Haes ESENTO XL-RDU Mode d’emploi
Installation, Commissioning &
Operating Manual
FULLY FUNCTIONAL/PASSIVE LCD DISPLAY REPEATER
PANEL
Approved Document DOC00636 Issue 4.0
Software Version 4.0 & Above
REMOTE DISPLAY UNIT
IMPORTANT NOTE
PLEASE READ THIS MANUAL BEFORE HANDLING THE EQUIPMENT AND
OBSERVE ALL ADVICE GIVEN IN IT
THIS PARTICULARLY APPLIES TO THE PRECAUTIONS NECESSARY TO AVOID
E.S.D
The panel is safe to operate provided it has been installed in compliance with the manufacturer’s instructions
and used in accordance with this manual.
Hazardous voltages are present inside the panel—DO NOT open it unless you are qualied and authorised
to do so. There is no need to open the panel’s enclosure except to carry out commissioning, maintenance
and remedial work. This work must only be carried out by competent service personnel who are fully
conversant with the contents of the panel’s installation manual and have the necessary skills for maintaining
this equipment.
This re alarm system requires periodic checks as specied in BS 5839 Part 1 It is the responsibility of the
system user to ensure it is regularly serviced and maintained in good working order.
Disclaimer
No responsibility can be accepted by the manufacturer or distributors of this re alarm panel for any
misinterpretation of an instruction or guidance note or for the compliance of the system as a whole. The
manufacturer’s policy is one of continuous improvement and we reserve the right to make changes to
product specications at our discretion and without prior notice. E & O E.
IMPORTANT SAFETY NOTES
Haes Systems Ltd, Unit 3 Horton Industrial Park, West Drayton, UB7 8JD
Model Number
Esento, LCD display repeater panel XL-RDU
European Standard EN54-2 : 1997 + A1 : 2006
Control and indicating equipment for re detection and re alarm systems for buildings.
European Standard EN54-4 : 1997 + A1 : 2002 + A2 : 2006
Power supply equipment for re detection and re alarm systems for buildings.
ATTENTION
Esento-RDU Installation, Commissioning & Operating Manual Approved Document Ref: DOC00636 Issue 4.0
1
CONTENTS
Page
ABOUT THIS PANEL 2
PRODUCT OVERVIEW 2
CABINET DETAILS 3
MAIN PCB TERMINALS 4
TECHNICAL SPECIFICATION 5
INSTALLATION 6
SAFETY 6
ESD PRECAUTIONS 7
GENERAL 7
MOUNTING THE CABINET 7
SETUP & PROGRAMMING 8
REPEATER PANEL SETUP & PROGRAMMING 8
REPEATER PANEL ADDRESSING 8
SET NUMBER OF REPEATER PANELS (ON MAIN CONTROL PANEL) 9
CABLING 10
CHANGE COMMS MONITORING TYPE (ON MAIN CONTROL PANEL) 11
USER MENU 12
OPERATING 16
PANEL CONTROLS & INDICATIONS 16
ACTIVATE CONTROLS 17
DISABLE MODE 18
TEST MODE 19
CONFIG SOFTWARE 20
PC CONFIGURATION SOFTWARE 20
Esento-RDU Installation, Commissioning & Operating Manual Approved Document Ref: DOC00636 Issue 4.0
2
ABOUT THIS PANEL
PRODUCT OVERVIEW
The Esento, LCD Remote Display repeater panels have the same, easy to use, controls and indications as
the main control panels with the addition of a 4 line x 40 character, backlit LCD display.
The remote display units are fully functional with ‘Silence’, ‘Resound’ and ‘Reset’ controls, as well as
Disable and Test Mode functions. It is also possible to disable the controls for each or all repeater panels
to make them passive (indication only). Up to 8 repeater panels can be supported on a system.
Repeater panels are designed to be wired in a fault tolerant (fail safe) loop conguration, from comms A
to B and back to the main panel again. This enables repeater panels to still work if there is a break in the
cables.
If replacing an older system where the existing cabling cannot be congured in a loop as above, it is
possible to re-programme the control panel back to legacy RS485 circuit comms monitoring. This then
allows any topology of comms cabling to be utilised.
The main circuit board has 2, switch –ve, outputs which provide re and fault signals. Inputs are available
for use as PSU fault inputs. An input for a remote key-switch is also provided.
Controls are enabled via a 4 digit code entry. The user code can be changed in the programming settings.
An eight button keypad is used to control the system and allow access to the function options.
The remote display unit is housed in a robust sheet steel enclosure suitable for wall mounting. Cable entry
is via 20mm ‘knockouts’ located at the top and rear of the cabinet.
A nominal 28v dc supply is required to power the remote display units which can be obtained from the
control panel or remote power supply unit.
Quiesecent and alarm current details for standby battery calculations
Standby Current Alarm Current
XL-RDU remote display unit 60mA 89mA
Esento-RDU Installation, Commissioning & Operating Manual Approved Document Ref: DOC00636 Issue 4.0
3
ABOUT THIS PANEL
CABINET
305mm
300mm
204mm
200mm
30mm
42mm
Esento-RDU Installation, Commissioning & Operating Manual Approved Document Ref: DOC00636 Issue 4.0
4
ABOUT THIS PANEL
MAIN PCB TERMINALS
1 2 3 4 ENTER
RESOUND SILENCE RESET
1 2 3 4
ON
SET ADDRESS
1 2 4 8
FIRE OP
+-
FAULT OP PSU DATA
+-
28V IP
+-
COMS A
+-
COMS B
+-
KEY SW
IP 0V
RX TX USB
Relay
Coil
Relay
Coil
28V
Power
Supply
+
-
Power Supply Fault Inputs
Alternative PSU Data Inputs
PSU
RX
TX
USB
Port
RS485
Comms
A & B
Optional
Key Switch
Input
LCD
Contrast
Adjust
Esento-RDU Installation, Commissioning & Operating Manual Approved Document Ref: DOC00636 Issue 4.0
5
ABOUT THIS PANEL
General Specication
Enclosure Steel IP30. Epoxy powder coated Interpon Radon, silver grey
Cabling The use of re resistant screened cable, is recommended, FireBurn,
FP200 or equivalent. Minimum size 1mm2. Max cable length 1Km
Non re resistant cable can be used, BELDEN 9271 or BELDEN 9860.
Maximum cable length 1.2Km
Temperature range -5 deg C to +40 deg C max RH 95%
TECHNICAL SPECIFICATION
Inputs & Outputs
Terminal capacity 0.5mm2 to 2.5mm2solid or stranded wire.
FIRE OP +/- A 28v +ve & switched negative output which activates when a re is present on the
network. Current limited to 40mA.
FAULT OP +/- A 28v +ve & switched negative output which activates when a fault is present on the
network. Current limited to 40mA.
28v IP +/- The RDU requires a 28 volt DC supply input. This can be derived from a control
panel output or local battery charger / power supply unit. The repeater consumes
around 100mA in normal operation. When deriving from a control panel supply,
consideration should be given to battery standby times.
PSU DATA RX/TX These are normally congured as switch negative fault inputs to collect a fault signal
from a local power supply if tted. They can be programmed to accept data from a
compatible PCA12 type power supply unit.
USB USB type B connector for PC cong purposes. Max 5v dc
COMS A RS485 data comms output to next network panel or repeater. For long cable runs a
120R termination resistor is recommended.
COMS B RS485 data comms input from previous next network panel or repeater. For long
cable runs a 120R termination resistor is recommended.
KEY SW IP/0V A 0v and input provided for connection of an external keyswitch to enable the
controls. A keyswitch can be mounted in a separate box or a link can be tted to
leave controls permanently enabled. In the case of a lost password this input can still
enable the controls.
Esento-RDU Installation, Commissioning & Operating Manual Approved Document Ref: DOC00636 Issue 4.0
6
INSTALLATION
SAFETY
Suppliers of articles for use at work are required under section 6 of the Health and Safety at Work Act 1974
to ensure as reasonably as is practical that the article will be safe and without risk to health when properly
used. An article is not regarded as properly used if it is used “without regard to any relevant information or
advice” relating to its use made available by the supplier.
It is assumed that the system, of which this control panel is a part, has been designed by a competent re
alarm system designer in accordance with BS 5839 Part 1 and with regard to BS EN 54 parts 2 and 4 in
the case of control equipment and power supplies. Design drawings should be provided to clearly show
the position of any eld devices and ancillary equipment.
This product should be installed, commissioned and maintained by, or under the supervision of, competent
persons according to good engineering practice and,
(i) BS 7671 (IEE wiring regulations for electrical installations)
(ii) Codes of Practice
(iii) Statutory requirements
(iv) Any instructions specically advised by the manufacturer
According to the provisions of the Act you are therefore requested to take such steps as are necessary to
ensure that any appropriate information about this product is made available by you to anyone concerned
with its use.
This equipment is designed to be operated from 230V AC 50/60 Hz mains supplies and is of Class I
construction. As such it must be connected to a protective earthing conductor in the xed wiring of the
installation. Failure to ensure that all conductive accessible parts of this equipment are adequately bonded
to the protective earth will render the equipment unsafe.
This equipment must only be installed and maintained by a suitably skilled and technically
competent person.
THIS IS A PIECE OF CLASS 1 EQUIPMENT AND MUST BE EARTHED
These panels are designed to comply with the requirements of EN 54 part 2.
Installation of the panel should only be carried out by qualied personnel. The electronic components
within the panel can be damaged by static charge. Suitable precautions must be taken when handling
circuit boards. Never insert or remove boards or components, or connect cables, with the mains power
on or batteries connected.
Equipment Guarantee
This equipment is not guaranteed unless the complete system is installed and commissioned in accordance with the laid
down national standards by an approved and competent person or organisation.
This product has been manufactured in conformance with the requirements of all applicable EU Council
Directives
Esento-RDU Installation, Commissioning & Operating Manual Approved Document Ref: DOC00636 Issue 4.0
7
INSTALLATION
ESD PRECAUTION
GENERAL
MOUNTING THE CABINET
Electronic components are vulnerable to damage by Electrostatic Discharges (ESD). An ESD wrist strap,
suitably grounded, should be worn at all times when handling pcbs. These wrist straps are designed to
prevent the build up of static charges, not only within a persons body, but on many other materials.
ESD damage is not always evident immediately, faults can manifest themselves at anytime in the future.
All pcbs should be stored in static shielded bags (silvered) for safe keeping, when not mounted in the
control panel.
Care should be taken with regards to avoiding the close proximity of high voltage cables or areas likely
to induce electrical interference. Earth links should be maintained on all system cables and grounded in
the control panel. The detection and sounder circuit cabling is classed as extra low voltage and must be
segregated away from mains voltage.
• Any junction boxes used should be clearly labelled FIRE ALARM.
• Any ancillary devices, e.g. door retaining magnets, must be powered from a separate power source.
• Any coils or solenoids used in the system must be suppressed, to avoid damage to the control
equipment.
The site chosen for the location of the panel should be clean, dry and not subject to shock or vibration.
Damp, salt air or environments where water ingress or extremes of temperature may affect the panel must
be avoided. The temperature should be in the range -5° to +40°C, and the relative humidity should not
exceed 95%.
Before mounting the cabinet remove the main PCB.
Remove the 6 x M4 nuts & washers securing the PCB. The board can then be carefully lifted off it’s
mounting pillars.
Secure the cabinet to the wall using the four indented holes in the back box. Ensure the box is mounted
level and in a convenient location where it may be easily operated and serviced.
External cables should be glanded via preformed knockouts at the top and rear of the cabinet. Remove
any knockouts and ensure the cabinet is clear of swarf etc prior to retting the PCB. Always ensure that if
a knockout is removed, the hole is lled with a good quality cable gland. Any unused knockouts must be
securely blanked off.
Knockouts should be removed with a sharp tap at the
rim of the knockout using a at 6mm broad bladed
screwdriver.
Use of excessive force will damage the enclosure
around the knockout.
Esento-RDU Installation, Commissioning & Operating Manual Approved Document Ref: DOC00636 Issue 4.0
8
SETUP & PROGRAMMING
REPEATER PANEL SETUP & PROGRAMMING
Up to 8 repeater panels can be supported on a system. The remote display units are fully functional with
‘Silence’ ‘Resound’ and ‘Reset’ controls, as well as Disable and Test Mode functions. It is possible to
disable the controls of each or all repeater panels to make them passive.
Repeater Comms PCB
To run remote display units, a Comms PCB (TPCA05) must be tted to the main control panel.
The Comms PCB ts into the control panel on top of the main circuit board where the ribbon cable from
the display board is normally plugged.
To t the Comms PCB, power down the panel, un-plug the display board ribbon cable from the main circuit
board and plug the Comms PCB into the socket instead.
A socket is provided on the top of the Comms PCB to re-connect the display board ribbon cable.
In order to initialise the Comms PCB in the main control panel the Network/Repeater mode DIL switch,
located on the main circuit board, must be switched to the ON position. For the 16-32 zone size panel this
is switch No. 3. For the 2-12 zone size panels this is switch No. 7. If this has not been set correctly the
‘System Fault’ lamp will be illuminated.
See panel manual for further details of tting a TPCA05, Comms PCB.
Set Number of Repeater Panels
The control panel will need to be programmed for the number of repeater panels on the system. See over
page.
The number of repeater panels on the system is programmed at the main control panel with
Level 3 programming mode active (see panel manual for details of Level 3 programming
mode).
Addressing
Each remote display unit needs to have a seperate address. The addressing is done using the 4 DIL
switches located on the circuit board (labelled SET ADDRESS) using binary code values, see diagram
below.
The address should be set in sequence from 1 - 8, rst display unit = address 01, next unit = address 02
etc. The main control panel should always be address 00 (all switches off).
1 2 3 4
ON
ADD 01
1 2 3 4
ON
ADD 02
1 2 3 4
ON
ADD 03
1 2 3 4
ON
ADD 04
1 2 3 4
ON
ADD 05
1 2 3 4
ON
ADD 06
1 2 3 4
ON
ADD 07
1 2 3 4
ON
ADD 08
Table des matières
