User manual

Washer-dryer

HWD80-BP14636

HWD80-BP14636S

Thank You GB

Legend

Warning – Important Safety information

General information and tips

Environmental information

Thank you for purchasing a Haier Product.

Please read these instructions carefully before using this appliance. The instructions con-

tain important information which will help you get the best out of the appliance and ensure

safe and proper installation, use and maintenance.

Keep this manual in a convenient place so you can always refer to it for the safe and proper

use of the appliance.

If you sell the appliance, give it away, or leave it behind when you move house, make sure

you also pass this manual so that the new owner can become familiar with the appliance

and safety warnings.

WARNING!

Risk of injury or suocation!

Disconnect the appliance from the mains supply. Cut o the mains cable and dispose

of it. Remove the door catch to prevent children and pets to get closed in the appliance.

GB Content

1- Safety information..........................................................................................................................4

2- Productdescription ........................................................................................................................10

3- Control panel....................................................................................................................................11

4- Programmes ....................................................................................................................................15

5- Consumption...................................................................................................................................16

6- Daily use ............................................................................................................................................17

7- Eco-friendly use..............................................................................................................................22

8- Care and cleaning ...........................................................................................................................23

9- Troubleshooting..............................................................................................................................25

10- Installation......................................................................................................................................29

1- Safety information GB

ing safety hints:

Dimension (HxWxD in mm) 850x595x600

Voltage in V 230 V~ /50Hz

Current in A 10

Max power in W 1900

Water pressure in MPa

Netto weight in kg 72

Trade mark Haier

HWD80-BP14636

Maximum spin speed for standard 60°C cotton washing cycle1) in rpm 1400

Washing capacity for standard 60°C cotton washing cycle (without drying)

in kg 8

Drying capacity for standard “dry cotton” drying cycle 1) (kg) 5

1) Standard cotton programmes:

Washing: Cotton Eco

Drying: “Dry” + “5+5kg”

HWD80-BP14636S

0.03<P <1

GB 1- Safety information

WARNING!

This appliance is intended to be used in household and similar

applications such as:

▶

– staﬀkitchen areas in shops, oﬃces and other working environments;

– farm houses;

– by clients in hotels, motels and other residential type environments;

– bed and breakfast type environments;

– areas for communal use in blocks of ﬂats or in launderettes.

This appliance is not intended for use by persons (including children)

with reduced physical,sensory or mental capabilities, or lack of

experience and knowledge, unless they have been given supervision

or instruction concerning use of the appliance by a person responsible

for their safety.

Children should be supervised to ensure that they do not play with the

appliance.

▶

▶The appliance must not be supplied through an external switching

device, such as a timer, or connected to a circuit that is regularly

switched on and oﬀ by the utility.

▶Use only the supplied hose set for the connection

Never reuse old hose sets!

If the supply cord is damaged, it must be replaced by the manufacturer,

its service agent or similarly qualiﬁed persons in order to avoid a hazard.

▶

1- Safety information GB

WARNING!

Before rst use

▶Make sure there is no transport damage.

▶Make sure all transport bolts are removed.

▶Remove all packaging and keep out of children´s reach.

▶Handle the appliance always with at least two persons because it

is heavy.

Daily use

▶This appliance can be used by children aged from 8 years and

above and persons with reduced physical, sensory or mental ca-

pabilities or lack of experience and knowledge if they have been

given supervision or instruction concerning use of the appliance

in a safe way and understand the hazards involved.

▶Keep away children under 3 years of age from the appliance un-

less they are constantly supervised.

▶Children shall not play with the appliance.

▶Do not let children or pets come close to the appliance when the

door is open.

▶Store washing agents out of reach of children.

▶Pull up zips, x loose threads and take care for small items to pre-

vent laundry from being entangled. If necessary, use an appropri-

ate bag or net.

▶Do not touch or use the appliance when barefoot or with wet or

damp hands or feet.

▶Do not cover or encase the appliance during operation or after-

wards to allow any moisture or dampness to evaporate.

▶Do not place heavy objects or sources of heat or damp on top of

the appliance.

▶Do not use or store ﬂammable detergent, sprays, dry cleaning

agent or ﬂammable gas in close vicinity to the appliance.

▶Do not wash any garments treated with solvents in the appliance

without having dried them previously in the air.

GB 1- Safety information

WARNING!

Daily use

▶Do not remove or insert the plug in the presence of ﬂammable

gas

▶Do not hot wash foam rubber or sponge-like materials.

▶Do not wash any laundry which is polluted with ﬂour.

▶Do not open detergent drawer during any wash cycle.

▶Do not touch the door during the washing process, it gets hot.

▶Do not open the door if the water level is visibly over the porthole.

▶Do not force the door to open. The door is tted with a self-lock

device and will open shortly after the washing procedure is ended.

▶Switch o the appliance after each wash programme and before

undertaking any routine maintenance and disconnect the appli-

ance from the electrical supply to save electricity and for safety.

▶Hold the plug, not the cable, when unplugging the appliance.

▶Do make sure the room is dry and well ventilated. The ambient

temperature should be between 5 °C and 35 °C.

▶Do not cover any ventilation openings in the base by a carpet or

similar object.

▶Keep the area around the appliance free of dust and lint.

▶Do make sure that there is only laundry inside the appliance and

no pets or children before you use it.

▶Only dry textiles washed in water.

▶Do make sure not to load more than nominal load.

▶Remove all items such as lighters and matches from pockets.

▶Use fabric softeners or similar products as specied by the

manufacturer´s packaging.

▶Notice that the last part of the drying cycle occurs without heat

(cool down cycle) to ensure remaining the garments at a temper-

ature which does not damage them.

▶Do not leave the appliance unattended during run time for some

time. If a long absence is intended, the drying cycle have to be

interrupted by switching o the unit and unplugging the mains.

▶Do not switch o the appliance except drying cycle is nished,

unless all items are quickly removed and spread out that the heat

can be released.

1- Safety information GB

WARNING!

Daily use

▶Do not dry following items in the appliance:

▶Items which are unwashed.

▶Items which have been contaminated with inﬂammable sub-

stances such as cooking oil, acetone, alcohol, benzine, petrol,

kerosene, spot removers, turpentine, waxes, wax removers

or other chemicals. The fumes can cause a re or explosion.

These items must always be washed rst by hand in hot wa-

ter with an extra amount of detergent and then be dried in the

open air before drying in the appliance.

▶Items which contain padding or llings (e.g. pillows, jackets), as

the lling can get out with the risk of igniting in the dryer.

▶Items which contain a large proportion of rubber, foam rubber

(latex foam) or rubber like materials such as shower caps, wa-

terproof textiles, rubberised articles and items of clothing and

pillows with foam rubber lling.

▶Switch o the appliance after each drying programme to save

electricity and for safety.

Maintenance / cleaning

▶Make sure children are supervised if they carry out cleaning and

maintenance.

▶Disconnect the appliance from the electrical supply before un-

dertaking any routine maintenance.

▶Keep the lower part of the porthole clean and open door and de-

tergent drawer if appliance is not in use to prevent odours.

▶Do not use water spray or steam to clean the appliance.

▶Replace a damaged supply cord only by the manufacturer, its ser-

vice agent or similarly qualied persons in order to avoid a hazard.

▶Do not try to repair the appliance by yourself. In case of repair

please contact our customer service.

GB 1- Safety information

Installation

▶Ensure a location which allows opening the door fully. Do not in-

stall the tumble dryer behind a lockable door, a sliding door or a

door with hinges on the opposite side of the tumble dryer door as

this limits the full opening of the tumble dryer door.

▶The appliance should be placed in a well-ventilated place. Ensure

a location which allows opening the door fully.

▶Never install the appliance outdoors in a damp place, or in an area

which may be prone to water leaks such as under or near a sink

unit. In the event of a water leak cut power supply and allow the

machine to dry naturally.

▶Install or use the appliance only where the temperature is above 5 °C.

▶Do not place the appliance directly on a carpet, or close to a wall

or furniture.

▶Do not expose the appliance to any frost, heat or direct sunlight

or in the near of heat sources(e.g. stoves, heaters).

▶Make sure that the electrical information on the rating plate

agrees with the power supply. If it does not, contact an electri-

cian.

▶Do not use multi-plug adapters and extension cables.

▶Make sure only the delivered electric cable and hose set are used.

▶Make sure not to damage the electric cable and the plug. If dam-

aged have it replaced by an electrician.

▶ The appliance’s power cable is tted with 3-cord

plug that fts a standard 3-cord (grounded) socket.

Never cut o or dismount the third pin (grounding). After the ap-

pliance is installed, the plug should be accessible.

▶Make sure the hose joints and connections are rm and there is

no leakage.

Intended use

This appliance is intended for washing machine-washable laun-

dry only. Anytime follow the instructions given on the label of each

garment label. It is designed exclusively for domestic use inside the

house. It is not intended for commercial or industrial use.

Changes or modications to the device are not allowed. Unintended

use may cause hazards and loss of of all warranty and liability claims.

(grounding)

2- Product description GB

2.1 Picture of appliance

Front (Fig. 2-1): Rear side (Fig. 2-2):

2.2 Accessories

Check the accessories and literature in accordance with this list (Fig.:2-3): :

Inlet hose-

assembly 5 Blanking

plugs Drain hose

bracket User manual

botton cover

bord with felt

Note:

Temp.Speed Intense Delay Start/Pause

Extra rinse

HW80-BP14636

BLDC motor

+++

AutoweightCapacityEnergy

8kg

Self Clean

Temp.Speed Intense Delay Start/Pause

Extra rinse

+++

Energy Capacity

7kg

rpm

1400

HW70-BP14636

1000

Temp.Speed Intense Delay Start/Pause

5+5kg

Dry

capacity

Spinspeed

1400 8/5kg

HWD80-BP14636

Speed up

2-1

T1 T2

T3 S1

S2 S4

134

265

2-2

1 Detergent /Softener drawer

2 Display

3 Worktop

4 Programme selector

5 Service flap

6 Adjustable feet

1 Transportation bolts (T1-T4)

2 Back cover

3 Back cover screws (S1-S4)

4 Power cord

5 Water inlet valve

6 Drain hose

2-3

Ce manuel convient aux modèles suivants

Table des matières

Autres manuels Haier Laveuse-sécheuse

Haier

Haier HWD1000 - 1.7 cu. Ft. Washer/Dryer Combo Manuel utilisateur

Haier

Haier HWD60-1403D Manuel utilisateur

Haier

Haier HWD1600 Manuel utilisateur

Haier

Haier HFP1W Manuel utilisateur

Haier

Haier Tiana HW100-HB1297NZP Manuel utilisateur

Haier

Haier XQG50-11 Manuel utilisateur

Haier

Haier HWD80-B14979 Manuel utilisateur

Haier

Haier HWD80-B14979 Manuel utilisateur

Haier

Haier HWD160-B1558U1 Manuel utilisateur

Haier

Haier HWD1000 - 1.7 cu. Ft. Washer/Dryer Combo Manuel utilisateur

Haier

Haier HWD80-B14959U1 Manuel utilisateur

Haier

Haier WNA500T Guide de l'utilisateur

Haier

Haier XQG50-11 Manuel utilisateur

Haier

Haier HWD80-BP14636N Manuel utilisateur

Haier

Haier Tiana HW1007NZP Manuel utilisateur

Haier

Haier HWD1600BW Manuel utilisateur

Haier

Haier XQG6511SU - Front-Load Washer/Dryer Combo Manuel utilisateur

Haier

Haier HWD100-B14876U1 Manuel utilisateur

Haier

Haier HWD 1500 Manuel utilisateur

Haier

Haier HWD100-1297HS Manuel utilisateur

Haier

Haier HWD1600 Manuel utilisateur

Haier

Haier XQG50-AB1100CTX Manuel utilisateur

Haier

Haier WD9900A Manuel utilisateur

Haier

Haier HWD120-B1558 Manuel utilisateur

Manuels Laveuse-sécheuse populaires d'autres marques

Whirlpool

Whirlpool WFC8090GX Manuel utilisateur

Whirlpool

Whirlpool LTE5243DQ6 Manuel utilisateur

Bosch

Bosch XQG100-WDU285H00W Manuel utilisateur

montpellier

montpellier MWD7512S Manuel utilisateur

LG FHD0905 T Series Manuel utilisateur

Midea

Midea MF200D85B Manuel utilisateur

Maytag

Maytag MGT3800XW Manuel utilisateur

Siemens

Siemens WD15G440TR Fiche technique

Equator

Equator Clothes Processor EZ1500 Manuel utilisateur

Splendide

Splendide WDC7100XCP Manuel utilisateur

John Lewis

John Lewis JLWD 1408 Manuel utilisateur

Ariston

Ariston A1200WD Manuel utilisateur

Whirlpool

Whirlpool YLTE5243DQ5 Manuel utilisateur

Whirlpool

Whirlpool WFCR 75230 Guide d'installation

ATT

ATT Hammer Jet v1 Manuel utilisateur

AEG

AEG LAVAMAT 63742 VI Manuel utilisateur

Electrolux

Electrolux EWW8024P5WB Manuel utilisateur

GE GTD42EASJWH Manuel utilisateur
