Grizzly G9984 Manuel utilisateur

OSCILLATING BELT

EDGE SANDER

MODEL G9984/G9985

PARTS LIST

WARNING: NO PORTION OF THIS MANUAL MAY BE REPRODUCED IN ANY SHAPE

OR FORM WITHOUT THE WRITTEN APPROVAL OF GRIZZLY INDUSTRIAL, INC.

PRINTED IN TAIWAN.

PARTS LIST DISCLAIMER

THIS PARTS LIST AND DRAWINGS REPRESENT THE CONFIGURATION OF THE MACHINE AS IT IS CURRENTLY BEING SHIPPED. THE MACHINE CONFIGURA-

TION CAN CHANGE AS PRODUCT IMPROVEMENTS ARE INCORPORATED. IF YOU OWN AN EARLIER VERSION OF THE MACHINE, THIS PARTS LIST MAY NOT

DEPICT YOUR MACHINE EXACTLY. CONTACT CUSTOMER SERVICE IF YOU HAVE ANY QUESTIONS ABOUT PART DIFFERENCES. PREVIOUS PARTS LIST VER-

SIONS ARE NOT AVAILABLE ONLINE.

G9984/G9985 Oscillating Belt Edge Sander -C-

REF PART # DESCRIPTION

01 P9984001 MACHINE BASE

02 G4573 MAGNETIC SWITCH-G9984

02 G4673 MAGNETIC SWITCH-G9985

03 P9984003 COVER

04 PS14M PHLP HD SCR M6-1.0 X 12

05 P9984005 BRACKET

06 PW06 FLAT WASHER 1⁄4"

07 PLW02 LOCK WASHER 1⁄4"

08 PS26M PHLP HD SCR M6-1.0 X 20

09 P9984009 RUBBER FOOT

13 P9984013 BASE SUPPORT

15 PW04M FLAT WASHER 10mm

17 P9984017 SUPPORT

18 PW02 FLAT WASHER 3⁄8"

19 PLW06M LOCK WASHER 10mm

20 PB31M HEX BOLT M10-1.5 x 40

21 P9984021 SANDING BELT 9" x 1381⁄2"

22 P9984022 PLATTEN 7⁄16" X 1389⁄16"

23 P9984023 PLATE

24 PLW01M LOCK WASHER 5mm

25 PS40M PHLP HD SCR M5-0.8 X 16

27 P9984027 BRACKET

28 PW06 FLAT WASHER 1⁄4"

29 PLW02 LOCK WASHER 1⁄4"

30 PS11M PHLP HD SCR M6-1 X 16

31 P9984031 BRACKET

32 P9984032 DUST HOOD

33 P9984033 GUARD PLATE

34 PW06 FLAT WASHER 1⁄4"

35 PLW02 LOCK WASHER 1⁄4"

36 PS11M PHLP HD SCR M6-1 X 16

37 P9984037 GUARD PLATE

38 PW06 FLAT WASHER 1⁄4"

39 PS03M PHLP HD SCR M6-1 X 8

40 P9984040 "U" HANDLE

41 PS16M PHLP HD SCR M8-1.25 x 16

42 PN03M HEX NUT M8-1.25

43 P9984043 STAR KNOB M10-1.5 X 15

44 P9984044 EYE BOLT M10-1.5 X 12

45 PB01M HEX BOLT M10-1.5 X 30

46 P9984046 ELECTRICITY LABEL

47 P9984047 READ MANUAL LABEL

48 P9984048 SAFETY GLASSES LABEL

49 P9984049 UNPLUG MACHINE LABEL

G9984/G9985 Oscillating Belt Edge Sander -E-

REF PART # DESCRIPTION

101 P9984101 ELEVATION BLOCK

102 P9984102 BRUSH

103 P9984103 SEAL

104 P9984104 SHAFT

105 P9984105 LINK

106 PB07M HEX BOLT M8-1.25 X 25

107 P9984107 SPRING

108 PW07 FLAT WASHER 5⁄16"

109 PLW01 LOCK WASHER 5⁄16"

110 PB06M HEX BOLT M8-1.25 X 12

111 PB34M HEX BOLT M10-1.5 X 60

112 PN02M HEX NUT M10-1.5

113 PLW06M LOCK WASHER 10mm

114 PW07 FLAT WASHER 5⁄16"

115 PLW01 LOCK WASHER 5⁄16"

116 PB30M HEX BOLT M8-1.25 X 55

117 P9984117 ADJUSTMENT PLATE

118 PFH14M FLAT HD ALLEN SCR M10-1.5 X 25

119 PW04M FLAT WASHER 10mm

120 PLW06M LOCK WASHER 10mm

121 PB14M HEX BOLT M10-1.5 X 35

122 P9984122 TABLE UNIT

123 P9984123 BRACKET (R)

124 P9984124 ADJUSTMENT BASE (R)

125 PB14M HEX BOLT M10-1.5 X 35

126 PLW06M LOCK WASHER 10mm

127 PN02M HEX NUT M10-1.5

128 PW04M FLAT WASHER 10mm

129 PLW06M LOCK WASHER 10mm

130 P9984130 LOCK HANDLE M10-1.5 X 35

131 P9984131 INDICATOR SCALE

132 P9984132 POINTER

133 PLW01M LOCK WASHER 5mm

134 PS09M PHLP HD SCR M5-0.8 X 10

135 P9984135 BRACKET (L)

136 P9984136 ADJUSTMENT BASE (L)

137 P9984137 OUTSIDE TABLE

138 PW02 FLAT WASHER 3⁄8"

139 PLW06M LOCK WASHER 10mm

140 PB01M HEX BOLT M10-1.5 X 30

141 P9984141 MITER GAUGE

142 P9984142 MITER GAUGE HANDLE 5⁄16"

143 P9984143 POINTER

144 PLW02M LOCK WASHER 4mm

145 PS17M PHLP HD SCR M4-0.7 x 6

146 P9984146 COVER

147 PS03M PHLP HD SCR M6-1.0 X 8

148 P9984148 LOCK HANDLE M12-1.75 X 40

149 P9984149 ID/WARNING LABEL G9984

149 P9985149 ID/WARNING LABEL G9985

G9984/G9985 Oscillating Belt Edge Sander -G-

REF PART # DESCRIPTION

201 P9984201 SIDE TABLE SUPPORT

202 PW02 FLAT WASHER 3⁄8"

203 PLW06M LOCK WASHER 10mm

204 PB01M HEX BOLT M10-1.5 X 30

205 P9984205 LOCK HANDLE M10-1.5 X 25

206 P9984206 SHAFT

208 PB73M HEX BOLT M10-1.5 X 50

209 PLW06M LOCK WASHER 10mm

210 PN25M HEX NUT ACORN M10-1.5

211 PW04M FLAT WASHER 10mm

212 PLW06M LOCK WASHER 10mm

213 PB14M HEX BOLT M10-1.5 X 35

214 PW04M FLAT WASHER 10mm

215 PLW06M LOCK WASHER 10mm

216 PB74M HEX BOLT M10-1.5 X 20

217 P9984217 ADJUSTMENT BASE

218 P9984218 SIDE SANDING TABLE

219 PR11M EXT RETAINING RING 25mm

220 P9984220 SHAFT

221 P9984221 DUST HOOD

222 PW07 FLAT WASHER 5⁄16"

223 PLW01 LOCK WASHER 5⁄16"

224 PS16M PHLP HD SCR M8-1.25 x 16

G9984/G9985 Oscillating Belt Edge Sander -I-

REF PART # DESCRIPTION

301 P9984301 SHAFT

302 P9984302 BRUSH

303 P9984303 STOPPER BLOCK

304 P9984304 SPRING

305 P9984305 PLATE

306 PLW06M LOCK WASHER 10mm

307 PB74M HEX BOLT M10-1.5 X 20

308 PSS30M SET SCREW M10-1.5 X 10

309 P9984309 LEVER

310 P9984310 HANDLE M10-1.5

311 PSB70M CAP SCREW M10-1.5 X 30

312 PLW05M LOCK WASHER 12mm

313 PN26M HEX NUT ACORN M12-1.75

314 PB01M HEX BOLT M10-1.5 X 30

315 PLW06M LOCK WASHER 10mm

316 P9984316 BUSHING

317 P6003 BEARING 6003LLB

318 PW04M FLAT WASHER 10mm

319 PN25M HEX NUT ACORN M10-1.5

321 P9984321 BRACKET

322 P9984322 SPHERICAL BEARING PB20

323 PW04M FLAT WASHER 10mm

324 PLW06M LOCK WASHER 10mm

325 PS41M PHLP HD SCR M10-1.5 X 25

326 PW04M FLAT WASHER 10mm

327 PLW06M LOCK WASHER 10mm

328 PS41M PHLP HD SCR M10-1.5 X 25

329 PLW07 LOCK WASHER 1⁄2"

330 PN09M HEX NUT M12-1.75

331 P9984331 THREADED ROD M12-1.75 X 140

332 PW01 FLAT WASHER 1⁄2"

333 P9984333 STAR KNOB

335 P9984335 SHAFT

336 P6205 BEARING NSK6205

337 P9984337 ROLLER

338 PR11M EXT RETAINING RING 25mm
