Grandstream Networks HA100 Manuel utilisateur
For Warranty and RMA information, please visit www.grandstream.com
HA100
High Availability Kit for UCM6510
Quick Installation Guide
Grandstream Networks, Inc.
126 Brookline Ave, 3rd Floor
Boston, MA 02215. USA
Tel : +1 (617) 566 - 9300
Fax: +1 (617) 249 - 1987
www.grandstream.com
Content
English..............................................................................1
~ 2 ~~ 1 ~
PACKAGE CONTENTS
PRECAUTIONS:
• Do not attempt to open, disassemble, or modify the device.
• Do not use a third party power adapter.
• Do not expose this device to temperatures outside the range of 0 °C to +40 °C
for operating or -10 °C to +60 °C for storage.
• Do not expose this device to environment outside of the following humidity range:
10-90% RH (non-condensing).
1 x HA100 Main Case
1 x 12V Power Adapter
OVERVIEW
HA100 works with UCM6510 to achieve High Availability function. It contains a set
of external ports and splits each of them into two internal ports: Port A and Port B.
The ports on the 2 UCM6510s should be connected to each Port A and Port B re-
spectively. The external ports on the HA100 provide PBX service. Powered by an
advanced hardware platform and revolutionary software functionality, the connec-
tion between the UCM6510 and HA100 offers a breakthrough turnkey solution for
converged voice, video, data, fax, security surveillance, and mobility applications
out of the box without any extra license fees or recurring costs.
1 x Quick Installation Guide
HA100 INTERFACES
2x LAN
Ports
4x FXO
Ports
2x WAN
Ports
The front panel contains the internal HA100 ports:
• 1 pair of internal WAN ports (WAN-A, WAN-B).
• 1 pair of LAN ports (LAN-A, LAN-B).
• 1 pair of T1/E1/J1 ports (T1/E1/J1-A, T1/E1/J1-B).
• 2 pairs of internal FXS ports (FXS 1-A, FXS 1-B, FXS 2-A, FXS 2-B).
• 2 pairs of internal FXO ports (FXO 1-A, FXO 1-B, FXO 2-A, FXO 2-B).
HA100 Front Panel
Ports LEDs
Indication
2 x FXS
Ports
LAN
Port
2 x FXO
Ports
RS-485
Ports
The back panel contains the external HA100 ports:
HA100 Back Panel
Power
Port (12V)
WAN
Port Ground
2xT1/E1/J1
Ports
T1/E1/J1
Ports
12V
2 x USB-to-RS485 Cable
• 2 RS-485 Ports.
• 1 Power Port 12V.
• Reset Pin.
• Ground.
• 2 FXS ports.
• 2 FXO ports.
• 1 WAN port.
• 1 LAN port.
• 1 T1/E1/J1 port.
4x FXS
Ports
~ 4 ~~ 3 ~
Powering and Connecting the HA100
Please refer to following steps for the basic connection setup of the HA100:
1. Connect one end of the Ethernet cable to the WAN port of the HA100 and the
other end to the RJ45 port of uplink of a hub or switch.
2. Connect 12V power adapter to the 12V power port on HA100 and the other end
to power jack.
HA100 CONNECTION
Optional Connection
1. For PSTN connection: Connect a PSTN cable to the FXO external port on
HA100.
2. For Analog phone/Fax connection: Connect analog phone or FAX machine
to the FXS external port on HA100.
3. For T1/E1/J1 connection: Connect T1/E1/J1 cable from the service provider
side to the T1/E1/J1 external port on HA100.
4. For LAN connection: Connect one end of the Ethernet cable to the LAN ex-
ternal port on HA100 and the other end to switch, hub or etc.
CONNECTING HA100 WITH 2 UCM6510
The following steps and diagram illustrate the connection between the HA100 and
2 UCM6510:
1. Connect the FXO port, FXS port, E1/T1/J1 port, WAN port and LAN port on
UCM6510 A to the FXO-A port, FXS-A port, E1/T1/J1-A port, WAN-A port and
LAN-A port on HA100.
2. Use the USB-to-RS485 serial cable to connect UCM6510 A’s USB port to the
RS485-A port on HA100.
3. Connect the FXO port, FXS port, E1/T1/J1 port, WAN port and LAN port on
UCM6510 B to the FXO-B port, FXS-B port, E1/T1/J1-B port, WAN-B port and
LAN-B port on HA100.
4. Use the USB-to-RS485 serial cable to connect UCM6510 B’s USB port to the
RS485-B port on HA100.
UCM 6510 A
UCM6510 B
HA 100
12V
Network Port Power Port
In this scenario, the HA100 separates the external port into the corresponding
internal ports (A and B). By default, Port A is always connected, and Port B is al-
ways disconnected. Only one UCM device is connected at any given time. If the
primary UCM (UCM6510 A) detects issues within itself, it will signal the HA100
via USB-to-RS485 cable to switch connection from Port A to Port B. The backup
UCM (UCM6510 B) will then be successfully connected and resume service.
Please refer to following diagram for more details.
