Haier DWE-270 Manuel utilisateur

Twin-tub Washing Machine

Names of the parts.............the 2nd cover

Safety precautions ...............................1

Installation and adjustment ..................3

Introduction of the major functions .......5

Preparation before washing ................6

The musts in washing .........................7

Usage of the detergent .......................8

Washing sequence ..............................9

Disposal after washing .......................13

Contents

Before using

Using process

Please read this manual carefully before using.

Retain it for reference

Please check if the power receptable is earthed

reliably before usage to guarantee your safety.

The manufacturer is not responsible for any

risks occurred owing to disobey these

stipulations.

User's manual

Trouble-shooting*

Answers to question.....................15

Specification*...........the back cover

Packing list ......................................16

Contents marked with that symbol are related to the safety of

the product and the personal safety of the users. Please operate

in strict conformity to the contents.

Contents marked with that symbol are prohibited, otherwise it

may do harm to the washing machine or the personal security

of the operator.

Accessories

Meaning and description of the symbols

Water inlet hose

Gland

(1 piece )

Before Using

Names of the parts

Buzzer

Water-filling entrance

Water inlet selector handle

Water selector

Wash timer

Control panel

Overflow filter

Water level adjusting lever

Drain hose hanging hole

Lint filter(Installed bu user)

Valve cover

Pulsator

Wash tub

Drain hose

Outer cover of the spin tub

Inner cover of the spin tub

Spin timer

Spin tub frame

Spin tub

Cabinet

Power cord

Warning sign

Prohibition sign

Lint filter

(1 piece )

Base frame

Wash tub cover

Before Using

Safety precautions

If the power cord is bad, to avoid risk it is required to replace it by the technicians

of our special shop or the after-sale service department. Keep the pin of the power

plug clean.

Ventilation hole at

the bottom of the

washing machine

Do not use water hotter than 50 C .

Do not share one receptacle with other

electric appliances. Do not use it in

case that the power plug is damaged

or the inserting into the receptacle is

loose.

Earth

Do not wash water-proof laundries such

as the raincoat, bicycle shelter etc. To

avoid abnormal vibration during spinning.

If the power cord is bad, to avoid risk it is required to replace it by the technicians

of our special shop or the after-sale service department. Keep the pin of the power

plug clean.

Earth the earthing terminal of the

receptacle reliably.

Do not put the machine at damp place

like the bathroom . Never wash it with

water.

In case the washing machine is installed

on ground with carpet , do not block the

ventilation hole with carpet.

When the machine is normally using, please

put the power plug at the location easily to

be inserted and extracted by hand. Be sure

to pull the plug off when the machine is idle

or when cleaning the machine.

Before Using

Do not stretch hands into the working

machine. It is dangerous even if the

rotation is slow. Take special care of

the children.

Handicapped or children without care

shall not use the machine.

Do not put any hot or heavy items

( such as the kettle with hot water )

on the washing machine.

Do not decompose, repair or alter the

machine by yourself.

Keep the machine away from direct

sunlight and heat source like the

heater.

Do not wash laundries with volatile

materials (such as thinner, petrol etc.).

Petrol

Thinner

Safety precautions

To prevent your laundries and washing

machine from damage,be sure to take out

all of the foreign materials from your pocket,

such as coins,buttons,sand or hair pins etc.

Before washing,please check if the water

tap is open,and if the water inlet pipe is

connected properly.

It is suggested to use low-foaming washing

powder.

Please install and adjust the machine according to the requirement of the manual.

It is very important to your security and correct operating the machine.

Usage of the drain hose

The drainage shall be smooth with the drain hose.

Before Using

Installation and adjustment

Install the water inlet hose; Select the water level

(about 46L)

High High

(about 55L)

Low Low

(about 36L)

Medium Medium

Adjust the water level adjusting

lever to desired water level line.

Water inlet hose

Water-filling

entrance

Water level

adjusting lever

4.If extra drain hose is needed , the inner

diameter of the extra hose shall not less

than 30mm, and the length shall not exceed

1.5m.

<10cm

> 30mm

<1.5m

1.The height of the drain hose shall be

less than 10cm , or the drainage will

not be smooth enough and cause

incomplete drainage.

2.Do not step on or press the drain hose.

3 If the drain hose is too long, cut it at mid

point. To make smooth drainage, cut the

front end of the hose slantingly.

Insert the water inlet hose into the water-filling

entrance on the control panel directly. (pull it

out to dismantle it)

Select water level according to the

quantity of the laundries.

Attention:

In water filling, do not exceed

the"High" water level. Otherwise

the water may overflow out of the

washing machine.

Lint filter

Filter frame

After opening the package,please take out the lint filter from

the document bag,install it to the filter frame of the

cabinet.See to the figure.

Install the lint filter

Before Using

How to change the direction of the drain hoses

Figure 1 indicates the ex factory

installation position of the drain

hose.

Then hang the drain hose into the hanging

hole at the spin tub side. (As per Figure 5).

Extend the drain hose from the side of spin tub.

Extend the drain hose from the rear side

Take out the drain hose from the fixing

hook. Extend it from the rear side (When

the drain hose is extended from the rear

side, it can be hung on the point for drain

hose at the two sides of the cabinet.)

(See to Figure 6).

Take off the drain hose from the hanging

hole of the cabinet. Pull the drain hose

fixing hook outwards gently to take out

the drain hose from the two fixing hooks.

(As per Figure 2)

Rotate the drain hose fixing hook for 90

to take it out from the installation hole

(As per Figure 3).

Install the two drain hose

fixing hooks taken out into

the installation hole at the

other side of the base frame

(to aim at the installation

hole accurately you can

lean the washing machine

forward slightly).Then rotate

for 90 (As per Figure 4).

Pull the fixing hook outwards slightly.

Inlay the drain hose into the fixing hooks

reliably along the groove at spin tub side,

and make it extend towards spin tub side.

Figure 6

Figure 5

Figure 4

Figure 2

Figure 1

Figure 3

Drain hose

fixing hook

Drain hose

fixing hook

Pull outwards

slightly

Side sectional view

Fixing hook

installation hole

Drain hose

Take off

the drain hose

Rotate the fixing

hook for 90 Rotate the fixing

hook for 90

Insert the fixing hook into the

installation hole upwards

Take off the fixing

hook downwards

to fix it

Using process

Introduction of the major function

The machine has good comprehensive performance, and nice appearance.

It adopts streamline appearance and full plastic shell, which will never get rust.

For the design on safety and reliability, it adopts the wash shelf and water reception

groove design, and reduces the unfavorable influence on the electrical component by the

vapor. Therefore it guarantees more safe and reliable washing.

It adopts complete enclosed base frame and low-noise motor, and thus reduces the

working noise significantly. We can guarantee that the purchase of this machine will bring

you a clean world without disturbing your quiet life.

Pulsator

WASH TIMER

OFF

WASH

SOAK

Foam-removing spinning during high-efficiency rinsing

Bubble washing + soak washing

Use the foam-removing spinning to

remove the extra detergent liquid. It can

both shorten the washing time and save

the water consumption.

When the pulsator rotates, the machine will

inhale air and produce small bubble. The bubble

can explode and produce tiny water current to

help dissolving the detergent, and improve the

cleaning capability the detergent , therefore

raise the cleaning ratio.

When you need to wash dirty laundries , you

can select soak washing. Select different time

according to the soil level of the laundries.

Foam-removing

spinning

Remove most of the foam

extra detergent liquid. it can

both shorten the washing

time and save the water

consumption.

Remove the detergent

liquid remained

The effect is best when the

laundries quantity is below

80% of the rated value.

Spin

Spin for about

1~2 minutes Fill water for

about 1 minutes Spin for about

1~2 minutes

Confirm if

there's special

requirement for

the laundries.

Clear the pocket.

Take out the

coins , sand,

hairpins etc.

Fasten the

buttons and

zippers.

When the pulsator

is running , the

buttons of the

laundries may

cause noise. For

the sake of

discretion,please

put the laundries

with buttons into

other laundries.

Preparation before washing

1.Connect the water inlet hose.

2.Confirm that the washing machine is earthed

reliably . Then insert the power plug into the

receptacle. Do not connect the earth terminal

to the gas pipe and tap water pipe.

3.Put down the drain hose .

4.Slanting or uneven ground may result in

unstable working or abnormal noise. Please

make the machine stand horizontally.

The quantity of

the laundries

shall not exceed

the rated value.

The big laundries

like the jeans

shall be put in

loosely.

Using process

Preparation before washing

Pay attention to followings before washing the laundries

Reference weight of the laundries

Working suit up,down

Jeans about 800g

The capacity of washing and spinning of

the machine refer to the largest weight of

the standard laundries under dry condition

that can be washed or spinned in one time.

Laundries quantity in one washing cycle

shall be lower than the rated capacity.

The largest capacity of this machine is

7.0 kg.

The thickness ,size , type of the cloth will

influence the actual washing capacity. It

is suitable to put in reasonable amount of

laundries and the laundries can be turned

round in washing for one time washing.

Do not select " High " water level for

laundries less than 3.2kg, so as to avoid

splashing of water.

Blending coat

about 800g

Shirt Jacket

Single bed sheet

Socking

Underpants

Undershirt

Pajamas

Blanket

cotton,about 900g

cotton,about

300g

cotton,about

800g

cotton,about 600g

blending,about 50g

cotton,about 70g

cotton,about 180g

Using process

The musts in washing

cotton,about 1120g

Selection of the quantity of the washing powder list 1

Selection of the current , water level and washing time list 2

How to use the washing powder

How to use the whitener

Fill water to decided level. Dilute the whitener with container. Pour it slowly into the

washing tub.

Avoid using whitener on laundries with color or pattern as they are prone to lose color.

The whitener shall not touch the laundries directly.

Direct dissolved in the machine:

1.Fill small quantity of water.

2.Add the powder . Run for 30 seconds to

dissolve it completely.

3.Put it in the laundries. Select suitable

water level.

The instant dissolving of the washing powder:

1.Prepare warm water of 30 C and a container.

2.Add the powder while stirring to fully

dissolve it.

The powder is more prone to pollute the

laundries than the detergent. Therefore

please use it with proper quantity.

It is suggested not to use high sudsing

detergent.

Dosage of different washing powder is

different. Please refer to the instruction

of the washing powder for the detail

dosage.

Refer to the user's manual for the usage and quantity of the whitener.

For powder whitener, please dissolve it before using.

Laundries

quantity

Laundries

quantity

Water level

Current

Standard dosage

Concentrated washing

powder

Laundries

Common washing

powder

Washing time

(minutes)

Water quantity

About About

About3~6

About8~10

About10~13

About7~13

About2~4

About3~6

About8~10

About About

4.5kg~7.0kg

3.2kg~7.0kg

2.5kg~4.5kg

Below2.5kg

Below3.2kg

High (about55L)

Standard

Low (about36L)

Gentle

Medium (about46L)

46g

38g

30g

55g

46g

36g

Usage of the detergent Using process

Using process

Knitwear

Cotton,blending,linen

Very dirty and thick

Bed sheet

Silk(thin laundries)

Chemical fiber

Cotton,blending,linen

Table des matières

Autres manuels Haier Rondelle

Haier

Haier HW-C1260TVE-E Manuel utilisateur

Haier

Haier JW-K33F Manuel utilisateur

Haier

Haier HW80-BP12929 Manuel utilisateur

Haier

Haier HWM89VA Manuel utilisateur

Haier

Haier HWM108VA Manuel utilisateur

Haier

Haier HW-C1470TVE-U Manuel utilisateur

Haier

Haier HWF5000AW Instructions de montage

Haier

Haier XQJ100-96A Manuel utilisateur

Haier

Haier Thermocool HMS1000TVE Manuel utilisateur

Haier

Haier JW-MD1080A Manuel utilisateur

Haier

Haier HQM62-K Manuel utilisateur

Haier

Haier HWD80-BP14636S Manuel utilisateur

Haier

Haier HE600TX Manuel utilisateur

Haier

Haier XPB135-LA Manuel utilisateur

Haier

Haier JW-G50B Manuel utilisateur

Haier

Haier HW50-1010 Mode d’emploi

Haier

Haier XPB76-113 Series Manuel utilisateur

Haier

Haier HWM110-0713S Manuel utilisateur

Haier

Haier HWM1480KFL Manuel utilisateur

Haier

Haier XQB50-18 Manuel utilisateur

Haier

Haier GE PTW600BPR DG Series Comment utiliser

Haier

Haier HW60-1081 Manuel utilisateur

Haier

Haier HLP21E - Pulsator Wash With Tub Manuel utilisateur

Haier

Haier HWM65-113S Manuel utilisateur

Manuels Rondelle populaires d'autres marques

Tricity Bendix

Tricity Bendix AW 1000 W Guide produit

Panasonic

Panasonic NA-F60L5WRB Manuel utilisateur

GE WSLP1500 Manuel

Electrolux

Electrolux EWF1284EDW Manuel utilisateur

Bosch

Bosch WAN2829BSN Manuel utilisateur

LG TV2516DV3B Manuel utilisateur

LG TH2517DSAV Manuel utilisateur

VESTEL

VESTEL CMH-XL 7510 TE Manuel utilisateur

AEG

AEG 74335 Manuel d'utilisation

Johnson

Johnson JWF721A Manuel utilisateur

Beko

Beko WTE7604XLW0 Manuel utilisateur

Danby

Danby DTT100A1WDB Instructions de montage

Amica

Amica WA 14 Ex Manuel utilisateur

Daewoo

Daewoo DWD-F1222 Manuel utilisateur

Bosch

Bosch WAS28461AU Manuel utilisateur

Miele

Miele PW 6080 Vario Manuel utilisateur

Finlux

Finlux FLX108CF220 Manuel utilisateur

Whirlpool

Whirlpool 3LBR5132AN0 Manuel utilisateur
