Grundig GRKHD01 Manuel utilisateur
www.topvehicletech.com
The informaon provided in this document is subject to change without noce due to changes and/or
improvements to the product/s.
V1.0522
GRKHD01
SUZUKI SWIFT
2011-2017
INSTALLATION MANUAL
This dash image is a visual representaon for display purposes only.
2
www.topvehicletech.com
ABOUT THIS PRODUCT
The GRKSZ01 installaon kit allows for the retenon of the vehicle’s steering wheel controls and helps maintain
the original aesthec of the interior when installing a new car stereo. The GRKSZ01 gives you everything you
need for a complete install in one box. The components of this kit are compable for the Suzuki Swi (2011-
2017) with Panasonic factory stereos. The wiring harness and interface will retain the steering wheel controls
and phone buon funconality (if vehicle is equipped).
The interface supplied features an OEM specic connector.
CUSTOMER SUPPORT
Installaons should be carried out by, or under the guidance of an experienced installer. If you do encounter any
problems during the installaon of this product, then please contact our dedicated customer service team at:
Phone: 01420 470 605 E-Mail: help@topvehicletech.com
CONTENTS
• 1x Fascia plate (with accessories)
• 1x Instrucon manual
• 1x Steering wheel control harness and interface
• 1x Antenna adapter
• 1x Stereo patch lead
3
www.topvehicletech.com
FITTING GUIDE
STEREO REMOVAL
FASCIA PLATE SET-UP
1. Once you have taken the main head unit out of the dashboard, you will need to transfer the 4x retaining
clips onto the corresponding posts of the new fascia.
2. Take the brackets from within the kit and line them up to the rear of the new fascia and use the 6x
screws within the kit to aach them securely.
3. Take the new radio and slide this inbetween the brackets from behind the fascia panel. Line the holes up
correctly and aach them accordingly.
4. Take the rubber band and align this around the outside of the trim. When aligned correctly, this can
then be pushed onto the front of the fascia for a seamless looking t.
1. Use a panel removal tool to free up the top vent panel which will have 3x retaining clips either side.
Once free, either disconnect the hazard switch connector and remove, or simply put to one side.
2. With the vent’s out of the way, this will uncover 2x phillips screws at either side of the radio. Undo these
screws and carefully remove them out of the dashboard.
3. When the top screws are out of the way, use the panel removal tool again to dislodge the 4x retaining
clips that hold the main head unit in place. Once free, remove completely whilst disconnecng the wiring.
5. With the bracketry aligned correctly, and the “Stereo Installaon” process complete, you can then push
the head unit and fascia assembly into the dashboard to complete the installaon.
4
www.topvehicletech.com
FITTING GUIDE
4. Aach the addional wiring on the harness to the back of the stereo:
Pink - Speed Pulse
5. When all the above wires (and any addional accessories) have been connected, nally make the power
connecons between the stereo and the vehicles pre-exisng connector.
3. Aach the antenna adapter to the vehicles pre-exisng connecon and the back of new stereo.
1. Take the steering wheel control interface and aach the 14-way steering wheel harness connector to
the relevant side.
STEREO INSTALLATION
2. Make a cut within the orange and purple loops on the back of the patch lead connector. Then proceed
to aach ‘Key 1’ to the light blue ‘SWC Remote’ wire on the stereo. When done, connect the 12-way
connector to the steering wheel control interface.
5
www.topvehicletech.com
Please note: conguraon layout may dier dependent on vehicle model.
STEERING WHEEL CONTROL FUNCTIONALITY
1
2
3
4
56
7
MODE
VOL
+
-8
1. Volume +
2. Volume -
3. Track +
4. Track -
5. Mute
6. Source
7. Pick Up
8. Hang Up
1. Volume +
2. Volume -
3. Up Arrow
4. Down Arrow
5. Mute
6. Mode
7. Pick Up
8. Hang Up
Original Buon New Funcon
6
www.topvehicletech.com
WIRING DIAGRAM
ISO Connector
Connect to new stereo
OEM Specific Connector [20 Pin]
Connect to corresponding
connector from vehicle
Main Wiring Loom Connector [14 Pin]
Connect to Interface Box
Interface Box
Flying Wires
Pink - Speed Pulse
Stereo Connection (Patch)
Lead Connector [12 Pin]
Connect to Interface Box
Note: Must be connected
first, before power
connection is made to the
interface
7
www.topvehicletech.com
NOTES
8
www.topvehicletech.com
If at any point you experience any problems and need any assistance before, during or aer the
installaon process, please contact us via :
Phone: 01420 470 605
E-Mail: help@topvehicletech.com
Mon - Fri 9am - 5.30pm GMT
TECHNICAL ASSISTANCE
If you would like to download a digital copy of this manual, or any other product, then please
visit the www.topvehicletech.com website.
This manual is considered correct at the me of prinng but is subject to change. For the latest
manuals & updates, refer to our website.
Copyright 2022 by TopVehicleTech.
All rights reserved. No part of this publicaon may be reproduced, distributed or transmied
in any form or by any means, including photocopying, recording, copying or other electronic or
mechanical methods, without the prior wrien permission of the author.
