3A1291A
Operation
18V Lithium Ion
Portable Battery Charger
- For use with all ProShot™and TrueCoat Pro™sprayer batteries -
IMPORTANT SAFETY INSTRUCTIONS
For complete warnings and safety
instructions, see sprayer manual.
SAVE THESE INSTRUCTIONS.
ENG
ti16590a
Model 16F628
WARNINGWARNINGWARNING
WARNING
BATTERY HAZARD
The battery may leak, explode, cause burns, or cause an explosion if mishandled. Contents of an open battery can
cause severe irritation and/or chemical burns. If on skin, wash with soap and water. If in eyes, flush with water for at
least 15 minutes and seek immediate medical attention.
• Do not short-circuit the terminals of the battery.
• Keep the battery away from fire.
• Charge only with Graco approved charger as listed in this manual.
• Do not expose to heat above 170° F (80° C).
• Do not expose battery to water or rain.
• Do not disassemble, crush, or penetrate the battery.
• Follow local ordinances and/or regulations for disposal.
CHARGER ELECTRIC SHOCK, FIRE AND EXPLOSION HAZARD
Improper setup or usage can cause electric shock, fire, and explosion.
• Charge only Graco 18V Lithium Ion batteries; other batteries may burst.
• Use only in dry locations. Do not expose to water or rain.
• If the supply cord is damaged, it must obtained from the manufacturer to avoid a hazard.
• Ensure that the outside surface of the battery is clean and dry before plugging into the charger.
• Do not attempt to charge non-rechargeable batteries.
• Place charger on flat non-flammable surfaces and keep away from flammable materials or fumes when recharging
battery.
• To reduce the risk of damage to cigarette lighter connector and cord, pull by cigarette lighter connector rather than
cord when disconnecting charger.
•Make sure cord is located so that it will not be stepped on, tripped over, or otherwise subjected to damage or stress.
• Do not operate charger with damaged cord or cigarette lighter connector; replace it immediately.
• Do not operate charger if it has received a sharp blow, been dropped, or otherwise damaged in any way; take it to a
qualified service person.
•Do not disassemble charger; take it to a qualified service person when service or repair is required. Incorrect reas-
sembly may result in a risk of electric shock or fire.
• To reduce the risk of shock, unplug charger before attempting any maintenance or cleaning. Turning off controls will
not reduce this risk.
•If a vehicle fuse opens repeatedly, do not keep replacing it. The cause of the overload must be found. On no
account should fuses be patched up with tin foil or wire as this may cause serious damage elsewhere in the electri-
cal circuit or cause fire.
