GVision K15TX-C Manuel utilisateur

Operation Guide

15” TFT LCD Monitor

On Screen Display Control

1024 x 768 Max. Resolution

Video-in/Touch Screen Function

 Key Control / Indicator

 Connector

R0062130

Package Contents

Included with your LCD monitor are following items:

 15” TFT liquid crystal monitor

 D-sub 15 pin signal cable

 DVI 24 pin signal cable ( option)

 Power apdater 12V/3A

 AC power cable

 DC 24V-in cable ( option )

 Operation guide

 RS232/USB cable for touch screen function ( option )

Product Features

 High contrast color TFT LCD display support resolution up to XGA

1024x768. Compatible with IBM VGA, VESA, and Macintosh

standards.

 Power management system conforms to VESA DPMS standard.

 DC 24V-in power system.

 Support DDC1/2B for Plug & Play compatibility.

 Advanced OSD control for picture quality adjustment.

 Video-in function ( S and RCA ) interface

 Touch screen function.

 Water proof (front frame ) is IP54

Key Control / Indicator

1. Power LED This LED indicates different status when this unit

operates in different modes.

2. Power Switch Pressing this button turns the display system power on

or off.

3. Menu/Select ▲Pressing this button pops up the OSD menus on the

screen, and used to select (“Up” direction) the OSD control options on

the screen.

4. Menu/Select ▼Pressing this button pops up the OSD menus on the

screen, and used to select (“Down” direction) the OSD control options

on the screen.

5. +This button is used to adjust the increasing value of the selected

OSD control option.

6. −This button is used to adjust the decreasing value of the selected

OSD control option.

Connector

1. Touch This is for connecting the touch panel RS232 /USB connector.

2. Power Connector This is for connecting the power cable.

3. Signal Connector This can be connected with the D-sub 15 pin

signal connector.

4. Signal Connector This can be connected with the DVI 24 pin signal

connector.

5. Video in(S) This can be connected with the video-in S connector.

6. Video in(RCA) This can be connected with the video-in RCA

connector.

Adjusting with the OSD Control

To Display and Select the OSD Functions:

1. Pressing ▲, ▼, +,or -once pops up the OSD function main menu.

2. Pressing ▲or ▼a second time to select the different OSD control.

3. Pressing

+or -button changes the value of the selected OSD control

option.

OSD Control Function

 CONTRAST

 BRIGHTNESS

 AUTOTUNE

 H-POSITION

 V-POSITION

 LANGUAGE

 FREQUENCY

 PHASE

 RED/GREEN/BLUE

 COLOR TEMP.

 INPUT SELECT

 RECALL

Display Modes

Item Resolution Type H. Scan V. Scan Pol. Pixel

(KHz) (Hz) (MHz)

1 640X350 VGA 31.469 70.087 + / - 25.175

2 720X400 VGA 31.469 70.087 - / + 28.322

3 640X480 VGA 31.469 59.940 - / - 25.175

4 640X480 VESA72 37.861 72.809 - / - 31.500

5 640X480 VESA75 37.500 75.000 - / - 31.500

6 640x480 MAC 35.000 66.667 - / - 30.240

7 800X600 SVGA 35.156 56.250 + / + 36.000

8 800X600 SVGA 37.879 60.317 + / + 40.000

9 800X600 VESA72 48.077 72.188 + / + 50.000

10 800X600 VESA75 46.875 75.000 + / + 49.500

11 832X624 MAC 49.722 74.546 - / - 57.280

12 1024X768 VESA60 48.363 60.004 - / - 65.000

13 1024X768 VESA70 56.476 70.069 - / - 75.000

14 1024X768 VESA75 60.023 75.029 + / + 78.750

Specifications

Model W5TX / S5TX

LCD Display 15.0” TFT Active Matrix Panel

Display Size 304.1(H) x 228.1(V) mm

Pixel Pitch 0.297(H) x 0.297(V) mm

Max. Resolution XGA 1024 x 768

Contrast Ratio 300 : 1 (min.) / 400 : 1 (max.)

Brightness 200 Cd/m2(min.) / 250 Cd/m2(max.)

Response Time 25 ms (min.) / 55 ms (max.)

Display Color 16M

Viewing Angle +70o~ -70o(L/R), +70o~ -70o(U/D) (min.)

Input Signal Video R.G.B. Analog 0.7V peak-peak

Sync TTL Positive or Negative

Signal Connector Analog 15 Pin D-Sub

digital 24 Pin DVI ( option )

Video-in ( option ) RCA/S connector

Touch Panel (option ) Resistive / Capacitive Type with RS232 or USB connector

Power Adapter Input :AC 100 ~ 240 V ; Output: DC 12 V, 3A

DC-DC Input: DC 18V~36 V ; Output: DC 12 V, 3A

Federal Communication Commission Radio Frequency

International Statement

This equipment has been tested and found to comply with the limits for a

Class A digital device, pursuant to Part 15 of the FCC Rules. These limits are

designed to provide reasonable protection against harmful interference when

the equipment is operated in a commercial environment. This equipment

generates, uses and can radiate radio frequency energy and, if not installed and

used in accordance with the instructions manual, may cause harmful

interference to radio communications. Operation of this equipment in a

residential area is likely to cause harmful interference in which case the user

will be required to correct the interference at his own expense.
