Page 10 of 33 V1.1
1.1 Features
•User settable channel sizes (0.3 μm, 0.5 μm, 0.7 μm, 1.0 μm, 2.0 μm, 2.5 μm, 5
μm, 10 μm, and 15 μm)
•User adjustable start delay, sampling time, and sampling interval
•USB interface for data downloading (Software included)
•Audible Count Limit Warning: FED (Standard), ISO (Standard), and user defined.
•Error status indicator: The instrument will automatically monitor the sensor status
and battery charge status
•Over 5000 data points of storage capacity.
•Average of multiple times of measurements
•External digital temperature, relative humidity, and pressure to assure accurate
measurement
•Up to 260 unique location labels
•No less than 6 hours of continuous operation
•Bluetooth® (Wireless) printing capabilities
•Compatible with Window XP/7/8/10 operation systems
1.2 Specifications
•Size Range: 0.3 μm to 25 μm.
•Channel Sizes: All channel sizes configurable by user (Choose from 0.3 μm,
0.5 μm, 0.7 μm, 1.0 μm, 2.0 μm, 2.5 μm, 5 μm, 10 μm, 15 μm, 20 μm)
•Light Source: Laser diode (more than 100,000 hours MTBF)
•Coincidence Loss: <5% @ 70,000 particles/Litre
•Warm-up Time: < 1 minute for most accurate results
•Flow Rate: 2.83 Litre/min (0.1 cfm)
•Counting Efficiency: 50±20%@0.3μm; 100±10%@0.5μm
•Test Standard: JIS-B-9921 (1997), ASTM-F649-01, ASTM-F328-98 (NIST
traceable)
•Sampling Time: 1 sec to 59 minutes and 59 seconds (User adjustable)
•Number of Sampling Count: 1 to 999 (User adjustable)
