Hamilton Beach 840091300 Manuel utilisateur

Iron

840091300

Important Safeguards ...................... 2

Parts and Features .......................... 3

Using Your Iron ................................ 4

Optional Features ............................ 6

Self-Clean .......................................... 6

Caring for Your Iron.......................... 7

Troubleshooting................................ 7

Customer Service ............................ 8

In USA: 1-800-851-8900

In Canada: 1-800-267-2826

840091300 ENv01 9/24/01 4:32 PM Page 1

IMPORTANT SAFEGUARDS

SAVE THESE INSTRUCTIONS!

When using your flatiron, basic safety precautions should always be followed, including the

following:

READ ALL INSTRUCTIONS BEFORE USING

1. Use iron only for its intended use.

2. To protect against risk of electric shock, do not immerse the iron in water or other liquids.

3. The iron should always be turned to OFF before plugging or unplugging from outlet.

Never yank cord to disconnect from outlet; instead, grasp plug and pull to disconnect.

4. Do not allow cord to touch hot surfaces. Let iron cool completely before putting away.

Loop cord loosely around iron when storing.

5. Always disconnect iron from electrical outlet when filling with water or emptying and

when not in use.

6. Do not operate iron with a damaged cord or if the iron has been dropped or damaged.

To avoid the risk of electric shock, do not disassemble the iron. Call our toll-free customer

service number for information on examination, repair or electrical or mechanical adjust-

ment. Incorrect reassembly can cause a risk of electric shock when the iron is used.

7. Close supervision is necessary for any appliance being used by or near children. Do not

leave iron unattended while connected or on an ironing board.

8. Burns can occur from touching hot metal parts, hot water, or steam. Use caution when

you turn a steam iron upside down – there may be hot water in the reservoir.

SPECIAL INSTRUCTIONS

1. To avoid a circuit overload, do not operate another high wattage appliance on the same

circuit.

2. If an extension cord is absolutely necessary, a 10-ampere cord should be used. Cords

rated for less amperage may overheat. Care should be taken to arrange the cord so that

it cannot be pulled or tripped over.

This product is intended for household

use only.

This appliance is equipped with a polarized

plug. This type of plug has one blade wider

than the other. The plug will fit into an

electrical outlet only one way. This is a

safety feature intended to help reduce the

risk of electrical shock. If you are unable to

insert the plug into the outlet, try reversing

the plug. If the plug should still fail to fit,

contact a qualified electrician to replace the

obsolete outlet. Do not attempt to defeat

the safety purpose of the polarized plug by

modifying the plug in any way.

Use the iron on an ironing board. Ironing

on any other surface may damage that

surface.

Do not iron or vertical steam clothes

that are being worn.

Do not use vertical steam in the direction

of people or pets.

Consumer Safety Information

840091300 ENv01 9/24/01 4:32 PM Page 2

Parts and Features

* Features on selected models.

1. Automatic Shutoff Reset

Button/Light*

2. Spray and Blast Buttons

3. Adjustable Steam Knob

4. Water Fill Cover

5. Spray Nozzle

6. Water Window

7. Temperature Control

Dial

8. Soleplate

9. Heel Rest

10. Power Light

11. Cord

Before First Use

• Steam vents should be cleaned

before first use. Prepare iron for

steam ironing, then iron over an old

cloth for a few minutes while letting

the iron steam. Press the Blast

button several times. This will

clean the vents. Then follow the

Self-Clean instructions (see page 6)

beginning with Step 3.

• Many irons spit or sputter during

the first few uses with tap water.

This happens as the steam chamber

becomes conditioned. This will stop

after a few uses.

840091300 ENv01 9/24/01 4:32 PM Page 3

1. Unplug iron. Turn Adjustable Steam

Knob to (Dry

Iron). Place iron

soleplate on flat

surface. Open

water fill cover.

2. Using a cup, slowly pour 6 ounces

of tap water into water tank opening.

Do not fill iron directly from the

faucet.

3. Plug iron into outlet. Set iron upright

on heel rest.

To Steam Iron

4. Turn the Temperature Control Dial to

desired fabric setting in the steam

range.

5. Allow two minutes for the iron to

reach desired temperature.

6. Set Adjustable Steam Knob to the

recommended

steam level. See

the “Fabric

Setting Chart.”

7. To turn iron off, set Adjustable

Steam Knob to (Dry Iron). Turn

the Temperature Control Dial to Off.

Unplug iron.

8. Empty water from the iron following

directions in “Caring for Your Iron.”

Water

Please use ordinary tap water. If you

have extremely hard water, alternate

between tap water and distilled water

for use in the iron.

To Dry Iron

3. Turn Temperature Control Dial to

desired temp-

erature. Allow

two minutes for

iron to reach

desired

temperature.

4. To turn iron Off, turn Temperature

Control Dial to Off and unplug iron.

1. Plug iron into outlet.

2. Set the Adjustable Steam Knob

to ( Dry Iron).

Using Your Iron

840091300 ENv01 9/24/01 4:32 PM Page 4

1. Unplug iron. Turn Adjustable Steam

Knob to (Dry

Iron). Place iron

soleplate on flat

surface. Open

water fill cover.

2. Using a cup, slowly pour 6 ounces

of tap water into water tank opening.

Do not fill iron directly from the

faucet.

3. Plug iron into outlet. Set iron upright

on heel rest.

4. Turn the Temperature Control Dial

to the highest

setting.

5. Allow two minutes for the iron to

reach desired temperature.

To Vertical Steam

6. Hang garment in a location that is

not susceptible to damage from heat

or moisture. Do not hang in front of

wallpaper, window, or mirror.

7. Hold iron about 6 inches away from

garment and

press and

release the

Blast Button

to steam out

wrinkles. Do not

press Blast

Button more

than once every

2 seconds.

8. To turn iron off, turn Temperature

Control Dial to Off. Unplug iron.

9. Empty water from the iron following

directions in “Caring for Your Iron.”

NOTE: Do not allow hot soleplate to

touch delicate garments.

Fabric Setting Chart

Steam

Setting

Steam Range Dry Iron

Temperature Setting

Off

Nylon, Acrylic

Silk

Wool

Polyester

Rayon

Cotton, Linen

Ironing Instructions

Dry iron using spray if necessary.

Dry iron on the inside of the garment.

Use a press cloth and steam iron on the

inside of garment.

Iron while fabric is still damp.

Iron using spray if necessary.

For cotton, iron while still damp or use

spray. For linen, iron fabric on the inside

of the garment. Use this setting for

vertical steaming.

840091300 ENv01 9/24/01 4:32 PM Page 5

Spray and Blast of Steam Buttons

Push Blast Button for an extra blast of

steam. Push Spray

Button to release a

fine spray of water

for difficult wrin-

kles in cotton or

linen.

Auto Shutoff Reset Button/Light

The light comes on when the iron is

first plugged in.

After one hour,

the iron will shut

off and the light

will go out. Push

the Reset Button/

Light to turn the

iron back on.

Power Light

This light comes on when the iron

is plugged in

and remains on

until the iron is

unplugged. The

light stays on even

if Temperature

Control Dial is

turned to Off.

Adjustable Steam Knob

This knob provides minimum steam for

wool or maximum

steam for linen.

Set the knob to

to change to Dry

Iron.

Power

Light

Optional Features (on selected models)

Blast Spray

Self-Clean

1. Fill iron with water. Plug in iron.

2. Turn Temperature Control Dial to

Linen setting and let iron heat for

2 minutes.

3. Turn Temperature Control Dial to Off.

Unplug iron and hold over a sink

with the soleplate facing down.

4. Turn Adjustable Steam Knob to

(Self-Clean). Hot water and steam

will flow out of steam vents.

5. Allow all water to drain from iron,

then let cool and store.

To keep the steam vents clear of any build-up, follow these instructions after each

time you use the iron using steam.

840091300 ENv01 9/24/01 4:33 PM Page 6

Troubleshooting

PROBLEM

Iron won’t heat.

Water is leaking

out of the iron.

Iron won’t steam.

Iron leaves spots

on clothing.

Wrinkles not

removed.

Iron too hot.

Things TO CHECK

• Is the iron plugged in and the outlet working?

Check the outlet by plugging in a lamp.

• Is Temperature Control Dial turned to a fabric setting?

• If auto shutoff model, is the Reset Button/Light

illuminated? If not, push to reset.

• Do not overfill the water tank.

• If steam ironing, is Adjustable Steam Knob in a steam

position that matches Temperature Control Dial steam

range? Did the iron have enough time to preheat?

• If dry ironing, make sure the Adjustable Steam Knob is

in the DRY IRON position.

• Check the water level.

• Is the Adjustable Steam Knob in the STEAM position?

• Has the iron had enough time to preheat?

• ALWAYS empty the water tank of the iron after

using. Water left in the tank may discolor clothing

and soleplate.

• Check Temperature Control Dial is set to

correct fabric.

• Check Temperature Control Dial and set to lower

setting. Let iron cool down 5 minutes before

continuing.

Caring for Your Iron

Soleplate

1. Never iron over zippers, pins, metal

rivets, or snaps, as these may

scratch the soleplate.

2. To clean occasional build-up on the

soleplate, wipe with a hot, sudsy

cloth. Do not use abrasive cleansers

or metal scouring pads. Do not

immerse in water.

3. Always store iron upright in the heel

rest position.

Iron

1. The water tank of your iron should

be emptied after each use. Turn

Temperature Control Dial to Off.

Unplug the iron and hold over a sink.

Slowly tilt pointed end of iron

down over sink. Water will run out

of water tank opening.

2. After iron has completely cooled,

wrap cord loosely around iron and

store in an upright position. Do not

store iron laying flat on soleplate.

840091300 ENv01 9/24/01 4:33 PM Page 7

If you have a claim under this warranty, please call our Customer Service Number.

For faster service please have model, series, and type numbers ready for operator

to assist you. These numbers can be found on the heel rest of your iron.

MODEL: _______________ TYPE: ________________ SERIES: _________________

Customer Service

LIMITED WARRANTY

This product is warranted to be free from defects in material and workmanship for a period

of two (2) years for Hamilton Beach Portfolio products or one (1) year for Hamilton Beach

products from the date of original purchase, except as noted below. During this period, we

will repair or replace this product, at our option, at no cost. THE FOREGOING WARRANTY

IS IN LIEU OF ANY OTHER WARRANTY, WHETHER EXPRESS OR IMPLIED, WRITTEN

OR ORAL INCLUDING ANY WARRANTY OF MERCHANTABILITY OR FITNESS FOR A

PARTICULAR PURPOSE. ANY LIABILITY IS EXPRESSLY LIMITED TO AN AMOUNT

EQUAL TO THE PURCHASE PRICE PAID, AND ALL CLAIMS FOR SPECIAL, INCIDENTAL

AND CONSEQUENTIAL DAMAGES ARE HEREBY EXCLUDED. There is no warranty with

respect to the following, which may be supplied with this product: glass parts, glass

containers, cutter/strainer, blades, and/or agitators. This warranty extends only to the

original consumer purchaser and does not cover a defect resulting from abuse, misuse,

neglect, use for commercial purposes, or any use not in conformity with the printed

directions. This warranty gives you specific legal rights, and you may also have other legal

rights which vary from state to state, or province to province. Some states or provinces do

not allow limitations on implied warranties or special, incidental or consequential damages,

so the foregoing limitations may not apply to you.

If you have a claim under this warranty, DO NOT RETURN THE APPLIANCE TO THE

STORE! Please call our CUSTOMER SERVICE NUMBER. (For faster service please have

model, series, and type numbers ready for operator to assist you.)

CUSTOMER SERVICE NUMBERS

In the U.S. 1-800-851-8900

In Canada 1-800-267-2826

Web site address: www.hamiltonbeach.com

KEEP THESE NUMBERS FOR FUTURE REFERENCE!

Web site address: www.hamiltonbeach.com

HAMILTON BEACH PROCTOR-SILEX,INC.PROCTOR-SILEX CANADA,INC.

263 Yadkin Road

Southern Pines, North Carolina 28387

Picton, Ontario K0K 2T0

9/01

840091300

840091300 ENv01 9/24/01 4:33 PM Page 8

Fer à repasser

840091300

Précautions importantes.................. 2

Pièces et caractéristiques .............. 3

Utilisation du fer................................ 3

Caractéristiques facultatives .......... 5

Autonettoyage .................................. 6

Entretien ............................................ 6

Dépannage ........................................ 7

Service à la clientèle ........................ 8

Aux É.-U. : 1-800-851-8900

Au Canada : 1-800-267-2826

840091300 FRv01 9/24/01 4:33 PM Page 1

PRÉCAUTIONS IMPORTANTES

CONSERVER CES INSTRUCTIONS!

Lors de l’utilisation de votre fer à repasser, des précautions préliminaires de sécurité

doivent toujours être observées, y compris ce qui suit :

LIRE TOUTES LES INSTRUCTIONS AVANT L’UTILISATION

1. Utiliser le fer seulement pour sa fonction déterminée.

2. Pour protéger contre le risque de choc électrique, ne pas immerger le fer dans l’eau ou

autres liquides.

3. Le fer doit toujours être éteint (réglé à ARRÊT) avant d’être branché sur une prise de

courant ou débranché. Ne jamais tirer le cordon pour le débrancher de la prise de

courant; saisir plutôt la fiche et la tirer pour la débrancher.

4. Ne pas laisser le cordon toucher les surfaces chaudes. Laisser le fer se refroidir

complètement avant de le remiser, et enrouler sans le serrer le cordon autour du fer.

5. Toujours débrancher le fer d’une prise de courant électrique lorsqu’on le remplit d’eau

ou lorsqu’on le vide, ou s’il n’est pas utilisé.

6. Ne pas faire fonctionner le fer avec un cordon endommagé ou si le fer a été échappé

ou endommagé. Pour éviter le risque de choc électrique, ne pas démonter le fer.

Téléphoner au numéro du service à la clientèle sans frais d’interurbain pour des

renseignements concernant l'examen, la réparation ou l'ajustement électrique ou

mécanique. Un réassemblage incorrect peut causer un risque de choc électrique lorsque

le fer est utilisé.

7. Une bonne surveillance est nécessaire pour tout appareil utilisé par des enfants ou près

d’eux. Ne pas laisser le fer sans surveillance pendant qu’il est branché ou pendant qu’il

est sur une planche à repasser.

8. Des brûlures peuvent survenir lorsqu’on touche des pièces chaudes en métal, de l’eau

chaude ou de la vapeur. Adopter des précautions lorsqu’on tourne un fer à vapeur à

l’envers, car il peut rester de l’eau dans le réservoir.

INSTRUCTIONS SPÉCIALES

1. Pour éviter de surcharger un circuit, ne pas faire fonctionner un autre appareil à haute

tension sur le même circuit.

2. Si une rallonge est absolument nécessaire, un cordon de 10 ampères doit être employé.

Des cordons évalués pour un ampérage moindre peuvent surchauffer. Il faut prendre

soin de placer le cordon de rallonge pour qu’il ne puisse pas être tiré par des enfants ou

faire trébucher.

Ce produit est conçu uniquement pour

l’usage domestique.

Cet appareil est muni d’une fiche polarisée.

Ce type de fiche présente une broche plus

large que l’autre. La fiche ne peut être intro-

duite dans une prise que dans un sens. Il

s’agit d’une caractéristique de sécurité

visant à réduire le risque de choc électrique.

Si la fiche ne peut pas être insérée dans la

prise, la tourner dans l’autre sens. Si elle ne

peut toujours pas être insérée dans la prise,

contacter un électricien qualifié pour qu’il

remplace la prise désuète. Ne pas essayer

de contourner l’objectif de sécurité de la

fiche polarisée en la modifiant de quelque

manière que ce soit.

Utiliser le fer sur une planche à repasser.

Le repassage sur toute autre surface peut

endommager cette surface.

Ne pas repasser ni tenter un vaporisage

vertical des vêtements sur une personne.

Ne pas utiliser le vaporisage vertical en

direction de gens ou d'animaux de

compagnie.

Renseignements de sécurité aux consommateurs

840091300 FRv01 9/24/01 4:33 PM Page 2

Ce manuel convient aux modèles suivants

Table des matières

Langues :

Autres manuels Hamilton Beach Fer

Hamilton Beach

Hamilton Beach 14671 Manuel du propriétaire

Hamilton Beach

Hamilton Beach 840154800 Manuel utilisateur

Hamilton Beach

Hamilton Beach 14885C Manuel utilisateur

Hamilton Beach

Hamilton Beach 14565 - Lightweight Iron Manuel du propriétaire

Hamilton Beach

Hamilton Beach 14600 Manuel de programmation

Hamilton Beach

Hamilton Beach Proctor Silex Manuel du propriétaire

Hamilton Beach

Hamilton Beach 14690 Manuel du propriétaire

Hamilton Beach

Hamilton Beach 14525 Manuel utilisateur

Hamilton Beach

Hamilton Beach ProCare HB268SGBG Manuel utilisateur

Hamilton Beach

Hamilton Beach HIR700-CE Manuel utilisateur

Hamilton Beach

Hamilton Beach 14875 Manuel du propriétaire

Hamilton Beach

Hamilton Beach 14880C Manuel utilisateur

Hamilton Beach

Hamilton Beach 14505 Manuel du propriétaire

Hamilton Beach

Hamilton Beach 10092 Manuel du propriétaire

Hamilton Beach

Hamilton Beach 14978 Manuel du propriétaire

Hamilton Beach

Hamilton Beach 14515R Manuel utilisateur

Hamilton Beach

Hamilton Beach 840101300 Manuel utilisateur

Hamilton Beach

Hamilton Beach HIR200R Manuel utilisateur

Hamilton Beach

Hamilton Beach Pro SteamMax HB608WB Manuel utilisateur

Hamilton Beach

Hamilton Beach 840127400 Manuel utilisateur

Hamilton Beach

Hamilton Beach 14975 - Professional Iron Manuel utilisateur

Hamilton Beach

Hamilton Beach 14X60 - Expression Ergonomic Handle Iron Manuel utilisateur

Hamilton Beach

Hamilton Beach 840124900 Manuel utilisateur

Hamilton Beach

Hamilton Beach 14200 - Nonstick Auto-Off Retro Steam Iron Manuel utilisateur

Manuels Fer populaires d'autres marques

Clatronic

Clatronic DB 3703 Manuel utilisateur

TEFAL

TEFAL FV4093Z0 Manuel utilisateur

Gorenje

Gorenje SIH 2200 BS Manuel utilisateur

Philips

Philips GC6012 Manuel utilisateur

Bosch

Bosch 2 Series Manuel utilisateur

Riffel

Riffel Catena KB-819 Manuel utilisateur

Texi

Texi Hestia Manuel utilisateur

Maxwell

Maxwell MW-3010 Manuel utilisateur

TREVIDEA

TREVIDEA Girmi ST60 Manuel utilisateur

Philips

Philips HI5914/30 Manuel utilisateur

Primula

Primula Vapormat Manuel utilisateur

Magio

Magio MG-541 Manuel utilisateur

Scarlett

Scarlett SC-1334S Manuel utilisateur

Bosch

Bosch Sensixx B22L Manuel utilisateur

Philips

Philips GC651 Manuel utilisateur

Vitek

Vitek VT-1247 VT Manuel utilisateur

Cleanmaxx

Cleanmaxx 3397 Manuel utilisateur

Philips

Philips GC800 Manuel utilisateur
