Service Support System

CPN10XHJ Page 1 of 7

This document provide two levels of support; customer advice provides information that meant to be shared with the customer

explaining possible operation issues that may be creating problems. Service assistance provides solutions for the technician servicing

the product in the home. Also included are applicable primary and secondary parts recommendations. The primary part listed is

expected to be the solution in 80% of the repairs with that symptom. The idea of the document is to provide the technicians with

repair advice that can be used to improve the first time fix ratio as well as reduce “shotgun” troubleshooting.

Model #

CPN10XHJ

Modified Date

8/8/2012

Symptom Customer advice Repair Guidance Primary

Part

Description

Primary

Part #

Secondary

Part

Description

Secon

dary

Part #

Musty Smell

Verify the Exhaust kit is not

obstructed.

Verify the water tank is not full.

If mold or sediment is found in

the water tray it is best to

clean the tray completely.

1. Inspect the drain tube

and pan assembly for

signs of standing water

or mold.

2. Inspect the evaporator

and blower fan motors

and fan blades looking

signs of wear or

overheating.

3. Inspect the evaporator

coils for mold

Pan base AC-

0250-29 N/A N/A

Service Support System

CPN10XHJ Page 2 of 7

Unit ices over

Verify the air filter is clear

verify there is nothing

obstructing air flow on the

outside of the unit

1. Verify the air filter is

clear

2. Verify there is nothing

obstructing air flow on

the outside of the unit

3.Verify the fan motors

are working properly and

the fan blades are

attached securely to the

motors

4. Verify the thermostat

is cycling the unit on and

off properly.

5. Verify the unit is

properly charged with

refrigerant

WHEEL-

BLOWER

CONDENS

AC-

8000-30 N/A N/A

STOP is

shown on the

LCD display

This indicates the internal

water tank has filled with water

and needs to be drained.

Open the drain plug on the

back of the unit and allow the

unit to drain into a shallow

bowl.

1. Inspect the drain tube

and pan for signs of

blockage.

2. Verify the float moves

freely and is not stuck in

the up position

3. Inspect the wiring to

and from the float switch

COVER-

FLOAT AC-

2855-02 N/A N/A

Service Support System

CPN10XHJ Page 3 of 7

Poor cooling

Verify the thermostat is set for

a value ~ 10 degrees lower

than the room temperature

Verify the air filter is clear

Verify there is nothing

obstructing air flow on the

outside of the unit and the

exhaust kit is venting outdoors

Verify the unit is not frosted

over and the drain is working

properly

Verify the water tank is empty,

drain the tank if necessary

Verify the unit is the proper

size for the room being cooled.

1. Verify the fan motors

are working properly and

the fan blades are

attached securely to the

motors

2. Verify the thermostat

is cycling the unit on and

off properly.

3. Inspect the wiring to

the Control PCB.

4. Verify the unit is

properly charged with

refrigerant

WHEEL-

BLOWER

CONDENS

AC-

8000-30 N/A N/A

Cannot adjust

the

Temperature

(Temperature

buttons do not

work)

When using Dehumidify or

Fan Mode the temperature

adjustment button is disabled

Inspect the wiring from

the Display PCB to the

Control PCB

P.C.B.-

CONTROL

BOARD

AC-

5210-

139 N/A N/A

The Fan

speed cannot

be adjusted

When Dehumidify mode is

selected and the room

temperature is lower than 77

degrees the fan speed is fixed

at the low setting

1. Verify the fan motors

are working properly and

the fan blades are

attached securely to the

motors.

2. Inspect the wiring

from to and from the fan

motor.

P.C.B.-

CONTROL

BOARD

AC-

5210-

139

WHEEL-

BLOWER

CONDENS

AC-

8000-

Service Support System

CPN10XHJ Page 4 of 7

The set

temperature

only shows on

the display for

a moment

after

adjustment

(where

applicable)

This is normal operation, after

adjusting the temperature the

display reverts to the

temperature value in the room.

N/A N/A N/A N/A N/A

No cooling,

fans are

running

Verify the thermostat is set for

a value ~ 10 degrees lower

than the room temperature

Verify the air filter is clear

Verify there is nothing

obstructing air flow through the

exhaust kit

Verify the water tank is empty ,

drain the tank if necessary

1. Verify the thermostat

is cycling the unit on and

off properly.

2. Inspect the wiring to

the Control PCB.

3. Verify the unit is

properly charged with

refrigerant

P.C.B.-

CONTROL

BOARD

AC-

5210-

139 N/A N/A

No Cooling

Fans are NOT

running

Verify the thermostat is set for

a value ~ 10 degrees lower

than the room temperature

Verify the air filter is clear

Verify there is nothing

obstructing air flow through the

exhaust kit

Verify the water tank is empty ,

drain the tank if necessary

1. Inspect the wiring

from the Control PCB to

the evaporator fan motor

and condenser fan

motor.

2. Verify the continuity of

the Overload protector.

3. Verify the continuity of

the compressor

windings.

P.C.B.-

CONTROL

BOARD

AC-

5210-

139 Fan Motor AC-

4550-

309

Service Support System

CPN10XHJ Page 5 of 7

The Reset

button is

tripped.

The reset button has popped

out and in some models the

green indicator light is out)

Press and release the RESET

button (listen for the click) the

reset button will latch and on

some models the green light

will turn on to resume

operation.

1. Inspect the wiring

from the Control PCB to

the compressor,

evaporator fan motor

and condenser fan

motor.

2. Verify the continuity of

the Overload protector.

3. Verify the continuity of

the compressor windings

WHEEL-

BLOWER

CONDENS

AC-

8000-30 Fan Motor AC-

4550-

309

A Household

fuse has

blown, or a

circuit Breaker

has been

tripped

It is recommended that an AC

unit have its own circuit.

Be sure the time-delay fuse or

circuit breaker of the correct

capacity

Do not use an extension cord

with this or any other

appliance.

You are trying to restart the

air conditioner too soon after

turning off the air conditioner.

Wait at least 3 minutes after

turning off the air conditioner

before trying to restart the air

conditioner.

1. Inspect the wiring

from the Control PCB to

the compressor,

evaporator fan motor

and condenser fan

motor.

2. Verify the continuity of

the Overload protector.

3. Verify the continuity of

the compressor

windings.

WHEEL-

BLOWER

CONDENS

AC-

8000-30 Fan Motor AC-

4550-

309

Service Support System

CPN10XHJ Page 6 of 7

Air conditioner

seems to run

too much or

over cycle

The use of more efficient

components may cause the air

conditioner to run longer than

an older model, but the total

energy consumption will be

less.

Newer air conditioners do not

emit the “blast” of cold air you

may be accustomed to from

older air conditioners, but this

is not an indication of lesser

cooling capacity or efficiency.

A higher capacity air

conditioner may be required,

depending on the size of the

room being cooled.

1. Verify the thermostat

is cycling the unit on and

off properly.

2. Inspect the wiring to

the Control PCB.

3. Verify the unit is

properly charged with

refrigerant

P.C.B.-

CONTROL

BOARD

AC-

5210-

139 N/A N/A

Remote not

working

Verify the batteries are good

Verify nothing is blocking the

receiver

Verify there are no fluorescent

lights or other sources of RF

interference near the unit.

1. Inspect the wiring to

and from the Control

PCB

2. Inspect the remote

sensor for signs of poor

connection

P.C.B.-

CONTROL

BOARD

AC-

5210-

139 N/A N/A

Service Support System

CPN10XHJ Page 7 of 7

Common Accessory Parts

Part Name

Part Number

Part Name

Part Number

REMOTE

AC-5620-62

PLATE-solid

AC-5300-192

HOSE-Exhaust

AC-1830-07

PLATE - Half Width

AC-5300-170

COUPLING - Connector for Hose

AC-1945-04

Filter

AC-2800-106

GRILL-FAN HOUSING

AC-3150-90

CAP - Window Panel

AC-1350-09

PLATE w/hole

AC-5300-186

Disclaimer 1: Although the information and recommendations in this document are presented in good faith and believed to be correct, Haier

America Trading LLC makes no representations or warranties as to the completeness or accuracy of Information. Every effort is made to provide

information that is accurate. However, materials are subject to change at any time. Information is supplied upon the condition that the persons

receiving same will make their own determination as to its suitability for their purposes prior to use. In no event will Haier America Trading LLC

be responsible for damages of any nature whatsoever resulting from the use of or reliance upon Information or the product to which

Information refers.

Disclaimer 2: This material is published for informational purposes only and intended for use only by persons qualified for the specific tasks

shown. Qualified personnel are those who, based on their training and experience, are capable of identifying risks and avoiding possible hazards

when handling or servicing a product. Only qualified personnel should repair products powered by electricity. Any attempt to handle, service or

repair the product or products by anyone other than qualified personnel could result in serious injury or death. You agree that your use of and

dependence on this information is at your sole risk. This information is subject to change or update without notice. There are no warranties,

either expressed or implied, regarding the accuracy or completeness of this information.

Ce manuel convient aux modèles suivants

Autres manuels Haier Congélateur

Haier

Haier HUF138PB - 16.8 Cu ft Frost-Free Freezer Instructions de montage

Haier

Haier BD-203GAA Manuel utilisateur

Haier

Haier HCF148A Manuel utilisateur

Haier

Haier Thermocool BD-100E Manuel utilisateur

Haier

Haier HUF138EA Instructions de montage

Haier

Haier ESCM050EC - 5.0 Cu Ft Chest Freezer Manuel utilisateur

Haier

Haier BD-519H Manuel utilisateur

Haier

Haier HCF-368H-2 Manuel utilisateur

Haier

Haier BD-146G Manuel utilisateur

Haier

Haier HCE 221S Manuel utilisateur

Haier

Haier H2F-220WSAA Manuel utilisateur

Haier

Haier HBF-1303AA Manuel utilisateur

Haier

Haier SC-260 Manuel utilisateur

Haier

Haier HFZ-238 Series Instructions de montage

Haier

Haier HCM050EB Manuel utilisateur

Haier

Haier HWC-22BS Manuel utilisateur

Haier

Haier DW-86L628 Manuel utilisateur

Haier

Haier HCF228-1 Manuel utilisateur

Haier

Haier HSC-110 Manuel utilisateur

Haier

Haier HFC3501ACW Manuel utilisateur

Haier

Haier HDF-385H Manuel utilisateur

Haier

Haier HF-128AE Manuel utilisateur

Haier

Haier JF-NC145A Manuel utilisateur

Haier

Haier DW-86L288 Manuel utilisateur

Manuels Congélateur populaires d'autres marques

Siemens

Siemens GU..D SERIES Manuel utilisateur

Omcan

Omcan FR-CN-0155 Manuel utilisateur

Beko

Beko FNE290E24W Manuel utilisateur

Electrolux

Electrolux ARCTIS G 8 60 50-6I Manuel utilisateur

Electrolux

Electrolux EUF2042AOX Manuel utilisateur

Dometic

Dometic CoolFreeze CFX95DZ Manuel utilisateur

Electrolux

Electrolux EUF7000W1 Manuel utilisateur

Polar Electro

Polar Electro CT330 Manuel utilisateur

MPM

MPM MPM-145-SK Series Manuel utilisateur

SAF

SAF PRESTOTIG 200AC/DC Guide rapide

Zanussi

Zanussi ZFT11407WA Manuel utilisateur

AEG

AEG A63190GT Manuel utilisateur

AEG

AEG A81000TNW0 Manuel utilisateur

Matsui

Matsui MUC50S15E Manuel utilisateur

NEFF

NEFF G4344X8 Manuel utilisateur

Frigidaire

Frigidaire FV 1246 H Manuel utilisateur

Frigidaire

Frigidaire FFC13K1AW Manuel utilisateur

Electrolux

Electrolux EU 2400C Manuel utilisateur
