YT2.291.036WHSC-JX1
CDM8240 Service Manual (level 1) Page ii of ii
Contents
1TOOLS ..........................................................................................1
1.1 STANDARD SERVICE TOOLS ...............................................................1
1.2 CLEANING TOOLS ...........................................................................1
2DISASSEMBLING AND REPLACEMENT..........................................3
2.1 REMOVAL AND INSERTION OF NC........................................................3
2.2 REMOVAL AND INSERTION OF RV........................................................4
2.3 REMOVAL AND REPLACEMENT OF MB....................................................5
2.4 REMOVAL AND REPLACEMENT OF NP....................................................7
2.5 REMOVAL AND REPLACEMENT OF NS....................................................9
2.6 REMOVAL AND REPLACEMENT OF NT..................................................11
2.7 REMOVAL AND REPLACEMENT OF NF..................................................13
2.8 REMOVAL AND REPLACEMENT OF CF ..................................................15
3NC ADJUSTMENT ........................................................................17
3.1 HEIGHT ADJUSTMENT....................................................................17
3.2 WIDTH ADJUSTMENT.....................................................................19
4ADJUSTMENT OF STACKING LIMITER .........................................20
5GENERAL TROUBLESHOOTING...................................................22
6PERIODIC MAINTENANCE ...........................................................23
6.1 NF MAINTENANCE ........................................................................23
6.2 NT MAINTENANCE........................................................................24
6.3 NS MAINTENANCE ........................................................................25
6.4 NP MAINTENANCE ........................................................................25
6.5 NC MAINTENANCE........................................................................25
