OPERATING MANUAL
Lithium Power Sweeper
Model number: SW22
4
Thank you for choosing a Gtech Power Sweeper
“I started Gtech to create sensible, easy to use products, which do a great job. Your opinion is
important to us. Please take the time to write a review of the Sweeper either on the website of
the store you bought it from or by emailing us at support@greytechnology.co.uk. We will use
your feedback to improve our products and services and let other people know what it’s like to
be part of the Gtech family.” Nick Grey – Inventor, Owner of Gtech
Register your warranty now at:
www.gtech.co.uk/warrantyregistration or call 08000 518353
Keep your receipt with this manual. You will need it if you ever have a warranty claim.
What’s in
the box
1
Sweeper
Upper Handle
Telescopic Handle Tubes
Lower Handle
Fast Charge Stand
Duster
Duster clip
3
4
5
6
7
4
5
6
7
1
2
3
2
5
The three parts of the telescopic handle
also click into place. The duster can be
clipped onto the back of the handle.
Assembly
Place the lower handle into the socket.
Push the locking clip back into place.
Push handle forward.
To assemble the lower handle
Pull out the locking clip.
6
Pull back the handle and press the “on”
button with your foot. When running, the
light shows green for a full charge, orange
for 20% charge and red for 10%. When
the sweeper needs recharging the light will
ash red and the sweeper will stop.
Remove the dust tray by pinching the
window slightly and pulling it out.
Normal operation
Push at over the oor.
Deeper cleaning
Lift the handle to lower the
brush bar into the carpet.
Tip the dirt into the bin. If you need to you
can wipe the tray clean with a dry cloth.
Operation
Emptying the bin
7
Remove the telescopic handle by pressing
the button at the front of the lower handle
and pulling the tube out.
The telescopic handle can now be
attached to the duster.
Remove the visor by unclipping the bottom
outer edges at the same time then lifting off.
Push lower handle fully forward.
Use on stairs, starting at the top and
front of each step then moving down and
towards you.
Removing telescopic handle and using duster
Handheld use and stair cleaning
8
Recharging
From time to time you may need to remove
hair and thread from the brush bar. Take off
visor and use a pair of scissors to remove
the hair.
Try to avoid carrying the sweeper ‘nose
down’ as you risk spilling dirt from the
dust tray.
Plug in the charge stand
and lower the sweeper onto it so that the
terminals connect at the back.
Clearing the brush bar Carrying
The 3 colour LED shows red when
charging starts, yellow when partially
charged and green when fully charged.
This will only take around 3 hours.
9
Product Care
Troubleshooting
Your Gtech sweeper doesn’t need much maintenance: empty the dust tray, remove hair
and bre from the brush bar and edge wheel and charge the battery. Wipe it with a dry
cloth if it gets dirty, including in and around the bin. Never wash it with liquid or run it
under a tap. Avoid cleaning over rug tassels or frayed carpets as this will tangle the brush
bar. The battery, drive belt, brush bar and side brush are all replaceable items.
If you nd you ever need to replace these items there is an FAQ section on our website at
www.gtech.co.uk
Sweeper is not cleaning well 1. Empty the bin.
2. Remove any build-up of hair from
brush bar and edge wheel.
Sweeper has stopped
or won’t work
1. Fully recharge for 3 hours.
If this doesn’t solve your problem don’t worry, we will help.
Go to www.gtech.co.uk or call 01905 345 891
The ecocharge stand has an efcient standby function to top up the battery when
needed. If not being used the product can be left on the charging stand so it will always
be fully charged until it is needed for use.
11
The symbol indicates that this product
is covered by legislation for waste electrical
and electronic products (EN2002/96/EC)
When the sweeper has reached the end of
its life, it and the Li-ion battery it contains
should not be disposed of with general
household waste. The battery should be
removed from the sweeper and both should
then be disposed of properly at a recognised
recycling facility.
Call your local council, civic amenity site,
or recycling centre for information on the
disposal and recycling of electrical products.
Alternatively visit
www.recycle-more.co.uk
for advice on recycling and to nd your
nearest recycling facilities.
WARNING: Only use the charger supplied
with the product.
Using another charger may damage the
product and the battery and will invalidate
your guarantee.
FOR HOUSEHOLD USE ONLY
SW22 TECHNICAL SPECIFICATION
Unit operating cycle
with full battery
up to 120 mins
(dependent on oor surface)
Battery type Lithium-ion
Battery voltage 7.4V
Charging period for fully
discharged battery
3 hours
Battery charger output 10V DC, 1000mA
Battery charger model GTECH-100100
Sound Level 75db (A)
Weight 1.4kg
