Quick Guide - Combi-lock
Do NOT move the traverse rail
when the hoist is in this position!
Position the traverse rail so it is alig-
ned with the Combi-lock rail.
When the rails are aligned the safety
gates open automatically.
After checking that the Safety lock
has engaged, position yourself right
behind or in front of the hoist. It is
now safe to manoeuver the hoist
through the Combi-lock, and on to
the fixed or traverse rail.
When the hoist has passed through
the Combi-lock it is safe to move the
traverse rail.
GH1Q should NEVER be used in
systems with a Combi-lock, as there is
a risk of the hoist falling down.
ADVARSEL
1 2
3 4
Quick Guide - Combi-lock
© Guldmann GB/US-12/2023 • # 900712
Place the hoist at the yellow marking approx.
1 meter from the end of the traverse rail and
Combi-lock.
Place the user facing / looking lengthwise
the traverse rail and in a level where you can
push / hold as in the picture.
To align the rails and engage the Combi-lock
place yourself on the side of the user so you
push or pull perpendicular on the traverse rail.
If the Combi-lock doesn’t engage the first
time, move the traverse rail approx. ½ to 1
meter away from the Combi-lock rail and try
again.
When the Combi-lock has engaged position
yourself behind the user and push lengthwise
the traverse rail though the Combi-lock. The
user is still facing / looking lengthwise the
traverse rail.
1
2
3
