Haier ACMO3ARW Manuel utilisateur

English

SAFETY PRECAUTIONS

Read all of the instructions before using this appliance. When using this

appliance, always exercise basic safety precautions, including the following:

1) Use this appliance only for its intended purpose as described in this use and care

guide.

2) This refrigerator must be properly installed in accordance with the

installation instructions before it is used. See grounding instructions in the

installation section.

3) Never unplug your refrigerator by pulling on the power cord. Always grasp the

plug firmly and pull straight out from the outlet.

4) Repair or replace immediately, all electric service cords that have become frayed

or otherwise damaged. Do not use a cord that shows cracks or abrasion damage

along its length, the plug or the connector end.

5) Unplug your refrigerator before cleaning or before making any repairs.

Note: If for any reason this product requires service, we strongly

recommend that a certified technician performs the service.

6) Do not use any electrical device or any sharp instrument in defrosting your

refrigerator.

7) If your old refrigerator is not being used, we recommend that you remove the

doors. This will reduce the possibility of danger to children.

8) After your refrigerator is in operation, do not touch the cold surfaces in the

freezer compartment, particularly when hands are damp or wet. Skin may

adhere to these extremely cold surfaces.

9) This refrigerator should not be recessed or built-in an enclosed cabinet. It is

designed for freestanding installation only.

10) Do not operate your refrigerator in the presence of explosive fumes.

SAVE THESE INSTRUCTIONS for Future Use

DANGER

Risk of child entrapment. Before you throw away your old refrigerator or

freezer, take off the doors. Leave the shelves in place so that children may

not easily climb inside.

English English

English

Thank you for using our Haier product.

This easy-to-use manual will guide you

in getting the best use of your

refrigerator.

Remember to record the model and

serial number. They are on a label in the

refrigerator.

Model number

Serial number

Date of purchase

Staple your receipt to your manual.

You will need it to obtain warranty service.

English English

English

Table Of Contents PAGE

Safety Precautions ............................................................................................1

Parts And Features............................................................................................4

Unpacking Your Refrigerator..............................................................................5

Proper Air Circulation ......................................................................................5

Electrical Requirements......................................................................................5

Use of Extension Cords......................................................................................5

Install Limitations ..............................................................................................5

Door Alignment................................................................................................6

Refrigerator Features And Use........................................................................6-8

Adjusting Temperature Control ..........................................................................6

Defrosting Your Refrigerator ..............................................................................7

Normal Operating Sounds You May Hear..........................................................7

Proper Refrigerator Care and Cleaning..............................................................8

Power Interruptions ..........................................................................................8

Vacation and Moving Care................................................................................8

Troubleshooting ................................................................................................9

Warranty Information......................................................................................10

English English

English

Installing Your Refrigerator

Unpacking Your Refrigerator

1 Remove all packaging material. This includes the foam base and all

adhesive tape holding the refrigerator accessories inside and

outside.

2. Inspect and remove any remains of packing, tape or printed

materials before powering on the refrigerator.

Proper Air Circulation

• To assure your refrigerator works at the maximum efficiency it was

designed for, you should install it in a location where there is proper air

circulation, plumbing and electrical connections.

• The following are recommended clearances around the refrigerator:

Sides……………3/4" (19mm)

Top....................2" (50mm)

Back..................2" (50mm)

Electrical Requirement

• Make sure there is a suitable power outlet (115 volts, 15 amps outlet) with

proper grounding to power the refrigerator.

• Avoid the use of three plug adapters or cutting off the third grounding in

order to accommodate a two plug outlet. This is a dangerous practice

since it provides no effective grounding for the refrigerator and may result

in shock hazard.

Use of Extension Cords

• Avoid the use of an extension cord because of potential safety hazards

under certain conditions. If it is necessary to use an extension cord, use

only a 3-wire extension cord that has a 3-blade grounding plug and a 3-

slot outlet that will accept the plug. The marked rating of the extension

cord must be equal to or greater than the electrical rating of the appliance.

Install Limitations

• Do not install your refrigerator in any location not properly insulated or

heated e.g. garage etc. Your refrigerator was not designed to operate in

temperature settings below 55˚ Fahrenheit.

• Select a suitable location for the refrigerator on a hard even surface away

from direct sunlight or heat source e.g. radiators, baseboard heaters,

cooking appliances etc. Any floor unevenness should be corrected with the

leveling legs located at the bottom.

English English

English

Door Alignment

1. Remove the top hinge cover using a flat head screw driver. Gently lift from

the rear of the hinge and slide forward.

2. Loosen the top hinge screws using a phillips head screwdriver.

3. Adjust the door or put a spacer in between and then tighten the screws.

4. Replace the top hinge cover by aligning the rear of the cover with the rear

of the hinge. Press firmly on the front of the cover until it snaps in place.

fig.1

English English

English

Refrigerator Features and Uses

General Features

Adjustable Temperature Control

Your refrigerator will automatically maintain the temperature level you select. The

temperature control dial has 7 settings plus off. 1 is the warmest. 7 is the coldest.

Turning the dial to “0” stops cooling in the refrigeration section. At first, set the dial

to 4 and allow 24 hours to pass before adjusting the temperature to your needs.

Note:

If the refrigerator has been placed in a horizontal or tilted position for any

period of time wait 24 hours before plugging the unit in.

Interior Shelves

To remove or replace a full-width slide-out shelf: (see fig. #2)

1. Gently tilt the shelf up and slide

forward until the shelf has been completely removed.

2. To replace the shelf, gently slide the shelf back.

Reversing Interior Shelf:

1. When storing a 2-Liter bottle in the door, the

shelf should be installed with the indent side

facing out and on the left

2. When not storing a 2-liter bottle in the door, the

shelf should be installed with the indent side

facing in on the right side.

Defrosting Your Refrigerator

• For maximum energy efficiency, defrost freezer section whenever frost

accumulates to a thickness of 1/4" or more on freezer walls. Note that frost

tends to accumulate more during the summer months.

• To defrost, remove the food and ice cube tray from the freezer section. Make

sure the drip tray is under the freezer section and turn off the thermostat.

Defrosting may take a few hours.

• While defrosting, water will accumulate

in the

drip tray. The drip tray may also need

to be emptied during the defrost

process. Do not leave unattended. (see

Fig. 5)

fig. 5

drip tray

fig. 4

English English

English

• After defrosting, empty and wipe down

the drip tray, as well as the interior of

the refrigerator.

Normal Operating Sounds You May Hear

• Boiling water, gurgling sounds or slight vibrations that are the result of the

refrigerant circulating through the cooling coils.

• The thermostat control will click when it cycles on and off.

English English

English

Proper Refrigerator Care

and Cleaning

Warning:To avoid electric shock always unplug your refrigerator before cleaning.

Ignoring this warning may result in death or injury.

Caution:Before using cleaning products, always read and follow manufacturer’s

instructions and warnings to avoid personal injury or product damage.

General: • Prepare a cleaning solution of 3-4 tablespoons of baking soda mixed

with warm water. Use sponge or soft cloth, dampened with the

cleaning solution, to wipe down your refrigerator.

• Rinse with clean warm water and dry with a soft cloth.

• Do not use harsh chemicals, abrasives, ammonia, chlorine bleach,

concentrated detergents, solvents or metal scouring pads. Some of these

chemicals may dissolve, damage and/or discolor your refrigerator.

Door Gaskets:

• Clean door gaskets every three months according to general instructions.

Gaskets must be kept clean and pliable to assure a proper seal.

• Petroleum jelly applied lightly on the hinge side of gaskets will keep

the gasket pliable and assure a good seal.

Power Interruptions

• Occasionally there may be power interruptions due to thunderstorms or other

causes. Remove the power cord from AC outlet when a power outage occurs.

When power has been restored, replug power cord to AC outlet. If outage is

for a prolonged period, inspect and discard spoiled food in the refrigerator.

Clean inside the refrigerator before reusing.

Vacation and Moving Care

• For long vacations or absences, empty food from refrigerator, move the

temperature DIAL to the OFF position and clean the refrigerator and door

gaskets according to “General cleaning” section. Prop doors open, so air

may circulate inside. When moving, always move the refrigerator vertically.

Do not move with the unit lying down. Possible damage to the sealed system

could occur.
