Gree GSY09BXAE Manuel utilisateur

Change for life

Thank you for choosing our product.

Please read this User's Manual carefully before operation and

retain it for reference.

If youlost theUser's Manual, please contact the Tool Box

or visit www.gilman-group.com or send an email to Tool Box

for theelectronic version.

User's Manual

Split Air Conditioner（Cool & Heat）

Thank

This appliance uses R32 mildly flammable refrigerant.

Installation, inspection and maintenance of R32 air conditioner shall

be conducted by authorized dealer, supplier or professionally trained technicians.

Installation shall fulfill the minimum room area and

minimum installation height as stated in this operating instruction.

GSY09BXAE/GSY09BXAC

GSY12BXAE/GSY12BXAC

GSY18BXAE/GSY18BXAC

Content

Operation Notices

The Refrigerant......................................................................................................1

Precautions............................................................................................................2

Special function and specification..........................................................................7

Screen Operation Guide

Parts’ Name..........................................................................................................10

Buttons on remote controller ................................................................................11

Introduction for buttons on remote controller........................................................11

Replacement of batteries in remote controller......................................................16

Maintenance

Emergency operation ...........................................................................................16

Malfunction

Installation Notice

Clean and Maintenance.......................................................................................17

Malfunction analysis ............................................................................................19

Safety operation of flammable refrigerant............................................................23

Installation dimension diagram ............................................................................25

Safety precautions for installing and relocating the unit.......................................26

Tools for installation .............................................................................................27

Installation

Selection of installation location ..........................................................................27

Installation of indoor unit......................................................................................29

Installation of outdoor unit...................................................................................34

Vacuum pumping.................................................................................................37

Leakage detection...............................................................................................37

Requirements for electric connection ..................................................................28

Test and operation

Check after installation ........................................................................................38

Attachment

Configuration of connection pipe.........................................................................39

Test operation ......................................................................................................38

Pipe expanding method.......................................................................................41

Specialist’s Manual..............................................................................................42

This appliance is not intended for use by persons (including children) with reduced physical, sensory

or mental capabilities, or lack of experience and knowledge, unless they have been given supervision

or instruction concerning use of the appliance by a person responsible for their safety.

Children should be supervised to ensure that they do not play with the appliance.

Explanation of Symbols

Damage the product due to improper use or misuse of the product;

Alter, change, maintain or use the product with other equipment without abiding

by the instruction manual of manufacturer;

Exception Clauses

After verification, the defect of product is directly caused by corrosive gas;

After verification, the defects are due to improper operation during transportation

of product;

Operate, repair, maintain the unit without abiding by instruction manual or related

regulations;

After verification, the problem or dispute is caused by the quality specification or

performance of parts and components that produced by other manufacturers;

The damage is caused by natural calamities, bad using environment or force

majeure.

Manufacturer will bear no responsibilities when personal injury or

property loss is caused by the following reasons.

Indicates a hazardous situation that, if not avoided, will

result in death or serious injury.

Indicates a hazardous situation that, if not avoided, could

result in death or serious injury.

Indicates a hazardous situation that, if not avoided, may

result in minor or moderate injury.

Indicates important but not hazard-related information,

used to indicate risk of property damage.

Indicates a hazard that would be assigned a signal word

WARNING or CAUTION.

DANGER

WARNING

CAUTION

N OTIC E

If it needs to install, move or maintain the air conditioner, please contact dealer

or local service center to conduct it at first. Air conditioner must be installed,

moved or maintained by appointed unit. Otherwise, it may cause serious

damage or personal injury or death.

When refrigerant leaks or requires discharge during installation, maintenance,

or disassembly, it should be handled by certified professionals or otherwise in

compliance with local laws and regulations.

The Refrigerant

WARNING：

To realize the function of the air conditioner unit, a special refrigerant circulates in

the system. The used refrigerant is R32.

The refrigerant is mildly flammable and inodorous. Furthermore, it can lead to explosion

under certain conditions. But the flammability of the refrigerant is very low. It can

be ignited only by fire.

Compared to common refrigerants, R32 is no harm to the ozonosphere.

The influence upon the greenhouse effect is also lower. R32 has got very good

thermodynamic features which lead to a really high energy efficiency.

The units therefore need a less filling.

Do not use means to accelerate the defrosting process or to clean, other than those

recommended by the manufacture. Should repair be necessary, contact your nea-

rest authorized Service Centre. Any repairs carried out by unqualified personnel

may be dangerous. The appliance shall be stored in a room without continuously

operating ignition sources. (for example: open flames, an operating gas appliance

or an operating electric heater.) Do not pierce or burn.

For repairs, strictly follow manufacturer’s

instructions only.

Be aware that refrigerants may not containan odour. Read specialist’s

manual.

The appliance is using mildly flammable refrigerant R32 and tested to comply with

IEC 60335-2-40. There is no minimum room area requirement for the appliance.

WARNING:Appliance filled with mildly flammable refrigerant R32.

If the refrigerant is leaked and exposed to external ignition source,

there is a risk of fire.

CAUTION:Before use the appliance,read the user's manual first.

CAUTION:Information is available such as the user's manual first.

CAUTION:Before repair the appliance ,read the service manual first.

Model

refrigerant charge

(kg)

maximum refrigerant charge

(kg)

minimum installation height

(m)

minimum room area

(m2)

GSY09BXAE/

GSY09BXAC

1.00 1.16 1.80 No minimum room area requirement

GSY12BXAE/

GSY12BXAC

1.00 1.24 1.80 No minimum room area requirement

GSY18BXAE/

GSY18BXAC

1.20 1.52 1.80 No minimum room area requirement

Precautions

Operation and Maintenance

This appliance can be used by children aged from 8

years and above and persons with reduced physical,

sensory or mental capabilities or lack of experience

and knowledge if they have been given supervision or

instruction concerning use of the appliance in a safe

Children shall not play with the appliance.

Cleaning and user maintenance shall not be made by

children without supervision.

conditioner. Otherwise, it may cause electric shock.

If the supply cord is damaged, it must be replaced by

electric shock.

shock or malfunction.

Do not block air outlet or air inlet. It may cause

malfunction.

remote controller may be broken.

●Power cord is overheating or damaged.

●There’s abnormal sound during operation.

●Circuit break trips off frequently.

●Air conditioner gives off burning smell.

●Indoor unit is leaking.

contact the dealer or qualified professionals for service.

When turning on or turning off the unit by emergency

operation switch, please press this switch with an insulating

object other than metal.

outlet. It may cause personal injury or damage.

Precautions

WARNING

conditioner and disconnect power immediately, and then

If the air conditioner operates under abnormal conditions,

it may cause malfunction, electric shock or fire hazard.

Do not spill water on the remote controller, otherwise the

electric shock or damage. Please contact dealer when

you need to repair air conditioner.

Do not repair air conditioner by yourself. It may cause

objects. It may cause damage or personal injury.

Do not step on top panel of outdoor unit, or put heavy

When below phenomenon occurs, please turn off air

Do not extend fingers or objects into air inlet or air

Maintenance must be performed by qualified

professionals. Otherwise, it may cause personal injury

or damage.

Do install the circuit break. If not, it may cause malfunction.

An all-pole disconnection switch having a contact separation

of at least 3mm in all poles should be connected in fixed

wiring.

According to the local safety regulations, use qualified

power supply circuit and circuit break.

Precautions

WARNING

Must follow the electric safety regulations when installing

the unit.

Make sure the power supply matches with the requirement

of air conditioner.Unstable power supply or incorrect wiring

may result in electric shock, fire hazard or malfunction.

Please install proper power supply cables before using the

air conditioner.

Properly connect the live wire, neutral wire and

grounding wire of power socket.

Be sure to cut off the power supply before proceeding

any work related to electricity and safety.

Don't use unqualified power cord.

Installation must be performed by qualified professionals.

Otherwise, it may cause personal injury or damage.

Including an circuit break with suitable capacity, please

note

the following table.Air switch should be included

magnet buckle

and heating buckle function, it can protect

the circuit-short and

overload.

Air Conditioner should be properly grounded. Incorrect

grounding may cause electric shock.

Attachment

Installation must be performed in accordance with the

persons in order to avoid a hazard.

must be properly grounding with specialized grounding

device by a professional. Please make sure it is always

grounded effectively, otherwise it may cause electric shock.

The appliance must be positioned so that the plug is

accessible.

If the length of power connection wire is insufficient, please

contact the supplier for a new one. Avoid extending the

wire by yourself.

All wires of indoor unit and outdoor unit should be

connected by a professional.

national wiring regulations.

requirement of NEC and CEC by authorized personnel

only.

Precautions

WARNING

wire, which can't be used for other purposes.

The grounding resistance should comply with national

electric safety regulations.

The air conditioner is the first class electric appliance. It

keep the interconnection cable away from the copper

tube.

The temperature of refrigerant circuit will be high, please

the manufacturer, its service agent or similarly qualified

If the supply cord is damaged, it must be replaced by

The yellow-green wire in air conditioner is grounding

The appliance shall be installed in accordance with

Do not put through the power before finishing installation.

The indoor unit should be installed close to the wall.

Instructions for installation and use of this product are

provided by the manufacturer.

Precautions

WARNING

place, only the qualified person can perform the work.

Otherwise, it may cause personal injury or damage.

If you need to relocate the air conditioner to another

must be installed in the line.

For the air conditioner without plug, an circuit break

far away from animals or plants.If it is unavoidable,

please add the fence for safety purpose.

Select a location which is out of reach for children and

reachable after finishing installation.

For the air conditioner with plug, the plug should be

Working temperature range

Outdoor side DB/WB(°C)Indoor side DB/WB(°C)

Maximum cooling 32/23 48/26

Maximum heating 27/- 24/18

NOTICE:

●The operating temperature range (outdoor temperature) for Low-temperature

cooling only unit is -15°C~ 48°C; for Low-temperature heat pump unit is

-25°C~ 48°C.

Ce manuel convient aux modèles suivants

Table des matières

Autres manuels Gree Climatiseur

Gree

Gree GJC10BL-A6NRNE2D Manuel utilisateur

Gree

Gree GPE12AF-K3NNA7A Manuel utilisateur

Gree

Gree GVC24AMXF-K3NTC7A Manuel utilisateur

Gree

Gree FP-22LM/D-K Manuel utilisateur

Gree

Gree GMV-N140U/A-T Manuel utilisateur

Gree

Gree GMV-ND07PLS/B-T Manuel utilisateur

Gree

Gree GWH07QB-K6DNB2E/O Manuel utilisateur

Gree

Gree GWH(09)MA-K3DNA2B Manuel utilisateur

Gree

Gree Feng Yun Series Manuel utilisateur

Gree

Gree GMV5 Series Manuel utilisateur

Gree

Gree GWCN24 B9NK1BA Manuel utilisateur

Gree

Gree G-TECH Series Manuel utilisateur

Gree

Gree Sapphire SAP24HP230V1A Manuel utilisateur

Gree

Gree GJC08BK-A6NRNC5B Manuel utilisateur

Gree

Gree GWC18KG-K3DNA5A Manuel utilisateur

Gree

Gree GWH09MB-D3DNA3D Manuel utilisateur

Gree

Gree GWC18KG-K3DNA5A Manuel utilisateur

Gree

Gree GWH09AB-A3DNA1B Manuel utilisateur

Gree

Gree Livo+ LIVS09HP230V1B Manuel utilisateur

Gree

Gree GMV-140WL/A-T Manuel utilisateur

Gree

Gree GWH07PA-K3NNA6E Manuel utilisateur

Gree

Gree GWH07AGA-K6DNA1A/I Manuel utilisateur

Gree

Gree GWH09QB-K3DNA6D Manuel utilisateur

Gree

Gree GWC07NA-K3NNB1A Manuel utilisateur

Manuels Climatiseur populaires d'autres marques

Spheros

Spheros CC 355 Manuel utilisateur

Bosch

Bosch Climate 5000 SCI 24 CAS/ OU- OUE Manuel utilisateur

Panasonic

Panasonic CS-E12HKEW Manuel utilisateur

nedis

nedis ACMB1WT7 Manuel utilisateur

Samsung

Samsung AR KV Series Mode d’emploi

Daikin

Daikin FCFV50A Manuel utilisateur

Fujitsu

Fujitsu Inverter ASBA30JFC Manuel utilisateur

Toshiba

Toshiba RAS-M10SMUV-E Manuel utilisateur

Daikin

Daikin FXLQ20MAVE Manuel utilisateur

Hitachi

Hitachi RAS-E24CAK Manuel utilisateur

CIAT

CIAT Magister 2 Series Mode d’emploi

Bestron

Bestron AAC6000 Manuel utilisateur

Hisense

Hisense 7K Manuel technique

Frigidaire

Frigidaire FFRE0533S1E0 Manuel utilisateur

Samsung

Samsung AS09HM3N Manuel utilisateur

Frigidaire

Frigidaire CRA073PU11 Manuel du propriétaire

Soleus Air

Soleus Air GB-PAC-08E4 Manuel utilisateur

McQuay

McQuay MCK020A Manuel utilisateur
