Accessories/

Attachments

Standard:

FOLDABLE ROPS

SUSPENSION SEAT

Optional:

55" SNOW BLOWER

60” ROTAR Y SWEEPER

60” SNOW BLADE

3-BUCKET X-TREME

FLO™ BAGGER

BAR STYLE TIRE KIT

DISCHARGE COVER KIT

ELECTRIC DECK LIFT KIT

FLEXTEND™ SHOULDER

SUPPORT SYSTEM

HEADLIGHT KIT

LIFT MASTER®

MULCHING KIT

OPERATOR CONTROLLED

CHUTE BAFFLE

POWERED BAGGER KIT

SOLID FRONT TIRE KIT

STRIPING KIT

VACUUM BAFFLE

WHEEL COVERS

• Lockable, oating front axle easily adjusts to uneven terrain for

added stability and operator comfort

• 7-Gauge fabricated and welded X-Factor® deck design assures

lasting strength and durability

• Maintenance-free XL Spindles® with durable cast iron housings

• Adjustable anti-scalp rollers and hardened steel blades eciently

integrate for a beautifully manicured nish.

• 1/2” Wear bar and two additional gussets guard against leading

edge or bae bending

• Industry leading 1-1/4” front caster forks enhance

maneuverability

• Large diameter steering arms and vibration isolators add operator

comfort and control

• Ergonomically designed cockpit with comfort-grip handles,

easy-access controls

• Suspension seat with adjustable armrests elevates operator

productivity by minimizing fatigue.

• Available in several fuel source options including liqueed

petroleum (LP) that burns cleaner which reduces emissions and

lowers engine maintenance.

• Hydraulic or mechanical deck lift available

Pro-Master™ 200 XDZ Series

PROFESSIONAL

WarrantyWarranty

3 Year

XL Spindle®

3 Year

XL Spindle®

WarrantyWarranty

HARDWORKING, HEAVY IRON, THAT

DOESN’T KNOW THE MEANING OF

DOWNTIME.

PRO-MASTER™ 200 XDZ SERIES

PRODUCT NAME 252M 260M 260H 260H 266H 272H 260H LP 260H 272H

MODEL NUMBER 992191 992188 992189 992190 992192 992193 992194 992195 992196

ENGINE

Kawasaki® FX Kawasaki® FX Kawasaki® FX Kohler®

Command Kawasaki® FX Kawasaki® FX Generac® Briggs & Stratton® - Daihatsu®

Air-cooled Verticak Twin Liquid-cooled

Horizontal Diesel”

Heavy-Duty Air Cleaner

HORSEPOWER 27 27 27 27 31 31 28 27 31

DISPLACEMENT (cc) 852 852 852 725 852 852 992 950 950

DRIVE SYSTEM Hydro-Gear 21cc Pump with Parker 18 c.i. Wheel motors

FUEL CAPACITY - Gallons (LITERS) 13 gallon (49L) 13 gallon (49L) 13 gallon (49L) 13 gallon (49L) 13 gallon (49L) 13 gallon (49L)

Twin 33.5 lb

LP Tanks

(Not Included)

13 gallon (49L) 13 gallon (49L)

GROUND SPEED (APPROX. Mph)

(Forward/Reverse) 13 mph/6 mph 13 mph/6 mph 13 mph/6 mph 13 mph/6 mph 13 mph/6 mph 13 mph/6 mph 13 mph/6 mph 13 mph/6 mph 13 mph/6 mph

STARTER Electric Electric Electric Electric Electric Electric Electric Electric Electric

DECK

DECK MATERIAL 7 ga steel with .25 inch spindle reinforcement

DECK CONSTRUCTION Welded Welded Welded Welded Welded Welded Welded Welded Welded

NUMBER OF SPINDLES 333333333

BLADE TIP SPEED (FPM) 18,000 18,000 18,000 18,000 18,000 18,000 18,000 18,000 18,000

SPINDLE HOUSING MATERIAL Cast Iron Cast Iron Cast Iron Cast Iron Cast Iron Cast Iron Cast Iron Cast Iron Cast Iron

SPINDLE SHAFT Steel Steel Steel Steel Steel Steel Steel Steel Steel

SPINDLE BEARINGS Ball Bearing Ball Bearing Ball Bearing Ball Bearing Ball Bearing Ball Bearing Ball Bearing Ball Bearing Ball Bearing

DECK DRIVE Belt Belt Belt Belt Belt Belt Belt Belt Belt

DECK ENGAGEMENT Ogura GT3.5 Electric Clutch

DECK LIFT SYSTEM Foot Operated Foot Operated Hydraulic Hydraulic Hydraulic Hydraulic Hydraulic Hydraulic Hydraulic

CUTTING WIDTH 52 60" 60" 60" 66" 72" 60" 60" 72"

CUTTING HEIGHTS 1"-5" 1"-5" 1"-5" 1"-5" 1"-5" 1"-5" 1"-5" 1"-5" 1"-5"

CUTTING POSITIONS 17 9 17 17 17 17 17 17 17

WHEELS

FRONT AXLE Pivoting/Locking

FRONT Ribbed 15 x 6-6

REAR Turf 24 x 11.5-12

FEATURES

HOOD Standard

SEAT High Back w/ Full Suspension

HOUR METER Standard

MACHINE DIMENSION

WEIGHT (lbs) 1272 TBD TBD TBD TBD TBD TBD TBD 1677

LENGTH (inches) 82 82 82 82 82 82 82 83.5 83.5

WIDTH (inches) 55.5 w/o chute 63 w/o chute 69 w/o chute 75 w/o chute 63 w/o chute 63 w/o chute 75 w/o chute

HEIGHT W/ ROPS EXT/DOWN

(inches) 72/48 72/48 72/48 72/48 72/48 v72/48 72/48 72/48 72/48

WARRANTY

UNIT 2 Year Limited Commercial

DECK SHELL & FRAME Limited Lifetime Deck Shell & Frame

SPINDLES 3 Year Limited Spindle

are registered trademarks of their respective companies. The engine horsepower information is provided by the engine manufacturer to be used for comparison purposes only. Actual operating

horsepower will be less. Visit www.ariens.com for a complete listing of engine manufacturer power rating information. Product features and specications subject to change without notice.

Photos are a representation of product; product may dier.

WWW.GRAVELY.COM
