Gram Precision K2P Series Manuel utilisateur
1
USER MANUAL
MANUAL DE UTILIZACION
MANUEL D´UTILISATION
SERIES / SERIE / SÉRIE K2P
REV. 2A11M103T
2
3
INDEX
Specifications
5
Power
5
Before using
5
System power consumption
5
Low power warning
5
Displays description
6
Keyboard description
6
Description of keys
7
Basic functions and operation
8
- Tare function
8
- Accumulation
8
- Add up function
8
- Payment change
8
- P1/P2 Price look up (PLU)
8
- Save the price look up (PLU)
9
Error messages
9
Guarantee
9
EC Declaration of Conformity
20
INDICE
Especificaciones
10
Alimentación
10
Antes de su utilización
10
Consumo
10
Aviso de batería baja
10
Descripción del display
11
Descripción del teclado
11
Descripción de las teclas
12
Funciones básicas
13
- Función de tara
13
- Acumulación de pesadas
13
- Función de suma
13
- Cambio a devolver
13
- Selección de PLU´s
13
- Introducción de PLU´s
14
Mensajes de error
14
Garantía
14
Declaración CE de Conformidad
20
4
SOMMAIRE
Spécifications
15
Alimentation
15
Avant d´utiliser
15
Consommation
15
Avis de batterie faible
15
Description de l´écran
16
Description du clavier
16
Description des touches
17
Fonctions fondamentales
18
- Fonction de Tare
18
- Accumulation de pesées
18
- Récuperation d´accumulations
18
- Fonction de somme
18
- Montant à render au client
18
- Enregistrer le prix dans une PLU´s
18
- Sélection de PLU´s
19
Messages d´erreur
19
Garantie
19
Declaration CE de Conformité
20
5
SPECIFICATIONS
Accuracy: Class III
Loadcell sensitivity range: 1.5
~
3.0mV/V
Nonlinear: ≤0.01%F.S
System working voltage: DC:5V
Division value: 1/2/5 auto setting
Large LCD display connector: Sampling serial output way
Sample rate: 20 times per second (can select)
Internal resolution: 300000
~
600000
POWER
Input: 120
~
240V
Output: 12
V/
1A
Rechargeable battery: 6
V/
4AH
BEFORE USING
1) Place this product on a firm and smooth place, don´t place it in vibration or
shaking, use bench for use on four only adjust foot, adjust the balance using the
bubble level.
2) Use independent source, avoid other electrical disturbance.
3) Don’t put any object on the platter when turn on the balance.
4) Please, turn on 2-3 minutes before using.
5) Avoid temperature change too large and air flow strenuous sites.
6) Don’t overload the balance, don’t exceed the maximal capacity.
SYSTEM POWER CONSUMPTION
Main system power consumption: about 12mA
Main system power consumption (with backlight): about 36mA
Main system power consumption (with backlight and RS-232): about 48mA
Battery life: none backlight, about 320 hours.
LOW POWER WARNING
When the battery voltage is below 5.6V, the low power indicator on the LCD display will
light up.
When the battery voltage is below 5.5V, the low power indicator on the LCD display will
start to flash.
When the battery voltage is below 5.5V, the scale will turn off.
6
DISPLAYS AND KEYBOARD DESCRIPTION
DESCRIPTION OF KEYS
Press and hold this key for 2 seconds to turn off the balance.
Press this key to turn on the balance
Accumulation key, use it to accumulate up to 20 data of weight, unit price
and total price.
Accumulation recall key, use it to recall and view data by data or
accumulated weights, unit price and total price.
Memory clear key, press it at accumulation recall mode to clear single
accumulated data. At weighing mode will clear all accumulated data at
once.
Tare key, to subtract the weight of a container (tare range: full capacity)
Quantity key, after a unit price has been entered, press this key then enter
how many pieces and the total price will be calculated (up to 99 pieces)
7
Add key, to add up unit price or total price.
Change key, to calculate the change for customer
Zero key, to reset the residual weight back to zero (only when the display
weight is less than +/- 2% of the max. capacity)
Clear key, to clear unit price.
Price look up key, to save unit price (for detail refer to “save the price look
up)
Group key: to switch between P1-P10 and P11-P20
BASIC FUNCTIONS AND OPERATION
Tare function.
Place a container on the platter and press the key, the weight of container will
be deducted. After a tare you will be able to weigh any object as its net weight.
Accumulation
Press the key to accumulate up to 20 data of weight and unit price. Must have
object to be weighed and unit price entered to be able to accumulate.
Recall accumulated data
Press the key to recall and view data of accumulated weight, unit price and
total price.
For example: If have accumulated three data, press the key to view the first
saved data. Press the key again to view the second saved data and third time
to see the third data, finally, press the key to view the total accumulated value
of all three data.
8
Add Up Function
Press the key for known unit price or total price to add up unit price or total
price.
Weight window shows added times.
Payment change
Press the key and enter the payment amount, the scale will automatically
calculate the charge for customer.
Example: The total price is 15 Euro, press this key and enter 20 Euro, on the Unit
Price window will be displayed 5 Euro as the change for customer
P1*/P2 Price Look Up (PLU)
Press the key to select between PLU group 1 (P01 – P20) and PLU group 2
(P21 – P40).
The display will light up the group selected.
Save the Price Look Up (PLU)
Enter the desired unit price and press the key, then press one of the 20 PLU
memories (P01 – P10), the unit price will be saved in the appointed number.
To change save unit price, just repeat the same steps.
ERROR MESSAGES
Err H lnitial zero too high (over 10% of max. cap)
Err L Initial zero too low (less than 10% of max. cap)
Err N Unstable internal value
hhhhhh Overload, over the max. capacity + 9d
------ Total price exceeded 999999
9
GUARANTEE
This balance is guaranteed for one year from the delivery date. The guarantee covers
any fabrication defect of the material.
During this period, GRAM PRECISION covers the manpower and the spare parts
necessary to repair the scale.
This guarantee does not cover the failures caused by an inappropriate use or
overload.
The guarantee does not cover the freight cost (transport) necessary to repair
the balance.
10
ESPECIFICACIONES
Precisión: Clase III
Rango de sensibilidad de la célula carga: 1.5
~
3.0mV/V
Nonlinear: ≤0.01%F.S
Voltaje: DC:5V
División: 1/2/5 (seleccionable)
Conector del display LCD: Forma de salida en serie
Frecuencia de muestreo: 20 veces por segundo (seleccionable)
Resolución interna: 300000
~
600000
ALIMENTACION
Entrada: 120
~
240V
Salida: 12
V/
1A
Batería recargable: 6
V/
4AH
ANTES DE SU UTILIZACION
1) Situar la balanza sobre una superficie firme y llana, no exponerla en ambientes
con vibraciones, nivelar la balanza utilizando el nivel de burbuja.
2) Utilizar una fuente eléctrica independiente, evitar perturbaciones eléctricas.
3) No colocar ningún objeto sobre la plataforma en el momento de poner en marcha
el indicador.
4) Por favor, permita que la balanza se precaliente durante 2-3 minutos antes de su
utilización.
5) Evitar cambios de temperatura muy bruscos y corrientes de aire.
6) No sobrecargar la balanza, nunca exceder la capacidad máxima.
CONSUMO
Consumo normal: approx. 12mA
Consumo con la retroiluminación: aprox. 36mA
Consumo con la retroiluminación y salida RS-232: aprox. 48mA
Duración de la batería: sin la retroiluminación, aprox. 320 horas.
AVISO DE BATERIA BAJA
Cuando el voltaje de la batería es inferior a 5.6V, el indicador de batería baja se activa
en el display.
Cuando el voltaje de la batería es inferior a 5.5V, el indicador de batería baja se activa
en el display.
