GVM SD200D Manuel utilisateur

G V M-S D200D

Produc t introduc tion ------------------------------------------- Pa ge 1

Disc la ime rs -------------------------------------------------------- Pa ge 2

Use a nd preserva tion ------------------------------------------ Pa ge 2

Produc t pa ra me te r --------------------------------------------- Pa ge 3

Produc t struc ture a na lysis ------------------------------------ Pa ge 4

Insta lla tion me thod ----------------------------------------- Pa ge 5~7

De sc ription of produc t c ontrol ke ys ----------------------- Pa ge 8

Func tion introduc tion a nd instruc tion --------------- Pa ge 9~1 0

APP c ontrol ------------------------------------------------------ Pa ge 1 1

Simple fa ults a nd trouble shooting ----------------------- Pa ge 1 2

Prec a utions ------------------------------------------------------ Pa ge 1 2

Pa c king list ------------------------------------------------------- Pa ge 1 3

DAFTAR ISI

Welcome to ''GVM-SD200D”, this product is specially designed for senior

photography enthusiasts. The product is suitable for live streaming / outdoor /

studio photography, and also for YouTube video shooting.

PENGENALAN PRODUK

①

②

Stepless adjustable light brightness, dual color temperature3200k~5600. It

has a high color render index CRI 97+ COB lamp bead. It helps to restore

the color of objects and provides you with natural and vivid shooting eﬀects.

App intelligent control system, which can be controlled by your intelligent

mobile device.

③It has LCD display and a stable system, which supports 360 ° rotation and

can eﬀectively control light. It is also equipped with a standard lampshade.

After installation, it can avoid excess light and make the light more

concentrated. Custom control ﬁlls the light, allowing you to easily and

easily shoot the desired results.

We believe that once using our product correctly, you can make huge progress

when shooting. Before using the product, you are strongly recommended to

read the instructions below carefully.

The main features of the product are:

CATATAN PENTING

Before using this product, please read the instructions carefully and make sure to

use the product correctly. If you don’t obey the instructions and warnings, you

maybe cause harm to yourself and the people around or even damage the product

and other things around.

2. Once you use this product, you are deemed to have read the disclaimer and warning

carefully, understand and acknowledge all the terms and contents of this statement,

and promise to take full responsibility for the use of this product and possible

consequences.

3. The design and speciﬁcations are subject to change without notice.

Do not put the light in a highly humid, strong electromagnetic ﬁeld, direct

sunlight, high-temperature environment. If the light is not use for a long time,

please disconnect the power

Clean：Before cleaning,please unplug the power plug. And use wet cloth rather

than any detergent or soluble liquid, avoiding damaging the surface layer.

PERAWATAN

Repairing：If there is fault or performance degradation, do not unpack the

shell by yourself, avoiding damage to the machine and lose the right of

maintenance. When there is a fault, do not hesitate to contact us, and we will

do our best to deal with the problem.

Accessories：Please use the accessories provided by the manufacturer and

approved ones, in order to maximize the performance.

Guarantee：Do does not modify the product, or you will lose the right of

maintenance.

Power：Make sure the power is in the demanded range, not too high or too low.

Correctly load the battery, in order not the damage to the machine.

SPESIFIKASI PRODUK

Brand : GVM

Product model : GVM-SD200D

Product Name : Photography lights

Product Type : Photography Fill Light

Lamp beads quantity : COB*1

Color rendering index : ≥97

Color temperature : 3200K~5600K

Lumen : 35000lux/0.5m ; 10000lux/1m

Add standard lampshade:93000lux/0.5m ; 25000lux/1m

Light adjustment method : Stepless adjustment

Function / Feature : APP, master/slave mode control, High display,

LCD screen

Product Weight : 3.15KG

Product Size (mm) : 228x133x349

Power : 200W

Voltage : AC 100-240V

Power supply mode : DC input

Power supply : DC32V/7A

Cooling : Radiator & fan cooling

Product material : Aluminum alloy + plastic

Commodity origin : Huizhou, China

MODE

BRG

CCT

OFF

IN Compound knob

LCD screen Mode button

Switch on/oﬀ

Vents

Diﬀuser Mount

Light frame interface

U-shaped frame

COB lamp bead

Bowens Mount

Light frame interface

Snap

Angle ﬁﬁxing handle

Fixing handle for

lamp holder

BAGIAN PRODUK

DC interface

1The lamp can be installed and ﬁxed on the bracket by rotating the knob

clockwise, and unloaded by rotating in the counterclockwise direction.

CARA PEMASANGAN

Snap

2Insert the Bowens mount of the standard lampshade into the Bowens mount

of the light, and then turn it slightly clockwise.

3Push Bowens dismantling buckle back while rotate the Standard lampshade

counterclockwise to remove the Standard lampshade.

Adapter interface

MODE

BRG

CCT

OFF

Loosen the angle ﬁxing handle, adjust the angle of the spotlight that you

need, and then turn the angle ﬁxing handle tightly.

Connect the power cord to charge.

MO DE

B R G

C C T

OF F

CARA PENGGUNAAN TOMBOL

PADA PRODUK

Power input interface

Switch ON/OFF

LCD display: Can display data such as mode, brightness,

channel value, etc.

Compound knob: Press the knob button to switch the mode, rotate

the knob to adjust the lighting parameters

Mode button: switch the control mode.The modes include:

rotate, slave, master, APP
