Gradus Group POLSEN DM-USX1 Manuel utilisateur
DM-USX1
DYNAMIC
MICROPHONE
WITH XLR AND USB OUTPUTS
PRODUCT
MANUAL
2
USB
ON
OFF
1. USB LED indicator
• Lights up to indicate connection to a powered USB port.
2. On/off switch
• The Off position mutes the microphone.
3. Headphone volume control
• Press +to increase the headphone volume, and -to
decrease the volume.
4. Mini-USB connector
• Use the included USB cable to connect the microphone
to a computer or recorder.
Note:You may need to adjust your computer’s audio
settings to receive signal from the microphone.
5. Headphone output
• Connect a headphone’s 1/8 in. (3.5 mm) plug for
latency-free monitoring.
6. XLR connector
• Use an XLR cable (not included) to connect the
microphone to a mixer or PA system.
7. USB cable
• Mini-USB to USB Standard-A cable.
8. Mic clip
9. Tripod desk stand
1
7
OVERVIEW
2
3 6
8
9
54
3
TRANSDUCER Dynamic
POLAR PATTERN Supercardioid
FREQUENCY RESPONSE 50 Hz to 16 kHz
IMPEDANCE 600 Ω ±30 % @ 1 kHz
OUTPUT CONNECTOR 3-pin XLR, Mini-USB
CABLE LENGTH 6.6 ft. (2 m)
HEIGHT 7.5 in. (19.1 cm)
DIAMETER 2.25 in. (5.7 cm)
WEIGHT 12.4 oz. (352 g)
SPECIFICATIONS
4
ONE-YEAR LIMITED WARRANTY
This Polsen product is warranted to the original purchaser to be free from defects in materials and workmanship under normal
consumer use for a period of one (1) year from the original purchase date or thirty (30) days after replacement, whichever occurs
later. The warranty provider’s responsibility with respect to this limited warranty shall be limited solely to repair or replacement, at the
provider’s discretion, of any product that fails during normal use of this product in its intended manner and in its intended environment.
Inoperability of the product or part(s) shall be determined by the warranty provider. If the product has been discontinued, the warranty
provider reserves the right to replace it with a model of equivalent quality and function.
This warranty does not cover damage or defect caused by misuse, neglect, accident, alteration, abuse, improper installation or
maintenance. EXCEPT AS PROVIDED HEREIN, THE WARRANTY PROVIDER MAKES NEITHER ANY EXPRESS WARRANTIES NOR ANY
IMPLIED WARRANTIES, INCLUDING BUT NOT LIMITED TO ANY IMPLIED WARRANTY OF MERCHANTABILITY OR FITNESS FOR A
PARTICULAR PURPOSE. This warranty provides you with specic legal rights, and you may also have additional rights that vary from
state to state.
To obtain warranty coverage, contact the Polsen Customer Service Department to obtain a return merchandise authorization (“RMA”)
number, and return the defective product to Polsen along with the RMA number and proof of purchase. Shipment of the defective
product is at the purchaser’s own risk and expense.
For more information or to arrange service, visit www.polsenaudio.com or call Customer Service at 212-594-2353.
Product warranty provided by the Gradus Group.
www.gradusgroup.com
Polsen is a registered trademark of the Gradus Group. ©2020 Gradus Group LLC. All Rights Reserved.
GG1
