Haier HS-08CD12 Manuel utilisateur
Air ConditionerEdition:2006/02/07
OPERRATION
MODE indicator
It indicates the operation mode.
The operation mode indicator selected
by the remote controller will also be on
during AUTO mode.
Air Conditione
r
Edition:2006/02/07
4
Remote signal receiver
A beeping sound is generated when a
signal from remote controller is received.
ON/OFF button
TIMER indicator
It turns on during TIMER running.
HEALTH ANION indicator
It turns on during HEALTH running.
and press it again to stop
POWER indicator
It turns on during POWER working
Press it to start unit
Air Conditione
r
Edition:2006/02/07
Operation
Fan
Display
Used to select temp setting
Temp.Set
Timer
Used to set timer setting
HEALTH ANION
ON/OFF
Mode
Used to select operation mode
it again to stop
Press it to start unit and press
Used to select desired fan speed
Time display
signal to the unit
Lights up when sending a
Signal indicator
selected to timer ON/OFF
Temp.indicator
To show temp.setting selected
Operation mode indicator
Fan speed indicator
Timer indicator
To show time mode display
To show mode selected
To show Fan speed selected
To show the number of hour
Press it to start health oprtation
AUTO COOL DRY FAN
LOW
HI
AUTO
BLANK
TIMER ON
TIMER OFF
SLEEP
5
Air Conditione
r
Edition:2006/02/07
2.Select operation mode
Press FAN button. For each press, fan speed changes as
follows:
Press MODE button. For each press, operation mode
changes as follows:
Remote controller:
Remote controller:
Then Select COOL operation
Press TEMP. button
Every time the button is pressed, temp.setting
increase 1oC,if kept depressed, it will increase
rapidly
Every time the button is pressed, temp.setting
increase 1oC,if kept depressed, it will decrease
rapidly
Select a desired temperature.
3.Select temp.setting
5.Unit stop
To protect unit system, don`t restart until 3 minutes have elapsed
When FAN is set to AUTO, the air conditioner
automatically adjusts the fan speed according to room
temperature.
Press ON/OFF button, the unit stops.
1. Unit start
Press ON/OFF on the remote controller, unit starts.
Cool Operation
3
2
4
5
1
3
If the unit has been running under large humidity for a long time, dew might occur
at outlet grating
4.Fan speed selection
Cautions
Remote Controller
AUTO COOL DRY FAN
LOW
HI
AUTO
6
Air Conditione
r
Edition:2006/02/07
Auto mode
2
4
3
3
About Auto Operation
Under the mode of auto operation, air conditioner will
automatically select Cool or Heat operation according
to room temperature.
5.Unit stop
Press ON/OFF button, the unit stops.
1. Unit start
Press ON/OFF on the remote controller, unit starts.
2.Select operation mode
Press MODE button.For each press, operation mode
changes as follows:
Remote controller:
Then Select Auto operation
Press FAN button. For each press, fan speed changes as
follows:
Remote controller:
Press TEMP. button
Every time the button is pressed, temp.setting
increase 1 C,if kept depressed, it will increase
rapidly
Every time the button is pressed, temp.setting
increase 1 C,if kept depressed, it will decrease
rapidly
Select a desired temperature.
4.Fan speed selection
3.Select temp.setting
Air conditioner is running under displayed fan speed.
When FAN is set to AUTO, the air conditioner
automatically adjusts the fan speed according to room
temperature.
LOW
HI
AUTO
COOL DRY FAN
5
1
AUTO
In Auto mode, the unit will select operation mode automatically according to room temp.
Auto mode:Air conditioner automatically changes between COOL and DRY and from mode.
DRY mode.(more details in DRY operation).
Cautions
when below 22 C, in FAN mode, fan speed automatically changs according to operation mode.
In AUTO mode, no temp. figure is displayed
FAN mode:when air conditioner is only in FAN mode,temp.setting is invalid, fan speed can be set
as desired.
when room, temp. is over 26 C,in COOL mode; when room temp. is between 26 C and 22 C,in
Remote Controller
7
Air Conditione
r
Edition:2006/02/07
Timer operation
2
4
TIMER function is not available in SLEEP mode.
Cautions
Set clock correctly before starting TIMER operation.
1. After unit starts, select your desired operation mode
Operation mode will be displayed on LCD.
2. Timer mode selection
Press TIMER button to change TIMER mode. Every
time the button is pressed, display changes as follows:
Remote controller:
Then select your desired TIMER mode (TIMER ON or
TIMER OFF).
3.Time setting
Press HOUR button.
Every time the button is pressed, time setting
increases 1 min, if kept depressed, it will increase
rapidly.
Every time the button is pressed, time setting
decreases 1 min, if kept depressed, it will decrease
rapidly.
Time setting is available within 1-12Hrs.
Time displayed shows how many hours later unit
will start of stop
4.Cancel TIMER mode
Just press TIMER button several times until TIMER
mode disappears.
Remote Controller
1
3
3
BLANK
TIMER ON
TIMER OFF
SLEEP
8
Air Conditione
r
Edition:2006/02/07
Dry Mode
3
4
Air blown out will be very cold at relatively low room temp.
Cautions
Remote Controller
3
2.Select operation mode
Press MODE button.For each press, operation mode
changes as follows:
Remote controller:
Then Select DRY operation
5.Unit stop
Press ON/OFF button, the unit stops.
AUTO COOL DRY FAN
1. Unit start
Press ON/OFF on the remote controller, unit starts.
Press FAN button. For each press, fan speed changes as
Remote controller:
follows:
Press TEMP. button
Every time the button is pressed, temp.setting
increase 1 C,if kept depressed, it will increase
rapidly
Every time the button is pressed, temp.setting
Select a desired temperature.
increase 1 C,if kept depressed, it will decrease
4.Fan speed selection
rapidly
3.Select temp.setting
Air conditioner is running under displayed fan speed.
LOW
HI
AUTO
2
15
DRY mode: When room temp. is higher than set temp. unit will in COOL mode:
When room temp. drops to set temp. compressor runs intermittently ,fan motor
will be in low speed.
Unit will run intermittently in Dry mode with fan speed at "LOW",regardless of its setting.
9
Air Conditione
r
Edition:2006/02/07
Fan operation
3
Hints
Remote Controller
2
14
2.Select operation mode
Press MODE button.For each press, operation mode
changes as follows:
Remote controller:
AUTO COOL DRY FAN
1. Unit start
Press ON/OFF on the remote controller, unit starts.
Press FAN button. For each press, fan speed changes as
Remote controller:
follows:
3.Fan speed selection
LOW
HI
4.Unit stop
In FAN operation mode, the unit will not operate in
COOL mode but only in FAN mode ,AUTO is
flow if necessary
not available in FAN mode.And temp.setting is disabled.
In FAN mode,SLEEP operation is not available.
Then Select FAN operation
Press ON/OFF button, the unit stops.
Select desired fan speed. Change air
10
Air Conditione
r
Edition:2006/02/07
Health operation
3
4
Hints
Remote Controller
3
2
5
Then Select COOL operation
5.Unit stop
Press ON/OFF button, the unit stops.
1. Unit start
Press ON/OFF on the remote controller, unit starts.
When FAN is set to AUTO, the air conditioner
automatically adjusts the fan speed according to room
temperature.
Air conditioner is running under displayed fan speed
IN COOL mode, air will blow out after a short period
of the time due to cold-draft function.
2.Select operation mode
Press MODE button.For each press, operation mode
changes as follows:
Remote controller:
AUTO COOL DRY FAN
Press TEMP. button
Every time the button is pressed, temp.setting
increase 1 C,if kept depressed, it will increase
rapidly
Every time the button is pressed, temp.setting
Select a desired temperature.
increase 1 C,if kept depressed, it will decrease
rapidly
3.Select temp.setting
Press FAN button. For each press, fan speed changes as
Remote controller:
follows:
4.Fan speed selection
Air conditioner is running under displayed fan speed.
LOW
HI
AUTO
1
11
Air Conditione
r
Edition:2006/02/07
Sleep operation
2
Hints
Remote Controller
1
1. Start unit and confirm its operation mode
2. Select SLEEP function
Press TIMER button to change TIMER mode. Every
Select "SLEEP" function
time the button is pressed, display changes as follows:
Remote controller:
BLANK
TIMER ON
TIMER OFF
SLEEP
Before going to bed, you can simply press the
SLEEP button and unit will operate in SLEEP
mode and bring you a sound sleep.
Use of SLEEP function
After the unit starts, set the operation status,
then press SLEEP button before which the
clock must be adjusted and time being set.
1. In COOL,DRY mode
1 hours after SLEEP mode starts, temp.will
become 1OC higher than temp. setting. After
another 1 hours, temp. rises by 1OC further.
The unit will run for further 6 hours then stops.
Temp. is higher than temp.setting so that room
temperature won't be too Iow for your sleep.
If the wind speed is high or middle before
4.Set the wind speed change when sleeping
setting for the sleep, set for lowing the wind
speed after sleeping.
If it is low wind, no change.
2.In AUTO mode
The unit operates in corresponding sleep
3. In FAN mode
mode adapted to the automatically selected
It has no SLEEP function.
operation mode.
12
