Grundig GTB59 Manuel utilisateur

GTB59

TRANSISTOR BOX 59

REPLICA AM/FM RADIO

GTB59

The Gold Technical Support Line: 1902 215 259

(Charges will apply at $2.95 per minute)

GTB59

Introduction

Thank you for buying this Grundig product, which is designed to give you many years of

trouble-free service.

You may already be familiar with using a similar unit, but please take time to read these

instructions. They are designed to familiarise you with the unit’s many features and to ensure you

get the very best from your purchase.

Safety is important

Your safety and the safety of others is important.

Please therefore, ensure you read the “Safety Instructions” before you operate this unit.

Warranty

In the unlikely event that your product fails to work normally, please call the below free phone

number to discuss the problem with one of our qualified service engineers.

Australia.

Grundig Warranty: 1800 509 394

New Zealand

Grundig Warranty: 0800 450 259

GTB59

Ensure that you read all of the safety instructions before using this unit.

SAFETY CONSIDERATIONS

Position the power cable and other connected cables so that they are not likely to be walked

on, pinched or where items can be placed on or against them.

Do not use the unit in humid or damp conditions.

Do not allow the unit to get wet.

Never allow children to insert foreign objects into holes or slots on the unit.

Do not cover the ventilation with items such as tablecloths, curtains, etc. This may cause

overheating.

No naked flame sources, such as lit candles, should be placed on or near the unit.

Do not expose the unit to dripping or splashing water, and no objects filled with liquids, such

as vases, should be placed on or near the apparatus.

Do not place the unit in closed cabinet without proper ventilation.

CLEANING

Disconnect the unit from the mains supply before cleaning.

Do not use any liquids or aerosol cleaners, as this may damage the unit. Use a soft, dust free

cloth.

SERVICING

There are no user serviceable parts in the unit. When servicing, refer to qualified service

professional.

Consult your retailer if you are ever in doubt about the installation / operation / safety of the

product.

Safety Instructions

GTB59

Grundig Radio are pleased to look back at this classic design with the GTB59, part of the Grundig

retro range of Audio Products. The quality of the sound reproduction from the modern technology

today, married with the classic styling, evokes the simple elegance of a bygone era.

CONTROLS

1.Tuning Knob –The Tuning Knob allows you to

set or adjust the radio frequency.

2.Volume Knob –The Volume Knob allows you to

set or adjust the volume.

3.Band Switch –The band Switch allows you to

set the radio to FM or AM.

4.iPod/Auxiliary Input –The iPod/Auxiliary Input

allows you to connect and play your iPod or MP3

Player.

5.3.5mm Headphone Jack –allows you to

connect your headphone for personal play.

6.DC Jack –The DC Jack connects to the DC power

cord so you can connect to the mains power.

7.Battery Compartment –You can also run this

radio on batteries. It requires 4 x UM-2 / C size

batteries

8.Speaker –The speaker provides you with quality

sound

9.Handle –The leather handle allows you to easily

carry your GTB59 with you anywhere.

Welcome to the GTB59

GTB59

Carefully remove your GTB59 from the box. You may wish to store the packaging for future use.

In the Box

Inside the box you will find:

GTB59 Transistor Box 59 (Main Unit)

Power Adaptor

User Guide

Letter of Authenticity

AC ADAPTOR OPERATION

Connect the AC Power Cord to your AC household mains outlet and switch on the mains power

supply. Make sure the voltage is compatible.

Note: Disconnect the Power Cord from the mains when not in use.

BATTERY POWER OPERATION

1. Remove the AC Power Cord from the power supply and the unit for battery operation.

2. Open the battery compartment lid.

3. Install 4 x UM-2 / C size batteries (not included). Refer to the polarity diagram on the

battery compartment. Match the (+) and (-) marks on the diagram to the (+) and (-) marks

on the batteries.

4. Replace the lid.

Note: Batteries should be removed from the compartment if the unit is not to be used for a

long period of time.

Flat batteries should be removed from the unit to avoid leakage.

Preparation For Use

GTB59

RADIO OPERATION

1. Turn on the radio by turning the VOLUME knob in clockwise motion until you hear a “click”

sound.

2. Select the desired frequency band with the BAND switch.

3. Tune in your desired station by turning the TUNING knob to the appropriate frequency.

4. Adjust the Volume by turning the VOLUME knob to your desired sound level.

5. For private listening, connect your headphones to the HEAPHONE jack.

6. To turn off the radio, turn the VOLUME knob in anti-clockwise until a “click” sound is heard.

CONNECTING AN IPOD

In order to connect an iPod or MP3 Player to this unit, you will need to purchase a 3.5mm

Auxiliary Cable from your local electrical retailer. Plug this cable into the Auxiliary Output or

Headphone Jack of the device for playback via the GTB59.

CONNECTING HEADPHONES

In order to listen to your GTB59 through Headphones, connect your 3.5mm Headphone Cable

into the Headphone Jack.

ANTENNA

The FM and AM Antenna is built in to this radio. To improve radio reception, rotate the unit or

move the unit to an area that receives better radio reception.

Listening to your Grundig Radio

GTB59

Troubleshooting

If a fault occurs, first check the points listed below before taking the set for repair. If you are unable

to remedy a problem by following these hints, consult you retailer or service professional.

WARNING: Under no circumstances should you try to repair the set yourself, as this would invalidate

the warranty.

PROBLEM

POSSIBLE CAUSE

REMEDY

No sound

Headphones are connected.

Volume not adjusted.

Power cord is not correctly

connected.

Disconnect the headphones.

Adjust the Volume.

Connect the power cord

properly.

Unit buttons/knobs are not

working

Electrostatic discharge.

Turn off the unit, disconnect

the mains plug, and reconnect

after a few seconds.

Radio poor reception

Weak radio aerial signal.

Interference caused by the

vicinity of electrical

equipment like TVs, Video

Recorders, Computer,

Thermostats, Fluorescent

Lamps (TL) engines etc.

Aim the aerial for best

reception, and ensure it is fully

extended.

Keep the unit away from other

electrical equipment

Troubleshooting

GTB59

Specifications ………………………………………………..

GTB59 Transistor Box 59, Replica

AM/FM Radio

Speaker Power…………………………………………..…..

4 Ohm 2W

Frequency Range.…………………………………………..

Output Power……………………………………………….

FM: 87.1 –108.7 MHz

AM: 517 –1635 KHz

900 mW (Max)

Power Supply.……………………………………………….

AC 230V 50Hz

DC 6V (4 x UM-2 battery, not included)

(please use provided adaptor)

Dimension.……………………………….………………….

188 (L) X 75 (W) X 130 (H) mm

Technical Specifications

GTB59

Please keep your receipt as proof of purchase. This product is warranted for any defect in materials

or workmanship for one year after the original date of purchase. This product is for normal

domestic and office use only. This warranty does not cover damage from misuse or neglect,

accidental damage, vermin infestation, excessive voltages such us lightning or power surges or any

alteration that affects the performance or reliability of the product.

In the unlikely event that your product fails to work normally, please contact Grundig Warranty on

1800 509 394 (Australia) or 0800 450 259 (New Zealand) and have your receipt of purchase on

hand.

This warranty is subject to the following provisions:

●It is only valid within boundaries of the country of purchase

●The product must be correctly assembled and operated in accordance with the instructions

contained in this manual

●This product must be used solely for domestic purposes

●The warranty does not cover accidental damage

●The warranty will be rendered invalid if the product is resold or has been damaged by inexpert

repair

●The manufacturer disclaims any liability for incidental or consequential damaged

This warranty is in addition to, and does not diminish, your statutory or legal rights.

PO BOX 6287

Silverwater NSW 1811

www.grundig.net.au

Grundig Warranty: 1800 509 394 Australia

Grundig Warranty: 0800 450 259 New Zealand

Warranty

GTB59

PO BOX 6287

Silverwater NSW 1811

www.grundig.net.au
