the enclosed Blade Balancing Kit

if the blade wobble is still noticeable.

Step 4. If the blade wobble is still noticeable,

interchanging two adjacent (side by side)

blades can redistribute the weight and

possibly result in smoother operation.

Figure 16

Motor assembly

Blade Bracket

Blade

bracket

Blade

Screws

Figure 15

Washer

Figure 16A

Blade Bracket

Screw

Motor Assembly

WARNING

TO REDUCE THE RISK OF PERSONAL INJURY, DO

NOT BEND THE BLADE BRACKET WHILE

INSTALLING, BALANCING THE BLADES, OR

CLEANING THE FAN.

DO NOT INSERT FOREIGN OBJECTS BETWEEN

ROTATING FAN BLADES.

Attaching the Fan Blades

Autres manuels pour Bryant

Ce manuel convient aux modèles suivants

Table des matières

Autres manuels HAMPTON BAY Ventilateur

HAMPTON BAY

HAMPTON BAY STANCE 52-STAN 52-STAN Manuel utilisateur

HAMPTON BAY

HAMPTON BAY TIPTON II 52 INCH Manuel utilisateur

HAMPTON BAY

HAMPTON BAY CF556A-H26 Manuel utilisateur

HAMPTON BAY

HAMPTON BAY Bay Island Manuel utilisateur

HAMPTON BAY

HAMPTON BAY WELLSTON EF200B-44 Manuel utilisateur

HAMPTON BAY

HAMPTON BAY MONTGOMERY RDB91-WH Manuel utilisateur

HAMPTON BAY

HAMPTON BAY 52-LASO Manuel utilisateur

HAMPTON BAY

HAMPTON BAY Mercer Manuel utilisateur

HAMPTON BAY

HAMPTON BAY METARIE II YG922B-MBK Manuel utilisateur

HAMPTON BAY

HAMPTON BAY Dawson 581 645 Manuel utilisateur

HAMPTON BAY

HAMPTON BAY Redington 740-125 Manuel utilisateur

HAMPTON BAY

HAMPTON BAY 91371 Manuel utilisateur

HAMPTON BAY

HAMPTON BAY GLENDALE II AG524PR-WH Manuel utilisateur

HAMPTON BAY

HAMPTON BAY 120-231 Manuel utilisateur

HAMPTON BAY

HAMPTON BAY 593-543 AL958-ORB Manuel utilisateur

HAMPTON BAY

HAMPTON BAY Glendale Manuel utilisateur

HAMPTON BAY

HAMPTON BAY Trieste Manuel utilisateur

HAMPTON BAY

HAMPTON BAY SINCLAIR 798-072 Manuel utilisateur

HAMPTON BAY

HAMPTON BAY CLARKSTON CF544H-PEH Manuel utilisateur

HAMPTON BAY

HAMPTON BAY Palm Beach II Manuel utilisateur

HAMPTON BAY

HAMPTON BAY Sabitini Manuel utilisateur

HAMPTON BAY

HAMPTON BAY AC457-WB Manuel utilisateur

HAMPTON BAY

HAMPTON BAY HVW-30M Manuel utilisateur

HAMPTON BAY

HAMPTON BAY ASHBURTON YG593-BN Manuel utilisateur

Manuels Ventilateur populaires d'autres marques

ELTA FANS

ELTA FANS H03VV-F Manuel utilisateur

Hunter

Hunter 20714 Manuel d'instructions

Emerson

Emerson CARRERA VERANDA CF542ORB00 Manuel utilisateur

Hunter

Hunter Caraway Manuel d'instructions

Panasonic

Panasonic FV-15NLFS1 Manuel utilisateur

Kompernass

Kompernass KH 1150 Manuel utilisateur

VES

VES FALA100/12V/TR Manuel utilisateur

Vertiv

Vertiv Liebert DCD Manuel utilisateur

Westinghouse

Westinghouse GFP Series Manuel utilisateur

Venmar

Venmar KUBIX HRV PLUS Series Manuel utilisateur

Maico

Maico ECR 31 Manuel utilisateur

Sonnenkonig

Sonnenkonig Dinky Manuel utilisateur

S&P

S&P ECOWATT HXBR Manuel utilisateur

Wider

Wider IMP03369BH Manuel utilisateur

Panasonic

Panasonic F-60DHN Manuel utilisateur

Hinkley

Hinkley HIGHLAND Manuel utilisateur

Broan

Broan 766BN Manuel utilisateur

Premium

Premium PFS16022 Instructions de montage
