Gree GWC07NA-K3NNB1A Manuel utilisateur

Change for Life

Split Air Conditioner

Owner's Manual

Residential Air Conditioners

Thank you for choosing Residential Air Conditioners,please read this owner’s

manual carefully before operation and retain it for future reference.

GWH07NA-K3NNB1A

GWH07NA-K3NNB2A GWH09NA-K3NNB2A

GWH24ND-K3NNB2A

GWH09NA-K3NNB1A

GWH24ND-K3NNB1A

GWC07NA-K3NNB1A

GWC07NA-K3NNB2A

GWH12NB-K3NNB1A

GWH18ND-K3NNB1A

GWH12NB-K3NNB2A GWH18ND-K3NNB2A

GWH24ND-K3NNB3AGWH12NB-K3NNB3A

GWH09NA-K3NNB3A

GWH18ND-K3NNB3A

GWH12NB-K3NNB4A GWH18ND-K3NNB4A

GWH24ND-K3NNB4A

GWH07NA-K3NNB4A GWH09NA-K3NNB4A

GWC12MB-K3NNC1A

GWC24ND-K3NNB3B

GWC09NA-K3NNB3B

GWC09NA-K3NNB3C

GWC12NB-K3NNB3B

GWH09NA-K3NNB3BGWH07NA-K3NNB3A

GWH09NA-K3NNB1C GWH12NB-K3NNB1C

GWH12NB-K3NNB4C

GWH09NA-K3NNB4C

GWH09NA-K3NNB2C

GWH09NA-K3NNB3C

GWH12NB-K3NNB3C

GWH24ND-K3NNB5A GWH18ND-K3NNB5A

GWH07NA-K3NNB5A GWH09NA-K3NNB5A

GWH24ND-K3NNB6A

GWH24ND-K3NNB7A

GWH24ND-K3NNB8A

GWH12NB-K3NNB5C

GWH09NA-K3NNB5C

GWH09NA-K3NNA2A GWH12NB-K3NNA2AGWH07NA-K3NNA2A

GWH24ND-K3NNA1A

GWH24ND-K3NNA2A

GWH12NB-K3NNA3A

GWH18ND-K3NNA3A

GWH07NA-K3NNA3A

GWH09NA-K3NNA3A

GWH07NA-K3NNA4A GWH09NA-K3NNA4A GWH18ND-K3NNA4A

GWH12NB-K3NNA4A

GWH24ND-K3NNA3A

GWH24ND-K3NNA4A

GWH18ND-K3NNA2A

GWH12NB-K3NNA2C

GWH12NB-K3NNA3C

GWH09NA-K3NNA2C

GWH09NA-K3NNA4C

GWH12NB-K3NNA4C

GWH09NA-K3NNA3C

GWH24ND-K3NNA5A

GWH12NB-K3NNA5C

GWH24ND-K3NNA7A

GWH24ND-K3NNA8A

GWH07NA-K3NNA5A GWH09NA-K3NNA5A

GWH12NB-K3NNA5A GWH18ND-K3NNA5A

GWH18ND-K3NNA8A

GWH12NB-K3NNA8A

GWH24ND-K3NNA9A

GWH09NA-K3NNA9C

GWH09NA-K3NNA8A

GWH07NA-K3NNA8A

GWC07NA-K3NNA8A

GWH12NB-K3NNA9C GWH09NA-K3NNA9A

GWH24ND-K3NNE4A

GWH18ND-K3NNA9A

GWH18ND-K3NNE4A

GWH07NA-K3NNE4A GWH09NA-K3NNE4A GWH12NB-K3NNE4A

GWH09NA-K3NNA8CGWH12NB-K3NNA8C

GWH09NA-K3NNA5C

GWH09NA-K3NNE4C

GWH24ND-K3NND2AGWH18ND-K3NND2A

GWH24ND-K3NND1A

GWH09NA-K3NND1AGWC07NA-K3NND1A GWH07NA-K3NND1A

GWH12NB-K3NND1A GWH18ND-K3NND1A

GWH07NA-K3NND2A GWH09NA-K3NND2A

GWH18ND-K3NNC7A

GWH07NA-K3NNC7A GWH09NA-K3NNC7A GWH24ND-K3NNC7A

GWH12NB-K3NNC7A

GWH09NA-K3NNE1A GWH09NA-K3NNE1C

GWH12NB-K3NNC7C

GWH24ND-K3NNE1A

GWH24ND-K3NNE2A

GWH12NB-K3NND2A

GWH12NB-K3NND1C

GWH12NB-K3NNE1A

GWH18ND-K3NNE1A

GWH12NB-K3NNE2C GWH18ND-K3NNE2A

GWC07NA-K3NNE1A GWH07NA-K3NNE1A GWC09NA-K3NNE1C

GWH09NA-K3NND2C

GWH12NB-K3NND2C

GWH09NA-K3NND1C

GWH09NA-K3NNC7C

GWH12NB-K3NNE1C

GWH09NB-K3NNE2A

CONTENTS

This symbol stands for the items

should be forbidden.

This symbol stands for the items

should be followed

■............................................................1

■

■................................................................14

■ ..............................................19

■

■..............................23

■

..........................24

....25

■

■ ........................................................17

■.................................................................12

Operation and maintenance

Notices for operation

Notices for use ....................................................................3

Names and functions of each part ..........................................7

■Operation of wireless remote control ........................................8

Clean and care

Troubleshooting

Installation service

Notices for installation

Installation dimension diagram

Install indoor unit

Install outdoor unit

Check after installation and test operation

Installation and Maintenance of Healthy Filter

Do not dispose this product as unsorted municipal waste.

Collection of such waste separately for special treatment

is necessary.

The products in this manual may be different with the real one, according to different

models, some models have displayer and some models without displayer, the position

and shape of the displayer please refer to the real one.

This appliance is not intended for use by persons (including children) with reduced

physical, sensory or mental capabilities or lack of experience and knowledge,

unless they have been given supervision or instruction concerning use of the appliance

by a person responsible for their safety.

Children should be supervised to ensure that they do not play with the appliance.

■Specificate Model and Technical Data .....................................5

...............................................................20

............................................................22

Configuration of connection pipe and additional volume of refrigerant

★

Operation and maintenance-notices for operation

★★Be sure to pull out the power plug

★

★★

★

Earth: The ground be

connected!

If not, please ask the qualified person-

nel to install. Furthermore, don't conn-

ect each wire to the gas pipe, water

pipe, drainage pipe or any other impr-

oper places.

when not using the air conditioner

for a long time.

Otherwise, the accumulated dust

may cause fire or electric shock.

Select the most appropriate temper-

ature.

Keep room cool-

er than outside

about 5 degree.

It can preclude the electricity wasted.

Don't leave windows and

doors open for a long time

while operating the air conditioner.

It can decrease the air conditioning

capacity.

Don't block the air intake or outlet

vents of both the outdoor and indoor

units.

It can decrease the air conditioning

capacity or cause a malfunction.

Keep combustible spray away

from the units more than 1m.

It can cause afire or explosion.

If it is damaged, it may lead to

the fall of the unit and cause

the injury.

Please note whether the installed

stand is firm enough or not.

Don't step on the top of the

outdoor unit or place something

on it.

As falling off the outdoor unit

can be dangerous.

Don't attempt to repair

the air conditioner by yourself.

The wrong repair will lead to

an electric shock or fire, so

you should contact the service

center to repair.

２

★

Notices for operation

If the supply cord is damaged, it must be replaced

by the manufacturer or its service agent or a

similarly qualified person in order to avoid a

hazard.

The airflow direction can be adjusted appro-

priately. At operating, adjust the vertical airflow

direction by adjusting the louvers of upward/do-

wnward direction. And then, hold two ends of

left and right louver to adjust the horizontal air-

flow.

Louver of left/right directionLouver of upward/

downward direction.

Don't insert your hands or stick into the air

intake or outlet vents.

Otherwise it will cause accident.

Don't blow the wind to animals and plants

directly. It can cause a bad influence to them.

Don't apply the cold wind to the body for a

long time.

It can cause the health problems.

Don't use the air conditioner for other purposes,

such as drying clothes, preserving foods, etc.

Splashing water on the air conditioner can

cause an electric shock and malfunction. Don't place a space heater near the air

conditioner.

Or CO toxicosis may occur for imcomplete

burning.

Anti-cool wind function:

In "Heat" mode, under the following three kinds of state, if indoor heat exchanger doesn't

arrive at certain temp., indoor fan will not act, in order to prevent cool wind blowing(within

2 mins):

1. Heating starts.

2. After Auto Defrost finished.

3. Heating under the low temperature.

Notices for use

Working principle and special functions for cooling

Principle:

Anti-freezing function:

Working principle and special functions for heating

Principle:

Defrosting:

Air conditioner absorbs heat in the room and transmit to outdoor and discharged, so that

indoor ambient temperature decreased, its cooling capacity will increase or decrease by

outdoor ambient temperature.

If the unit is running in COOL mode and in low temperature, there will be frost formed on

the heat exchanger, when indoor heat exchanger temperature decreased below 0 , the

indoor unit microcomputer will stop compressor running and protect the unit.

℃

Air conditioner absorbs heat from outdoor and transmits to indoor, in this way to increase

room temperature. This is the heat pump heating principle, its heating capacity will be

reduced due to outdoor temperature decrease.

If outdoor temperature becomes very low, please operate with other heating equipments.

When outdoor temperature is low but high humidity, after a long while running, frost will

form on outdoor unit, that will effect the heating effect, at this time, the auto defrosting

function will act, the heat running will stop for 8-10mins.

During the auto defrosting, the fan motors of indoor unit and outdoor unit will stop.

During the defrosting, the indoor indicator flashes, the outdoor unit may emit vapor.

This is due to the defrosting, it isn't malfunction.

After defrosting finished,the heating will recover automatically.
