Hafele 533.03.560 Manuel utilisateur
Hob / User Manual
EN
533.03.560
EN - 2
Icon Type Meaning
WARNING Serious injury or death risk
RISK OF ELECTRIC SHOCK Dangerous voltage risk
FIRE Fire risk
CAUTION Injury or property damage risk
IMPORTANT Operating the system correctly
Thank you for choosing this product.
This User Manual contains important safety information and instructions on the operation
and maintenance of your appliance.
Please take the time to read this User Manual before using your appliance and keep this
book for future reference.
CONTENTS
1.SAFETY INSTRUCTIONS ................................................................................................4
1.1. General Safety Warnings ..............................................................................................4
1.2. Installation Warnings .....................................................................................................6
1.3. During Use.....................................................................................................................7
1.4. During Cleaning and Maintenance ................................................................................7
2.INSTALLATION AND PREPARATION FOR USE ............................................................9
2.1. Instructions for the Installer ...........................................................................................9
2.2. Installation of the Hob....................................................................................................9
2.3. Electrical Connection and Safety................................................................................. 11
3.PRODUCT FEATURES...................................................................................................12
4.USE OF PRODUCT ........................................................................................................13
4.1. Hob Controls................................................................................................................13
5.CLEANING AND MAINTENANCE .................................................................................16
5.1. Cleaning ...................................................................................................................16
6.TROUBLESHOOTING&TRANSPORT...........................................................................18
6.1. Troubleshooting ...........................................................................................................18
6.2. Transport ...................................................................................................................18
7.TECHNICAL SPECIFICATIONS.....................................................................................19
7.1. Energy Fiche ...............................................................................................................19
EN - 4
1. SAFETY INSTRUCTIONS
• Carefully read all instructions before using your
appliance and keep them in a convenient place for
reference when necessary.
• This manual has been prepared for more than one
model therefore your appliance may not have some
of the features described within. For this reason, it
is important to pay particular attention to any figures
whilst reading the operating manual.
1.1. General Safety Warnings
• This appliance can be used by children aged from
8 years and above and by persons with reduced
physical, sensory or mental capabilities or lack
of experience and knowledge if they have been
given supervision or instruction concerning use of
the appliance in a safe way and understand the
hazards involved. Children should not play with the
appliance. Cleaning and user maintenance should
not be made by children without supervision.
WARNING: The appliance and its accessible parts
become hot during use. Care should be taken to avoid
touching heating elements. Keep children less than 8
years of age away unless they are continually
supervised.
WARNING: Unattended cooking on a hob with
fat or oil can be dangerous and may result in fire.
NEVER try to extinguish such a fire with water, but
switch off the appliance and cover the flame with a lid
or a fire blanket.
WARNING: Danger of fire: Do not store items
on the cooking surfaces.
WARNING: If the surface is cracked, switch off
the appliance to avoid the possibility of electric shock.
EN - 5
• For models which incorporate a hob lid, clean any
spillages off the lid before use and allow the cooker
to cool before closing the lid.
• Do not operate the appliance by means of an
external timer or separate remote-control system.
• Do not use harsh abrasive cleaners or scouring
pads to clean oven surfaces. They can scratch the
surfaces which may result in shattering of the door
glass or damage to surfaces.
• Do not use steam cleaners for cleaning the
appliance.
• Your appliance is produced in accordance with all
applicable local and international standards and
regulations.
• Maintenance and repair work should only be carried
out by authorised service technicians. Installation
and repair work that is carried out by unauthorised
technicians may be dangerous. Do not alter or
modify the specifications of the appliance in any
way. Inappropriate hob guards can cause accidents.
• Before connecting your appliance, make sure
that the local distribution conditions (nature of the
gas and gas pressure or electricity voltage and
frequency) and the specifications of the appliance
are compatible. The specifications for this appliance
are stated on the label.
CAUTION: This appliance is designed only for
cooking food and is intended for indoor domestic
household use only. It should not be used for any
other purpose or in any other application, such as for
non-domestic use, in a commercial environment or for
heating a room.
• All possible measures have been taken to ensure
your safety. Since the glass may break, care should
EN - 6
be taken when cleaning to avoid scratching. Avoid
hitting or knocking the glass with accessories.
• Make sure that the supply cord is not trapped or
damaged during installation. If the supply cord is
damaged, it must be replaced by the manufacturer,
its service agent or similarly qualified persons in
order to prevent a hazard.
1.2. Installation Warnings
• Do not operate the appliance before it is fully
installed.
• The appliance must be installed by an authorised
technician. The manufacturer is not responsible
for any damage that might be caused by defective
placement and installation by unauthorised people.
• When the appliance is unpacked, make sure that
it is has not been damaged during transportation.
In the case of a defect do not use the appliance
and contact a qualified service agent immediately.
The materials used for packaging (nylon, staplers,
Styrofoam, etc.) may be harmful to children and they
should be collected and removed immediately.
• Protect your appliance from the atmosphere. Do
not expose it to sun, rain, snow, dust or excessive
humidity.
• Materials around the appliance (i.e. cabinets) must
be able to withstand a minimum temperature of
100°C.
• The temperature of the bottom surface of the hob
may rise during operation, therefore a board must
be installed underneath the product.
EN - 7
1.3. During Use
• Do not put flammable or combustible materials in or
near the appliance while it is operating.
Do not leave the cooker unattended when
cooking with solid or liquid oils. They may catch fire
under extreme heating conditions. Never pour water
on to flames that are caused by oil, instead switch the
cooker off and cover the pan with its lid or a fire
blanket.
• Always position pans over the centre of the cooking
zone, and turn the handles to a safe position so they
cannot be knocked or grabbed.
• If the product will not be used for a long period of
time, turn the main control switch off.
• Make sure the appliance control knobs are always
in the “0” (stop) position when the appliance is not in
use.
1.4. During Cleaning and Maintenance
• Make sure that your appliance is turned off at
the mains before carrying out any cleaning or
maintenance operations.
• Do not remove the control knobs to clean the control
panel.
• To maintain the efficiency and safety of your
appliance, we recommend you always use original
spare parts and to call our authorised service agents
when needed.
EN - 8
CE Declaration of conformity
We declare that our products meet the
applicable European Directives, Decisions
and Regulations and the requirements listed
in the standards referenced.
This appliance has been designed to be used only
for home cooking. Any other use (such as heating a
room) is improper and dangerous.
The operating instructions apply to several models.
You may notice differences between these instructions
and your model.
EN - 9
2. INSTALLATION AND
PREPARATION FOR USE
WARNING : This appliance must be
installed by an authorised service
person or qualified technician, according to
the instructions in this guide and in
compliance with the current local
regulations.
• Incorrect installation may cause harm
and damage, for which the manufacturer
accepts no responsibility and the
warranty will not be valid.
• Prior to installation, ensure that the local
distribution conditions (electricity voltage
and frequency and/or nature of the gas
and gas pressure) and the adjustments
of the appliance are compatible. The
adjustment conditions for this appliance
are stated on the label.
• The laws, ordinances, directives and
standards in force in the country of use
are to be followed (safety regulations,
proper recycling in accordance with the
regulations, etc.).
2.1. Instructions for the Installer
General instructions
• After removing the packaging material
from the appliance and its accessories,
ensure that the appliance is not
damaged. If you suspect any damage,
do not use it and contact an authorised
service person or qualified technician
immediately.
• Make sure that there are no flammable
or combustible materials in the close
vicinity, such as curtains, oil, cloth etc.
which may catch fire.
• The worktop and furniture surrounding
the appliance must be made of
materials resistant to temperatures
above 100°C.
• If a cooker hood or cupboard is to be
installed above the appliance, the safety
distance between cooktop and any
cupboard/cooker hood should be as
shown below.
HOB
Minimum
42 cm Minimum
42 cm
Minimum
65 cm (with
hood)
Minimum 70
cm (without
hood)
• The appliance should not be installed
directly above a dishwasher, fridge,
freezer, washing machine or clothes
dryer.
• If the base of the appliance is accessible
by hand, a barrier made from a suitable
material must be fitted below the base
of the appliance, ensuring that there is
no access to the base of the appliance.
2.2. Installation of the Hob
The appliance is supplied with an
installation kit including adhesive sealing
material, fixing brackets and screws.
• Cut the aperture dimensions as
indicated in the figure. Locate the
aperture on the worktop so that, after
the hob is installed, the following
requirements are followed.
W (mm) 290 min. A (mm) 50
D (mm) 520 min. B (mm) 50
H (mm) 47.5 E (mm) 10
C1 (mm) 270 min. F (mm) 10
C2 (mm) 490
EN - 10
W
D
C2
A
B
C1
H
F
HOB
W
D
C2
A
B
C1
Separator
E
E
H
Separator
F
HOB
• Apply the supplied one-sided self-
adhesive sealing tape all the way
around the lower edge of the cooktop.
Do not stretch the tape.
Self-adhesive
sealing tape
Worktop mounting
bracket
• Screw the 4 worktop mounting brackets
on to the side walls of the appliance.
Table des matières
Autres manuels Hafele Plaque
Hafele
Hafele H05V2V2-F 3G Manuel utilisateur
Hafele
Hafele 539.07.261 Fiche technique
Hafele
Hafele HC-IF77A Manuel
Hafele
Hafele HC-I604D Manuel utilisateur
Hafele
Hafele H05V2V2-F Manuel utilisateur
Hafele
Hafele 533.03.543 Manuel utilisateur
Hafele
Hafele HC-M773A Manuel utilisateur
Hafele
Hafele PBZ4VI517FTB4SCO Manuel utilisateur
Hafele
Hafele J-series Guide de configuration rapide
Hafele
Hafele 533.03.511 Manuel utilisateur
