Haier 21F6D Manuel utilisateur

Digital Curtain

218 Preset Channel

Multiple Picture and Sound Mode

On/Off Timer

Child Lock

Soft Channel Change Function

Personalized Channel Timer Function

DVD Video Component Input Terminals

COLOR TV RECEIVER

OWNER'S MANUAL

21F6D-Slim

Please read this manual carefully before operating

the unit, and keep it for future reference.

MAIN FEATURES

CONTENTS

Warning and cautions....................................................................................1

Basic feature..................................................................................................2

Technical specification...................................................................................2

Preparing for operations................................................................................3

Function buttons and external sockets..........................................................4

AV connections.............................................................................................5

Remote controller guide................................................................................6

Power supply.................................................................................................7

Tuning procedure..........................................................................................7

Picture and audio adjustment function ........................................................11

Time function...............................................................................................14

Setting function ...........................................................................................17

Game...........................................................................................................22

Trouble shooting guide................................................................................23

WARNING AND CAUTIONS

1. When you clean the TV set, please

pull out the power plug from AC outlet.

Or may result in electric shock, fire or

damage to the TV set. Don't clean the

cabinet and the screen with benzene,

petrol and other chemicals.

4. Do not place the TV set near rain

or moisture as it may cause an electric

shock, or the TV set to catch fire. The

TV set must only be

Used in dry indoor

location.

2. In order to prolong the using life of

the TV set, please place it at a well

ventilated location.

5. The back cover must only be

removed by a registered electrical

service person. Removing the back

cover may result in electric shock, fire

or damage to

the TV set.

3. Don't place the TV

set in direct sunlight

or near heat source.

6. If the TV set is not going to be

used for a long time, or there is a

severe thunder & lightening storm, it

is recommended that the TV set be

disconnected from the AC.

Explanation on the display tube

When the picture tube requires cleaning, please disconnect the power and use

a dry soft cotton cloth. Do not use any cleaner or abrasive cloth.

BASIC FEATURE

TECHNICAL SPECIFICATION

Digital Curtain

218 Preset Channel

Multiple Picture and Sound Modes

On/Off Timer

Child Lock

Soft Channel Change Function

Count

Appointment

DVD Video Component Input Terminals

1.CRT: 21"

2.COLOUR SYSTEM: PAL NTSC3.58/4.43(AV)

3.AUDIO SYSTEM: BG

4.POWER SUPPLY: ~220V 50Hz

5.POWER SUPPLY VOLTAGE RANGE: ~160V -250V 50/60Hz

5.POWER CONSUMPTION: 80W

6.ANTENNA INPUT IMPEDANCE : 75

7.VIDEO INPUT: 1.0Vp-p( 75 )

8.VIDEO OUTPUT: 1.0Vp-p( 75 )

9.AUDIO INPUT: 400Vrms( 40k )

10.AUDIO OUTPUT: 400Vrms( 600k )

11.SOUND OUTPUT POWER: 10W+10W

Supplied accessories:

Infrared remote control handset 1

Battery(AA) 2

Owner s Manual 1

Design and specifications are subject to change without notice.

Antenna connection

Connect an antenna to the antenna socket on

the TV set, we recommend using a Cable TV

system for better picture and audio quality.

1.If you use a coaxial cable(75 ),insert the

antenna plug (see figure C) into 75 socket

(see figure A).

2.If you use a twin-lead cable(300 ),please

shape the cable as figure D, and connect the

leads to antenna adapter and then insert the

antenna adapter into the 75 socket (see

figure B).

Power source wire connection

Insert the power plug into AC outlet.

Install and replace batteries of the

remote control unit:

1.Place the remote control unit with the face

down, then open the battery cover of the

unit.

2.Place the two"AA"size batteries, matching

the + and - signs on each battery to the +

and -signs of the battery compartment.

3.Close the cover of the battery compartment.

NOTE:

(1)Don't drop or wet or dismantle the unit.

(2)If you don't intend to use the unit for a

long period or the electricity of the

batteries is used up, remove the batteries

to prevent batteries acid from leaking

into the battery compartment.

(3)Replace the two old batteries at the

same time.

(4)Don't use charge battery (Ni-cd )and

don't mix battery type.

(5)Don't throw your batteries into a fire.

Dispose of your batteries in a required

place.

PREPARING FOR OPERATIONS

Figure A Figure B

Antenna cable

with a plug

Figure C Figure D

Antenna feeder

Antenna adapter

75-300¦¸

Coaxial cable(75 ) twin-lead cable(300 )

Antenna

(5)S-video input

(2)AV input socket

(1)DVD component input

(3)Audio/Video output socket

(4)Antenna socket

(1)Remote sensor: let the remote

controller aim here the set can

receive remote control signal.

(2)Power switch: press the button

to turn on the TV set . Press

the button again to turn off

the TV set.

(3)Power indicator: the indicator

lights in standby status ,the

indicator lights in sleep status.

The indicator glints when you

use remote controller.

(4)Menu button

(5)Program up/down button

(6)Volume up/down button

(7)TV/AV

1.Front Panel

FUNCTION BUTTONS AND EXTERNAL SOCKETS

2.Rear Panel and

Side Panel

(5)

(2)

(4)

Remote sensor

Power switch

Power indicator

MENU Volume down/up Program down/upTV/AV

(input select

(3)(1)

You can connect DVD VCD LD to the TV set to watch the high quality picture.

The connections are as follows:

AV CONNECTIONS

Direction of signal

white left audio

red C /right audio

blue C

green

video

yellow

DVD(with DVD component)

VCR (without S-VIDEO terminalL)

To audio out

VCR (with S-VIDEO terminal)

To s-videooutput

Toaudio output

To component out

To audioout

To video output

Note:

1.S-VIDEO terminal and VIDEO input terminal can not be used at the same

time.

2.Video2 in the menu is not useful.

REMOTE CONTROLLER GUIDE

Remote controller functions

Intelligent button:

The numeric button 1 has intelligent function,

press it for 6s, then the TV set will search and store

the program automatically.

TV/AV

DISP SYSTEM SCAN

S.STD

P.STD

LOCK

PRE BACK

CALENDAR

LIGHT

EXIT

MODE

TV and AV Exchange Button

To exchanger between TV and

other available video inputs

Mute Button

Press to conceal the sound of

programs.

Screen Display Button

System AdjustButton

Direct-digit Choosing Button

Directly select channel numbers

Lock Setting button

Menu Select/ Adjust Button

Use this button to adjust the menu,

the volume and the channels, as

well as to control the game.

Program Play-forward Button

Calendar

Game Background Select Button

Background Lamp Control Button

(The model no including)

Start/Restart Game Button

Game Exit Button

Program Play-backward Button

Sound Mode Select Button

Include THEATER, NEWS

MUSIC and PERSONAL modes.

Digit Select Button

Change the channel position

number between one digit, two-

digits andthree -digits.

Picture Mode Select Button

There are DYNAMIC, STANDARD,

MILD,MEMORY, PICTURE MUTE

andCOLOR MUTE six modes of

picture.

Program Scan Button

DC Standby Button

Sleep TimerButton

GAME

CH+

CH-

VOL+

VOL- MENU

I/II

Stereo Button

POWER SUPPLY

Power supply (switch on/off to set main power supply).

1.Press power switch button to switch on AC power supply. The red power

indicator will light.

2. Press the power switch button on the remote controller to enter normal

receiving condition when the TV set is in standby condition.

There are Auto-search, Semi-Auto search and

Fine tuning method.

Auto-search

1.Press [MENU] button to let TUNING menu display

on the screen, then press [-CH+] buttons to select

AUTO MEMORY.

2. Press [VOL+] button to make the AUTO

MEMORY mode work, the TV set will begin to

search programs from program number 0.

After the search is finished, program number

0 will display on the screen.

Note: During auto-search, if you want to stop

searching, press [VOL-] button.

TUNING PROCEDURE

ASM VL 0

STOP

TUNING

SELECT ADJUST

POSITION 01

BAND V L

SKIP OFF

SEARCH DOWN

MFT UP

AUTO MEMORY

49.87 MHZ

TUNING PROCEDURE

Press [MENU] button to let TUNING menu

display on the screen,

3.Press [-VOL+] buttons to start searching.

1.Press [-CH+] buttons or numeric button (0~9) to

select the channel number you need.

(For example: channel 1).

Then press [-CH+]

buttons to select SEARCH item.

[VOL+] button is to search the program from

low FC. [VOL-] button is to search the program

from high FC. Repeat above procedure until

you find the channel you need.

4.When you intend to memory another channel in

another position, press [-CH+] buttons to select

POSITION, and use [-VOL+] buttons to select a

number you need, then press [-CH+] buttons to

select SEARCH, and repeat forth procedure.

TUNING

SELECT ADJUST

POSITION 01

BAND V L

SKIP OFF

SEARCH DOWN

MFT UP

AUTO MEMORY

49.87 MHZ

TUNING

SELECT ADJUST

POSITION 01

BAND V L

SKIP OFF

SEARCH DOWN

MFT UP

AUTO MEMORY

49.87 MHZ

TUNING

SELECT ADJUST

POSITION 01

BAND V L

SKIP OFF

SEARCH DOWN

MFT UP

AUTO MEMORY

49.87 MHZ

Ce manuel convient aux modèles suivants

Table des matières

Autres manuels Haier Récepteur TV

Haier

Haier LET26C600F Manuel utilisateur

Haier

Haier 34F9K-P Manuel utilisateur

Haier

Haier WL19T1 Manuel utilisateur

Haier

Haier 21F7A Manuel utilisateur

Haier

Haier L22A11W Manuel utilisateur

Haier

Haier 21NT1 Manuel utilisateur

Haier

Haier L26A9-AK Manuel utilisateur

Haier

Haier 25FA18-T Manuel utilisateur

Haier

Haier 21FA18-T Manuel utilisateur

Haier

Haier D29FV6-A, D29FV6, D34FV6-A, D3 Manuel utilisateur

Haier

Haier L3D42D25N Manuel utilisateur

Haier

Haier LT19Z6 Manuel utilisateur

Haier

Haier LET19T1000H Manuel utilisateur

Haier

Haier 29F9K Manuel utilisateur

Haier

Haier D34FV6 Manuel utilisateur

Haier

Haier LET26C400HF Manuel utilisateur

Haier

Haier 21F3A Manuel utilisateur

Haier

Haier 21FA10-AM Manuel utilisateur

Haier

Haier LET32T1000HFM Manuel utilisateur

Haier

Haier L1920A-C Manuel utilisateur

Haier

Haier 51B3Y-N Manuel utilisateur

Haier

Haier LET19C400F Manuel utilisateur

Haier

Haier 51B3Y-N Manuel utilisateur

Haier

Haier LE46D10F Manuel utilisateur

Manuels Récepteur TV populaires d'autres marques

NEC

NEC PX-TUAN-01 Manuel utilisateur

Edision

Edision Piccollino Manuel utilisateur

Matsui

Matsui DTR1 Manuel utilisateur

Dyon

Dyon Raptor Manuel utilisateur

Strong

Strong SRT 2401 Mode d'emploi

TerraTec

TerraTec CINERGY DT USB XS DIVERSITY Manuel d'instructions

TechniSat

TechniSat DigiCom 1 Manuel utilisateur

Triax

Triax CR 317 Manuel utilisateur

DirecTV

DirecTV D10-300 Manuel utilisateur

Motorola

Motorola VIP2502W Manuel utilisateur

ActionTec

ActionTec WirelessTV Manuel utilisateur

Motorola

Motorola VIP1200 Series Manuel utilisateur

Xoro

Xoro HRT 1300 Manuel utilisateur

Motorola

Motorola DH6200 Manuel utilisateur

Manhattan

Manhattan Plaza DS-100 Manuel utilisateur

Micro Prose

Micro Prose MPI-500 Manuel utilisateur

TechniSat

TechniSat DIGIT ISIO S Manuel d'instructions

Rextor

Rextor 3488 Manuel utilisateur
