Haier MS-2480EG(SS) Manuel utilisateur

Before Use

Features of the Product............1

Names of the Parts...................2

Safety Precautions...................3

Installation Environment...........5

Open the Package Carton *

Installation................................5

Usage

Instructions of the Control Panel

Functions..................................6

Usage.......................................7

Selection of the Cooking

Dishware.................................12

Cooking Tips...........................13

Maintenance * Repair

Maintenance * Repair.............14

Answers to Questions............15

After-sales Service............16

Household Microwave Oven

MS-2480EG(SS)

* Please read this manual carefully before use

* Please retain it for future use

* See to the physical sample for the appearance, colour pattern.

User’s Manual

Contents

Haier

THERMOCOOL

Features of the Product

● The door adopts unique anti-choke structure and integrated punch forming,

and thus effectively prevents the microwave from leaking.

● It is controlled by two-step interlock switch. The power will be switched off

automatically when the door is open, therefore it is much safer to use.

● It is produced with antiseptic materials, and can suppress the reproduction

of the bacteria effectively.

● The special function of the microwave oven can eliminate the germ in the

food quickly and completely.

★High-temperature roast

● It has two-step roast function, and can roast food quickly and high-efficiently.

● It has two-step “microwave + roast” combined roast function, and can

produce perfect roast food.

● The door shell and operation panel frame shell adopt imported high-quality

stainless steel materials, and will never get rust and change color. It has

modern appearance and superior quality, and thus becomes the best

choice for the household microwave oven.

★Safe to use

★Shining appearance

★Healthy and germicidal

glass rotary

tray

shell

operation

board

tray support

diagrammtic sketch for

the accessory installation

baking

mesh

cavity

door hook

door seal

door

mesh board

(heating pipe on board)

useful volume of the

cavity is 16 l

cavity

Names of the Parts

Please read the safety precautions carefully to guarantee safe and convenient

use of the microwave oven.

Danger Warning

No one except the professional technicians

are permitted to disassemble the microwave

oven, or it may result in electric shock.

Danger

Attention Electric

shock

hazard

Do not use metal rod to enter the interlock

switch hole on the front side of the cavity. It

may cause hazard.

interlock switch hole

dismantle

Danger

Do not use the microwave oven for purposes

other than for cooking food This appliance must be earthed

Do not cook eggs in their shells to avoid

bursting Remember to clear away excess grease

from the inside the cavity. Otherwise it may

cause smoke or fire during heating.

warning

Do not apply excess force to the door. It

may cause distortion of the door and result

in microwave leakage.

Do not use sealed containers. For those

foods with skin, please prick holes on the

skin.

warning

Safety Precautions

warning warning

safe and

reliable

Safety Precautions

Warning

warning warning

When roasting , the face of the door and

the top of the cabinet may become hot to

touch.

Do not use it with the cavity empty. It will

damage the microwave oven.

Do not use the product for any industrial and commercial purpose.

Do not use metallic dishware to cook with

microwave as it will cause internal arcing.

Allow the cavity to cool after long cooking

processes (i.e. Roasting etc) before

starting another cook cycle.

warning warning

1. If the door or door seals are damaged, the oven must not be operated until

it has been repaired by a competent person;

2. It is hazardous for anyone other than a competent person to carry out any

service or repair operation that involves the removal of a cover which gives

protection against exposure to microwave energy.

3. Liquids and other foods must be heated in sealed containers since they are

liable to explode.

4. Only allow children to use the oven without supervision when adequate

instructions have been given so that the child is able to use the oven in a

safe way and understands the hazards of improper use;

5. Only use utensils that are suitable for use in microwave ovens;

6. When heating food in plastic or paper containers, keep an eye on the oven

due to the possibility of igniton;

7. If smoke is observed, switch off or unplug the appliance and keep the door

closed in order to stifle any flames;

8. Microwave heating of beverages can result in delayed eruptive boiling,

therefore care must be taken when handing the container;

9. The contents of feeding bottles and baby food jars shall be stirred or shaken

and the temperature checked before consumption, in order to avoid burns;

10.Eggs in their shell and whole hard-boiled eggs should not be heated in

microwave ovens since they may explode, even after microwave heating

has ended.

Installation Environment

glass rotary tray

rotary tray support

Open the

carton user’s

manual

Open the Package Carton Installation

Ventilation space is required in installation

of the microwave oven. Do not install the microwave oven in

environment that is humid or with high

temperature.

attention

Install

Put the microwave oven levelly at the

position you choose. Keep good

ventilation.

Select independent special socket,

with current at least 10A. Be sure to

ground it reliable.

L>15cm

baking mesh

Haier

THERMOCOOL

Haier

THERMOCOOL

Functions

Usage

1. Push the “POWER LEVEL” button three times.

1. Cooking function

For instance

The microwave oven has five power levels,

which are able to meet your requirements for

different cooking functions.

Remarks:

1. This model uses a circulating display for power level selection i.e with each push, the

power level changes in following manner: P100-P70-P50-P30-P10, then P10-P100.

2. When the cooking time expires (the counting down time is 0:00), the buzzer will sound

four times to indicate that the cooking is finished.

3. The largest cooking time of this model is 99 minutes and 50 seconds.

To cook for 12 minutes and 30 seconds with medium power level.

P100 P70 P50 P30 P10

High

●

POWER LEVEL

10SEC

1MIN

START

Medium-high

Medium

Medium-low

Low

LED display

3. Push the “1MIN” button twice.

4. Push the “10SEC” button three times.

5. Push the “START” button.

LED display

●

10MIN

2. Push the “10MIN” button once. LED display

AUTO MENU

cooking With the AUTO MENU cooking function, you only need

set the type and weight of the food then start the oven

to do cooking, without setting the cooking time.

Menu types:

Cook

meat

1. Push the “AUTO MENU” button four times. LED display

●

Remarks:

1. TheAUTO MENU uses a circulating display, i.e.with each push, it will change in

following manner: A1-A2-A3-A4-A5-A6, then A6-A1.

2. The weight grade for one certain menu, the display is also circulating.

3. The weight grade offered by the AUTO MENU is only for reference.

4. Reference for the food with AUTO MENU cooking.

Auto

reheat

Heat

milk

A3 A4

Cook

fish

A5 A6

Cook

chicken

Cook

vegetable

Recipe Type Weight(g) reference

140

210

280

350

420

500

A1 Auto

turnover

A2 Heat

milk

100

200

300

100

200

300

400

500

600

Cook

meat

Cook

fish

Cook

chicken

100

200

300

350

400

450

100

200

300

350

400

450

100

200

400

500

600

800

AUTO MENU

WEIGHT

START

Usage

For instance

To cook 200g mutton with AUTO

MENU function.

2. Push the “WEIGHT” button twice.

3. Push the “START” button.

LED display

Recipe Type Weight(g) reference

Cook

vegetable
