GSSI StructureScan Mini XT Manuel utilisateur

MN70-812 Rev E

including the right of reproduction

in whole or in part in any form

Published by Geophysical Survey Systems, Inc.

40 Simon Street

Nashua, NH 03060-3075 USA

Printed in the United States

SIR, RADAN, UtilityScan and PaveScan are registered trademarks of Geophysical Survey Systems, Inc.

StructureScan™Mini XT Quick Start Guide

A Fast Check List for Field Operation

Introduction ............................................................................................................................................................. 1

StructureScan™ Mini XT........................................................................................................................................ 2

Front/Top View ........................................................................................................................................................2

Back View ...................................................................................................................................................................3

Section 1: Getting Started.................................................................................................................................... 4

First Time Setup .......................................................................................................................................................6

Section 2: Using ScanEZ Mode........................................................................................................................... 7

Understanding the Mini XT Screen ..................................................................................................................8

Collecting Data and Marking Targets .......................................................................................................... 10

Playing Back 2D Data.......................................................................................................................................... 13

Section 3: Using the Scan3D App....................................................................................................................15

Setting up Collection Parameters.................................................................................................................. 16

Section 4: File Management .............................................................................................................................23

Appendix A: The Dielectric Constant.............................................................................................................24

Appendix B: Data Interpretation and Examples of Common Features..............................................25

Limited Warranty, Limitations of Liability and Restrictions

Geophysical Survey Systems, Inc. hereinafter referred to as GSSI, warrants that for a period of 24 months from the delivery date to the

original purchaser this product will be free from defects in materials and workmanship. EXCEPT FOR THE FOREGOING LIMITED

WARRANTY, GSSI DISCLAIMS ALL WARRANTIES, EXPRESS OR IMPLIED, INCLUDING ANY WARRANTY OF

MERCHANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE. GSSI's obligation is limited to repairing or replacing parts

or equipment which are returned to GSSI, transportation and insurance pre-paid, without alteration or further damage, and which in

GSSI's judgment, were defective or became defective during normal use.

GSSI ASSUMES NO LIABILITY FOR ANY DIRECT, INDIRECT, SPECIAL, INCIDENTAL OR CONSEQUENTIAL

DAMAGES OR INJURIES CAUSED BY PROPER OR IMPROPER OPERATION OF ITS EQUIPMENT, WHETHER OR NOT

DEFECTIVE.

Before returning any equipment to GSSI, a Return Material Authorization (RMA) number must be obtained. Please call the GSSI

Customer Service Manager who will assign an RMA number. Be sure to have the serial number of the unit available.

Regulatory Information

Please see our website, www.geophysical.com/regulatoryinformation, for current information and FCC Registration Form, including:

FCC Notice for U.S. Customer

Canadian Requirements for RSS-220

Declaration of CE Conformance

Laser Cautions and Warnings

Please see the full StructureScan Mini XT manual for important laser cautions and warnings.

StructureScan Mini XT Quick Start Guide Page 1

Introduction

Thank you for purchasing the StructureScan Mini XT by GSSI. StructureScan Mini XT is the very latest product from

GSSI’s line of cutting-edge GPR concrete inspection tools. The Mini XT is designed with today’s busy concrete

professional in mind. It’s a tool that packs a ton of simple to learn functionality into a ruggedly reliable package.

The Mini XT will turn in a solid day of work and be back on the job first thing in the morning with no complaints.

What Comes in the Box

•StructureScan Mini XT

•StructureScan Mini XT transit case

•Two (2) rechargeable lithium ion batteries

•Battery charger with AC power adaptor and set

of international plugs

•Tool to remove the XT’s handle

•Safety wrist strap

•Quick Start Guide (this document)

About this Quick Start Guide

This document is provided to get you up and running with your new Mini XT right out of the box. It details field setup

and use of two of the Mini XT’s applications: Scan EZ (for simple 2D collection) and Scan 3D (for 3D collection). The

Quick Start Guide is not a replacement for the full Mini XT manual. The XT manual contains full information on the

other modes as well as some tips and tricks for processing and presenting your data. You can download the full manual

from GSSI’s public website: www.geophysical.com. Navigate to Support → Download Resources.

GSSI also recommends that you take advantage of one of the training opportunities provided for the Mini XT. GSSI offers

a full suite of webinars, videos, and live training classes for you to deepen your knowledge of GSSI products and GPR

applications. Please visit www.geophysical.com or contact training@geophysical.com for more details.

StructureScan Mini XT Quick Start Guide Page 2

StructureScan™Mini XT

Front/Top View

Ergonomic removable handle and

controls

2Easy to use operator interface with

color display screen

3Survey wheel encoder

4Guiding laser for locating

5 Accessory attachment point

StructureScan Mini XT Quick Start Guide Page 3

Back View

Power button

2 Battery slot

3USB port

4 Battery release

StructureScan Mini XT Quick Start Guide Page 4

Section 1: Getting Started

1Remove any protective tape from the wheels.

2GSSI recommends fully charging the batteries prior to use.

3Insert a fully charged battery into the battery slot. The battery should

be inserted with the small plastic tabs pointing down.

Gently push the battery in until the plastic battery release clips

on the Mini XT catch on the battery tabs.

4Push the Power Button to turn on the Mini XT. The Mini XT is powering up and on when the Blue ring on the button

is illuminated. After a few moments the Mini XT Main menu screen will appear.

Note: The Mini XT incorporates a power-saving Sleep feature. The Mini XT is asleep when the screen goes black

and the blue ring around the power button pulses. Pushing any of the buttons on the handle control keypad will wake

the Mini XT. You can modify the sleep settings and power management plan in the ScanMax App. Please see the full

Mini XT manual for details.

StructureScan Mini XT Quick Start Guide Page 5

The Main Menu Screen

App Selection

Carousel

Handle Keypad

Menu Carousel Softkeys

Battery and Storage Indicators

StructureScan Mini XT Quick Start Guide Page 6

First Time Setup

Note: The Mini XT incorporates a touch screen. You can use the handle keypad or touchscreen to access most of the

menu items.

1Set Language: Make sure that the Mini XT is in ScanMax App. Click the Down arrow to highlight the Menu

Carousel and then the Left/Right arrows to choose Select Language. Click the middle keypad button or press the

softkey on the carousel to select. Choose your desired language. This may cause the Mini XT to restart.

2Set Units: In the ScanMax App, choose Units from the Menu Carousel. Click the middle handle keypad button to

press the softkey to toggle between English (Imperial) and Metric units.

3Calibrate Antenna: In the ScanMax App, select Calibrate Antenna from the Menu Carousel. Follow the onscreen

instructions. Calibrating will set appropriate gain levels.

4Set Date/Time:In the ScanMax App, choose the secondary menu softkey: Click the middle handle

button or push the softkey to toggle to the ScanMax secondary menu carousel.

Follow the onscreen instructions to set the appropriate date and time.

The choices you have made here will carry over to the ScanEZ and the

Scan3D Collection Apps.

Secondary Menu Softkey
