• The ceiling hoist is switched on by pressing

one of the buttons on the hand control.

• A green indicator lamp will show that the

hoist is switched on and ready for use.

• If the indicator lamp shows yellow, this

means that there is no main connection to

the hoist.

• If the indicator lamp is yellow and the hoist is

beeping when activated, there is a fault with

the hoist.

• If the ceiling hoist does not switch on, this

may be because the emergency stop has

been activated – red strap (labelled with

triangle symbol).

• The hoist does not need to be turned off – it

switches off automatically after approximately

two minutes without activation.

• The hoist recharges when the hand control is

placed in the charging station with the power

supply turned on (3 beeps for charging). The

position of the lifting hanger does not affect

charging. Charging will always take place

irrespective of the height of the lifting hanger.

• The hoist’s lifting capacity will be marked on

the hoist, e.g., 205 kg/450 lbs. This means

that the hoist may be used for loads up to

205 kg/450 lbs. Note however that the rail

system or the sling may have a lower lifting

capacity. The load may not exceed the low-

est lifting capacity.

• The GH1Q features a quick-release system

that makes it very simple to click-on and

click-off the lifting module from the rails.

• If you have any questions regarding instruc-

tions and training, ask your environmental

health & safety coordinator, human resourc-

es manager or your line manager.

Quick Guide – GH1/GH1 Q

Safety functions

Emergency stop

• One pull on the red strap. Use only in emer-

gencies, when there is an immediate need to

stop the hoist.

• When the emergency stop is activated, only

the hoist’s emergency lowering device will

function.

• Deactivate the emergency stop by press-

ing the “stop” button (yellow button) on the

hoist. Then press one of the buttons on the

hand control unit twice.

Emergency lowering device

This is activated by a prolonged pull on the

red strap. Use only in an emergency. This

function allows the patient to be lowered

when the hoist has failed to work.

Scan here for user manual,

etc. concerning use of the

GH1/GH1 Q.

Accessories

Lifting hanger

Place the sling straps in the hooks. Check

that the straps have been correctly attached

to the hanger.

Lifting sling

We recommend using a lifting sling with two

or four loop attachments for attaching the

sling to the lifting hanger. The sling must

always correspond with the hoist’s lifting

capacity. In case of doubt concerning the

use of a lifting sling, please contact your

supplier.

Daily cleaning and

maintenance

Clean with a damp cloth and ordinary de-

tergent. Do not use strong acids, bases or

alcohol when cleaning. See user manual.

For Sales or Customer Service

please contact:

Guldmann Inc. - (800) 664-8834
