Haier HP200S1 Fiche technique

Heat pump Water Heater

Operation and Installation Manual

Model

HP200S1

HP300S1

Please read this manual carefully prior to

your use of this water heater.

The appearance of the water heater given

in this manual is for reference only.

English

ELECTRICITE

ELECTRICITE PERFORMANCE

Contents

1. Safety instructions ..................................................................................................................3

2. Instructions on transportation and storage...................................................................6

3. Functionings & principles .....................................................................................................6

4. Technical parameters .............................................................................................................7

5. Description of parts and components .............................................................................8

6. Installation introduction .... ................................................................................................11

7. Operation and functions ....................................................................................................24

8.Checking and maintenance ................................................................................................28

9.Faults and protection ............................................................................................................29

10.Product Fiche .........................................................................................................................30

Dear users of Haier,

Thank you for choosing Haier products.

Please read this manual carefully and follow the operation and safety instruction to ensure

best installation and utilization of the product.

Product safety statement:

1.The appliance is not to be used by persons (including

children) with reduced physical, sensory or mental capabilities,

or lack of experience and knowledge, unless they have been

given supervision or instruction. Children being supervised not

to play with the appliance. Cleaning and user maintenance

shall not be made by children without supervision.

2. Children shall be closely supervised to make sure they stay

away from this product.

3.The method of installing safety valve please refer to Page 19.

4.The water may drip from the discharge pipe of the pressure

relief device and this pipe must be left open to the

atmosphere.

5.The water heater is to be drained according to the

instructions specified on page 28.

English

11.Warranty certificate ............................................................................................................. 31

Safety instructions (to be followed at any time)

Failure to respect these instructions may lead to serious malfunctions of the

device and to risks for the user

Instructions with this warning mark shall be strictly followed during operation.

They relate to product and body safety of users.

Information provided with this banning mark relates to activities that are

deﬁnitely forbidden. Otherwise the machine may be damaged or users may

risk personal danger.

The water heater shall be

installed in strict accordance

with local wiring regulations,

and equipped with power

supply with a ground line.

Please ensure an eﬀective

ground connection.

It is recommended that the

water heater shall be installed

inside.

The water heater shall not be

installed at places where

water drainage is unavailable

or impossible.

While bathing, children must

be under guidance of an adult

person.

This water storage tank must

be equipped with a safety

valve. Its installation position

shall not be changed. To

guarantee safe operation, it

shall not be blocked at any

time.

Ground line and zero line of the

power supply shall not be

connected together. The

ground line shall not be

connected to pipeline

conveying gas or water,

lightning arresters or

telephone lines.

Interpretation of marks and symbols

English

The outlet water temperature

of a water heater is typically

higher than the temperature

indicated on the display. Hot

water shall not be pointed at

the human body immediately

after opening the hot water

valve to avoid injury caused by

hot water.

Hands or other items shall not

be put into the air grille to

avoid injury or damage to the

water heater.

Means for disconnection from

the main supply having a

contact separation in all poles

that provide full

disconnection under

overvoltage category III

conditions must be

incorporated in the ﬁxed

wiring in accordance with the

wiring rules.

If the power cord is damaged,

it shall be replaced by

qualiﬁed professionals to

avoid hazards.

Install the water heater in

strict accordance with the

installation instruction

speciﬁed on page 11-23.

Maintenance shall be carried

out according to the

instructions speciﬁed on

page 28.

Safety instructions (to be followed at any time)

English

Rotate the safety valve handle

once a month.The valve works

well if there is water flowing

out, otherwise check for

blocking and replace the safety

valve if necessary.

Refrigerant: R134a; When handling product, you should

- No smoking

- Prevent the accumulation of electrostatic charges

- Work in a well ventilated place.

- Avoid contact with the skin and eyes

- Do not inhale the vapours

- Evacuate the hazardous area

- Stop the leakage

Water heaters shall be

equipped with a dedicated

power line and residual

current circuit breakers. The

action current shall not exceed

30 mA;

Safety instructions (to be followed at any time)

The water drain pipe shall be in connection with the

atmosphere, it shall not be blocked; the water drain pipe

connected to a safety valve shall be installed in a frostless

environment with an continuous downwards inclination.

English

The appliance contains fluorinated greenhouse gases.

Chemical name of the gas: R134a

Fluorinated greenhouse gases are contained in hermetically

sealed equipment.

An electrical switchgear has a tested leakage rate of less

than 0.1 % per year as set out in the technical specification

of the manufacturer.

The quantity expressed in weight and in CO2 of fluorinated

greenhouse gases for which the appliance is designed, and

the global warming potential of those gases. (R134a, GWP

1430)

Instructions on transportation and storage

Functionings & principles

1. During transportation or storage, the heat pump water heater shall be packed in the

undamaged package to avoid damage to appearance and performance of the product;

2. During transportation or storage, the heat pump water heater shall be in the upright

position;

The external unit shall be kept in the upright position at any time for the best

performance !

A low-pressure liquid refrigerant is vaporized in the heat pump's evaporator and passed into

the compressor. As the pressure of the refrigerant increases,so does its temperature.The

heated refrigerant runs through a condenser coil within the storage tank,transferring heat

to the water stored there.As the refrigerant delivers its heat to the water, it cools and

condenses,and then passes through an expansion valve where the pressure is reduced and

the cycle starts over.

English

Technical parameters

Model (system)HP200S1 HP300S1

Tank volume 195L 293L

Rated voltage/ frequency 230V/50Hz 230V/50Hz

Tank rated pressure 0.85MPa 0.85MPa

Corrosion protection Magnesium rod(x2) Magnesium rod(x2)

Water proof grade IPX4 IPX4

Water inlet and outlet connection G3/4"F G3/4"F

Safety valve connection G3/4"F G3/4"F

Drain & Water intlet connection G3/4"F G3/4"F

Product dimension（tank unit）

544*512*1765 mm 632*600*1795 mm

Packing dimension（tank unit）

676*636*1927 mm 737*696*1958 mm

Packing dimension （external unit）

960*425*735 mm 960*425*735 mm

Net/Gross weight（tank unit）77/89kg 98/112kg

* Tested by LCIE France according to CDC LCIE N° 103-15/B:2011 +A1:2013 and EN16147:2011.

Model (tank unit)

Dimension and connections

English

Product dimension（external unit）

Net/Gross weight（external unit）

899*352*681 mm 899*352*681 mm

41/44kg 44/48kg

Model (external unit)

TS200HE-S1 TS300HE-S1

UE1.0-S1 UE1.5-S1

Power input by electric backup 2150W 2150W

Rated power input by heat pump 665W 885W

Maximum power input by heat pump 1000W 1350W

Maximum power input 3150W 3500W

Type of extraction Exterior Exterior

Coefficient of performance (COP) * 3.09 3.20

Tapping cycle L XL

Max volume of usable hot water at 40

℃

setting at 55

℃

245.1L 382.6L

Performance certified at 7 ° C air (CDC LCIE 103-15 / B)

Standby power input/ Pes 28W 29W

Heating up time 4h03 4h45

Reference temperature /Tref 53.86

℃

53.91

℃

Assembled System

Default temperature setting 55

℃

Temperature setting range- with heater 35

℃

-75

℃

-75

℃

20m 20m

Max working pressure of refrigerant 0.8/2.8MPa 0.8/2.8MPa

Refrigerant type / weight R134a/1.3kg R134a/1.5kg

Sound power level 64dB 64dB

Ambient temperature for use of product -7~45

℃

-7~45

℃

Operating temperature of heat pump -7~45

℃

-7~45

℃

Maximum length of refrigerant pipe

Description of parts and components

Safety

valve

Refrigerant

outlet

Cold water

inlet

Hot water

outlet

Heat pump structure

HP200S1/HP300S1

BOOST

SET

ACT

START

STOP

VAC

ERROR

ECO ECO+

AUTO



HP HC

TIMER

SET

BOOST

MODE

Drain outlet

Refrigerant

inlet

Electrical cover

-up

Electrical cover

Air grille

Electrical cover

-down

English

Description of parts and components

English

Exploded view（tank unit）

Accessories（tank unit）

Part

name Tank The strap

of tank

Fiber

washer

Instruction

manual

Expansion

bolts

Quantity 12

Plastic cover

Electrical cover - down

Display panel

5Electrical cover - up

Anode Rod

Heating element

Bottom Cover

Top cover

Tank case

Handle

S/N Description

Interconnection cable (3*1.5mm2)

Anode Rod

Flange

Tank temperature sensor

Display panel signal wire

Description of parts and components

Exploded view（external unit）

1 Air grille

2 Front cover

3 Evaporator

4Fan

5 Bottom Cover

6 Four-way valve

S/N Description

457

910 11

Electrical cover

8Expansion valve

9 Controller panel

10 Top Cover

11 Right Cover

Compressor

S/N Description

Accessories（external unit）

Part

name External

unit Elbow

Drain pipe for

condensate water

Protective

ring

Expansion

bolts

Quantity 14

Rubber

pad

English

Autres manuels pour HP200S1

Ce manuel convient aux modèles suivants

Table des matières

Langues :

Autres manuels Haier Chauffe-eau

Haier

Haier ES50H-CK1(MEA) Manuel utilisateur

Haier

Haier Little Sea-ox FCD-JTSA50-III Manuel utilisateur

Haier

Haier HP200M3 Fiche technique

Haier

Haier ES10V-M1 Manuel utilisateur

Haier

Haier ES8VQ1 (R) Manuel

Haier

Haier FCD-JTHA40-III, FCD-JTHA50-III,... Manuel utilisateur

Haier

Haier HP200M3 Fiche technique

Haier

Haier ES8V-Q1(EU) Manuel utilisateur

Haier

Haier FCD-6.6 Manuel utilisateur

Haier

Haier Little Sea-ox FCD-JTHC40-III (E) Manuel utilisateur

Haier

Haier Sea Elephant PJF2-150W Manuel utilisateur

Haier

Haier FCD-JTHMG100-III Instructions de montage

Haier

Haier S110ENF Manuel utilisateur

Haier

Haier ES10V-M1 Manuel utilisateur

Haier

Haier Little Sea-ox FCD-30 Manuel

Haier

Haier ES30V-A3 Manuel utilisateur

Haier

Haier FCD-JTHC100A-III (E) Manuel utilisateur

Haier

Haier ES15V-P1 Manuel utilisateur

Haier

Haier ES8V-Q1(EU) Manuel utilisateur

Haier

Haier ES6VQ2 (R) Manuel utilisateur

Haier

Haier EI39G1M(W) Manuel utilisateur

Haier

Haier ES25HH1 (R) Manuel utilisateur

Haier

Haier FCD-JTHA30-III Manuel utilisateur

Haier

Haier ES100V-G1 Manuel utilisateur

Manuels Chauffe-eau populaires d'autres marques

Kenmore

Kenmore 153.582400 Manuel utilisateur

Applimo

Applimo Edel AIR Manuel utilisateur

STIEBEL ELTRON

STIEBEL ELTRON Eltronom SHU 5 S Manuel utilisateur

clage

clage E-Mini Series Manuel utilisateur

Toyotomi

Toyotomi Oil Miser OM-180 Manuel utilisateur

Bradford White

Bradford White EF Series Manuel utilisateur

Eccotemp

Eccotemp 40-H Manuel utilisateur

Dimplex

Dimplex ECSd125-580 Mode d’emploi

Dux

Dux 32FCR6N Manuel utilisateur

Toyotomi

Toyotomi Oil Miser OM-148 (Type D) Guide de dépannage

Noritz

Noritz N-132M Manuel d'instructions

TESY

TESY GCV7/4S 10047 Fiche technique

A.O. Smith

A.O. Smith Gphe 50 Manuel utilisateur

Koryo

Koryo KWHZF15Y Manuel utilisateur

Pentair

Pentair PSC-14-4-02 Manuel utilisateur

GE 40M06AAG Instructions de montage

Thermor

Thermor AEROMAX SPLIT 2 Manuel utilisateur

American Hometec

American Hometec AHQ-B03X Manuel utilisateur
