MODEL:

LE42D10FM

LED TV RECEIVER

USER MANUAL

Please read this manual carefully before

using your television and keep this manual

in a good place for future reference.

Contents

Caution

Safety Information

Accessories

Technical Specification

Product Introduction

Front View

Rear View

OSD Menu

1. CHANNEL menu

2. PICTURE menu

3. SOUND menu

4. TIME menu

5. OPTION menu

Multimedia Operation

2-3

10-16

17-19

10-11

Hotel Mode 16

Connections

7-8

Remote Control

9Basic Operation

20Simple Troubleshooting

Caution

The exclamation point within an equilateral triangle is intend to alert the

user to the presence of important operating and maintenance (servicing)

instructions in the literature accompanying the appliance.

The lightening flash with arrowhead symbol, within an equilateral triangle

is intended to alert the user to the presence of un-insulated “dangerous

voltage” within the products enclosure that may be of sufficient magnitude

to constitute a risk of electric shock to the persons.

Correct disposal of this Product

(Waste Electrical & Electronic Equipment (WEEE)

Your product is designed and manufactured with high quality materials and

components which can be recycled and reused.

This symbol means that electrical and electronic equipment, at their end-

of-life should be disposed of separately from your household waste.

Please dispose of this equipment at your local community waste collection/

recycling center.

In the USA there are separate collection systems for used electrical and

electronic products. Please help us to conserve the environment we live in!

Safety information

Mains supply

This television is designed to operate from a 100-240 Volts 50Hz AC mains supply. Other power sources

may damage it. Check that the rating plate states 100-240V AC before you plug it in for the first time. The

Mains plug

We have fitted this television with a standard mains plug.

If for any reason you cut off the mains plug, please destroy the old plug as it would be dangerous if inserted

into a live power outlet. Carefully follow the wiring instructions supplied with the new plug.

fitted to the plug, remove the fuse before throwing the plug away.

The mains plug shall be the main disconnect device and shall be operable at all times.

Safe use and care of your television

We have designed and made this television to meet European safety standards, but as with any electronic

equipment you must take care to stay safe and get the best results. Here is some good advice to help you

do this.

Don’t continue to use your television if you have spilt liquids in it, if it is damaged in any way or if it does not

work normally. Immediately unplug the television and get expert advice.

Switch off mains power or pull out the power plug when you leave the television unattended, unless the function

of the television requires a continuous power supply.

Protect the screen from fingerprints.

Ventilation

Place the television on a hard flat surface away from direct sunlight and heat sources. If it is in a cabinet,

allow at least a 10cm gap all around. Don’t obstruct the ventilation slots, including those underneath, with soft

furnishings. Overheating will shorten the life of the television and increase the risk of fire.

Cleaning

Disconnect the mains supply and use only a lightly dampened soft cloth. Do not use chemical solvents or

strong detergents as these may damage the cabinet or screen.

Never allow water droplets to remain on the screen as moisture can cause permanent discolouration. Greasy

.sneercsDELrof

dednemmoceryllacificepsrenaelclaicremmocahtiwdevomerebylnotsumskram

Safety information

manufacturer accepts NO liability for damage or injury caused by using the product with the wrong mains

voltage.

Batteries

Remove batteries when the television is not to be used for a long time. Batteries left in equipment may cause

damage through deterioration and corrosive leakage, invalidating the guarantee. To protect the environment,

use local recycling facilities for battery disposal.

Protect the mains lead. You must ensure the mains lead cannot be walked on, crushed, chafed, cut,

trapped.

Avoid harsh conditions such as wet or damp places, high humidity, strong vibration, extremely high or low

temperatures, strong sunlight, places which are very dusty.

Never fit makeshift stands or legs to the television.

Never push objects into holes and ventilation slots.

Don’t touch the LED display as it gets warm when operating, this is normal and is not a fault.

To prevent electric shock, do not remove any cover.

.titakoolottnegaecivresdeifilauqateg,flesruoytixifdnayrtt’nod,gnorwseoggnihtynafI

To prevent injury this television must be securely attached to the wall or it’s supplied stand in accordance

with the installation instructions.

Pull the mains plug out of the wall socket and disconnect the aerial lead during thunderstorms.

Eye Fatigue

When using this product as a computer monitor, health and safety experts recommend short frequent

breaks

rather than occasional, longer breaks, for example a 5-10 minute break after an hour of continuous screen

work is likely to be better than a 15 minute break every 2 hours.

Do not use the monitor against a bright background or where sunlight or other bright light source will shine

directly on the screen.

CAUTION:

WARNINGS:

The apparatus shall not be exposed to dripping or splashing and that no objects filled with liquids, such as

vases, shall be placed on the apparatus.

flame sources, such as lighted candles, should be placed on the apparatus.

To prevent injury, this apparatus must be securely attached to the floor / wall in accordance with the installation

instructions.

The mains plug shall be the main disconnect device and shall be operable at all times.

This appliance is intended for domestic / household use only, and should not be used for any other purpose.

Any other use may invalidate the warranty and might be dangerous.

If the supply cord is damaged, it must be replaced by the manufacturer, its service agent or similarly qualified

persons in order to avoid a hazard.

Safety information

Accessories

Accessories & Technical Specification

- TV System

- Screen Size

- Resolution

- Aerial input

- Audio output power

- Power Consumption

Remote Control

Type

Control distance

Control angle

Batteries

Technical Specification

User’s Manual Remote control

PAL BG/DK/I SECAM BG/DK

42 inch (diagonal)

1920 x 1080

2x8W

100-240V 50/60Hz 180W

infrared

30 (horizontal)

2 x 1.5V, size AAA

Batteries

Converter cable

for YPBPR video

Converter cable

for AV

PICTURE SOUND SLEEP DISPLAY

SOURCE

VOL+

VOL-

EXIT

MUTE

CH+

CH-

123

456

789

AUTO

ASPECT

NICAM

TV/TXT HOLD

SIZE

INDEX

REVEAL

SUBPAGE

A-B

REPEAT

GOTO

ROOT

FAV FAV- FAV+

Product Introduction

Rear View

Remote Control window(keep clear)

LED indicator

(IR) Infrared Receiver: Receives IR signals from the remote control.

(Power on/Standby) LED indicator: Press to turn on and off.

The effective receiving range for the signal is 5-8 metres from the front of the remote

control window, and 30

to the left or right side and 20

above or below the control

window.

Indicator on(Red) Standby mode

Indicator on(Green) Power on mode

Front View

Connections

See next page

Display/exit the OSD menu.

Scan through channels.

Adjust the volume.

Display the input source menu.

Turn on/standby the TV set.

Product Introduction

AC Power cable- Connect to AC power supply

VOL

200mm

Connections

PC: Connect to the PC VGA output to display PC graphics

USB:Connect to USB device for multimedia

HDMI 1/2/3 IN: Connect to the HDMI socket of your DVD or Satellite Box.

PC audio: PC audio input

Video 1: Connect to the video output of external devices.

Mini YPbPr 2: Connect to the YPbPr output on external devices with the

converter cable.

YPbPr 1: Connect to the YPbPr output on external devices.

Mini AV 2: Connect to the Video & Audio output on external devices with

the converter cable. (Audio outputs are shared with YPbPr 2)

ANT IN: Connect to antenna or cable source.

COAXIAL: Output to audio amplifier

Headphone:Connect Headphone

(AUDIO)L/R IN 1: Audio signal input for AV. (Shared with YPbPr 1)

Connections

HDMI1 IN HDMI2 IN HDMI3 IN Y Pb Pr 1 PC

AUDIO VIDEO R-AUDIO-L 1 YPbPr2 AV2 ANT IN COAXIAL

mini mini

USB

PICTURE SOUND SLEEP DISPLAY

SOURCE

VOL+

VOL-

EXIT

MUTE

CH+

CH-

123

456

789

AUTO

ASPECT

NICAM

TV/TXT HOLD

SIZE

INDEX

REVEAL

SUBPAGE

A-B

REPEAT

GOTO

ROOT

FAV FAV- FAV+

Remote Control

The remote control is using Infra-Red(IR). Point it towards the front of the TV. The remote

control may not work correctly if it is operated out of range or out of angle.

: Auto adjust in the PC mode.

SOURCE : Source select.

POWER : Turn on/standby the TV

MUTE: Silence status

EXIT:Exit from the current menu

Cursor up/down keys in OSD menu

Cursor left/right keys in OSD menu

OK: Comfirm button

MENU : TV system menu

DISPLAY: Display playing status

PICTURE: Select the picture mode

AUTO

SOUND : Select the sound mode

SLEEP: Time shutting down

0-9,: Choose channel

: Go to program you latest program

CH+/-: Scan the channel.

VOL+/-:Volume up/down

Remote Control
