USER'S MANUAL

MOUNTCORDER

MANUAL NO. MT100-UM-151

Introduction

Thank you for purchasing the MOUNTCORDER MT100.

Please read this manual thoroughly before attempting to use your new product to ensure that you use it

correctly and to its full potential.

Notes on Use

Be sure to read all of the following notes before attempting to use the MT100 MOUNTCORDER.

1. Note on the CE Marking

The MT100 complies with the EN61326 Class A standard based on the EMC directive (89/336/EMC). It also

conforms to the EN61010-1 standard based on the LV directive (72/73/EEC).

Although the MT100 complies with the above-mentioned standards, be sure to use it correctly in accordance

with the instructions and notes provided in its User's Manual.

Moreover, use of the MT100 by incorrect procedures may result in damage to the MT100 or may invalidate

its safeguards. Please confirm all of its notes regarding use and other related information to ensure correct

use.

2. Warning

This is a Class A product according to the EMC directive.

In a domestic environment, this product may cause radio interference or may be affected by radio

interference to the extent that proper measurement cannot be performed.

3. Notes for Safe Operation

(1) In environments where there is a lot of noise or where the power supply is unstable, we recommend that

you ground the MT100.

(2) When a high-voltage signal cable has been connected to the main unit's analog signal input terminal,

avoid touching the leads of the input terminal's signal cable to prevent electrical shock due to high

voltage.

(3) Ensure that the MT100's power source is positioned so that it can easily be disconnected.

4. Notes on Functions and Performance

(1) Be sure to connect the main unit to an AC power supply that conforms to the rated range.

Connection to a non-rated power supply may cause the main unit to overheat and break down.

(2) Do not block the vent on the main unit.

Continued operation with the vent blocked may cause the main unit to overheat and break down.

(3) To avoid malfunctions and other damage, avoid using the MT100 in the following locations.

• Places exposed to high temperature and/or high humidity, such as in direct sunlight or near heating

equipment. (Operating range - Temperature: 0 to 50°C, Humidity: 5 to 85% RH)

• Locations subject to excessive salt spray or heavy fumes from corrosive gas or solvents.

• Excessively dusty locations.

• Locations subject to strong vibrations or shock.

• Locations subject to surge voltages and/or electromagnetic interference.

(4) If the main unit becomes soiled, wipe it off using a soft, dry cloth. Use of organic solvents (such as

thinner or benzene) causes deterioration and discoloration of the outer casing.

Introduction

(5) Do not use the MT100 in the vicinity of other devices which are susceptible to electromagnetic

interference.

(6) Measured results may not conform to the stated specifications if the MT100 is used in an environment

which is subject to strong electromagnetic interference.

(7) Insofar as possible, position the MT100 input signal cables away from any other cables which are likely

to be affected by electromagnetic interference.

(8) For stabilized measurement, allow the MT100 to warm up for at least 30 minutes after turning it on.

To Ensure Safe and Correct Use

iii

To Ensure Safe and Correct Use

• To ensure safe and correct use of the MT100, read this Manual thoroughly before use.

• After having read this Manual, keep it in a handy location for quick reference as needed.

• Do not permit small children to touch the MT100.

• The following describes important points for safe operation. Please be sure to observe them strictly.

Conventions Used in This Manual

To promote safe and accurate use of the MT100 as well as to prevent human injury and property damage,

safety precautions provided in this manual are ranked into the five categories described below. Be sure you

understand the difference between each of the categories.

DANGER

This category provides information that, if ignored, is highly likely to cause fatal or serious injury to

the operator.

WARNING

This category provides information that, if ignored, is likely to cause fatal or serious injury to the

operator.

CAUTION

This category provides information that, if ignored, could cause physical damage to the MT100.

HIGH TEMPERATURE

This category provides information that, if ignored, is likely to cause burns or other injury to the

operator due to contact with high temperature.

ELECTRICAL SHOCK

This category provides information that, if ignored, is likely to expose the operator to electrical

shock.

Description of Safety Symbols

The symbol indicates information that requires careful attention (which includes warnings).

The point requiring attention is described by an illustration or text within or next to the symbol.

The symbol indicates action that is prohibited. Such prohibited action is described by an

illustration or text within or next to the symbol.

The symbol indicates action that must be performed. Such imperative action is described by an

illustration or text within or next to the symbol.

Safety Precautions

WARNING

Be sure to securely connect the MT100's power cord.

• After checking that the Power switch is turned off, connect the power cord's

female plug to the MT100 and then connect its male plug into the electrical

socket.

• Use of the MT100 without the power cord securely plugged into the

electrical socket may result in electrical shock due to current leakage.

If the MT100 generates smoke, is too hot, emits a strange odor, or otherwise functions abnormally, turn off

the Power switch and power source, and disconnect the power cable.

• Use of the MT100 in such status may result in a fire hazard or electrical

shock.

• After checking that smoke is no longer being generated, contact your sales

representative or nearest Graphtec vendor to request repair.

• Never try to perform repair yourself. Repair work by inexperienced

personnel is extremely dangerous.

Before turning on the MT100, ensure that the electric socket's supply voltage conforms to the MT100's

power rating.

• Use of a different supply voltage may cause damage to the MT100 or a fire

hazard due to electrical shock or current leakage.

Never disassemble or remodel the MT100.

• Such action may cause a fire hazard due to electric shock or current

leakage.

• Contact with a high-voltage component inside the MT100 may cause

electric shock.

• If repair is required, contact your sales representative or nearest Graphtec

vendor.

Avoid using the MT100 in extremely dusty or humid places.

• Such use may cause a fire hazard due to electrical shock or current

leakage.

Securely connect the power cord

Make sure that the socket has a good

protective ground

Use of a different

supply voltage

prohibited

Amateur repair

prohibited

No disassembly

Use prohibited

Watch out for

electrical shock

Safety Precautions

WARNING

Avoid using the MT100 in places where it may be exposed to water such as bathrooms, locations exposed

to wind and rain, and so on.

Prevent dust or metallic matter from adhering to the power supply connecter and power terminal.

• Adhesion of foreign matter may cause a fire hazard due to electrical shock

or current leakage.

Never use a damaged power cord.

• Use of a damaged cord may result in a fire hazard due to electrical shock.

• If the cord becomes damaged, order a new one to replace it.

Avoid water

Watch out for

electrical shock

Unplug the power

cord from the socket

No foreign matter

Watch out for

electrical shock

Safety Precautions

CAUTION

Do not use or store the MT100 in a location exposed to direct sunlight or the direct draft of an air

conditioner or heater.

• Such location may impair the MT100's performance.

Do not place coffee cups or other receptacles containing fluid on the MT100.

• Fluid spilling inside the MT100 may cause a fire hazard due to electrical

shock or current leakage.

Do not use the MT100 in a location subject to excessive mechanical vibration or electrical noise.

• Such location may impair the MT100's performance.

To insert or disconnect the power cord or a signal input cable, grasp the power cord's plug or the signal

input cable's connector.

• Pulling the cord/cable itself damages the cord/cable, resulting in a fire

hazard or electrical shock.

If fluid or foreign matters enters inside the MT100, turn off the Power switch and power source, and

disconnect the power cable.

• Use in such status may cause a fire hazard due to electrical shock or

current leakage.

• Contact your sales representative or nearest Graphtec vendor to request

repair.

Do not input voltage that exceeds the permissible input voltage range that is specified on the MT100's

label.

• Exceeding the specified voltage input range may cause electrical shock or

a fire hazard.

Storage/Use prohibited

Use prohibited

Unplug the power

cord from the socket

No pulling

Use prohibited

Avoid fluids

Watch out for

electrical shock

Safety Precautions

vii

Do not attempt to lubricate the MT100's mechanisms.

• Such action may cause the MT100 to break down.

Never clean the MT100 using a volatile solvent (such as thinner or benzine).

• Such action may impair the MT100's performance.

• Clean off any soiled areas using a soft dry cloth.

Safety Precautions

CAUTION

No lubrication

No volatile solvents

viii
