GPS Tracker Mp2 Manuel utilisateur

Gpstracker.net.in

Freedom is lost now…!

Model no: mp2

Personal GPS Tracker

USERS MANUAL

Gpstracker.net.in

Freedom is lost now…!

1 Product Overview

This tracker shows you with your mobile phone or PC the location of your targets via

SMS or GPRS

TRACKER has the following features

Tracking via SMS or GPRS 



Current location report 



Tracking by time interval 



Two-way conversation 



SOS alert 



Geo-fencing control 



Low battery alert 



Over speed alert 



Four buttons for making phone call and/or sending message to reset numbers 



Removable and rechargeable internal battery 



Built-in speaker and microphone 



Alert when Track enter/exits GPS blind area 



Live Voice monitoring 



Vibrating alert 



Without drift 



Vehicle safeguard 

2 For Your Safety

Read these simple guidelines. Not following them may be dangerous or illegal. Read

the full user manual for more information.

Water Resistance –Track is not water resistant. Keep it dry. Use waterproof bag if

necessary.

Gpstracker.net.in

Freedom is lost now…!

3 Track Parameters& Panel Description

Item

Specification

Charging Voltage

DC 5V/500mA (Micro USB port)

Internal Battery

Rechargeable and removable 830 mAh battery (3.7V)

Operating temperature

-20° to 55° C

Humidity

5% to 95% Non-condensing

GSM module

GSM 900/1800/1900Mhz

GPS Chipset

sirmens (AGPS)

GPS Sensitivity

-158Db

GPS Frequency

L1, 1575.42 MHz

C/A Code

1.023 MHz chip rate

Channels

24 channel all-in-view tracking

Position Accuracy

5 meters, 2D RMS

Velocity Accuracy

0.1 m/s

Time Accuracy

1 us synchronized to GPS time

Default datum

WGS-84

Reacquisition

0.1 sec., average

Hot start

1 sec., average

Warm start

38 sec., average

Cold start

42 sec., average

Altitude Limit

18,000 meters (60,000 feet) max.

Velocity Limit

515 meters/second (1000 knots) max.

Acceleration Limit

Less than 4g

Jerk Limit

20 m/sec

Work time

60 hours in sleep mode and 10 hours in normal mode

LED

3 LED indicators showing power, GPS, GSM status and other

operation status.

G-Sensor

± 2g

Gpstracker.net.in

Freedom is lost now…!

Panel Description



4 Getting Started

4.1 Hardware and Accessories

USB Power Cable 



User Manual 



Other document or software if required 

4.2 Light and Button Functionality++++++ 

TRACKER has four buttons and three LED lights with three different colors to indicate

the status of the unit. All LED is enabled when power on, and short click SOS key to change

GSM & GPS LED enable / disable status. 

Gpstracker.net.in

Freedom is lost now…!

Red LED -- Indicating power status

Off

Power off / charging complete / working / GPS optional

Flashing (on for 0.05s and off for 4.95 s)

Low power

Flashing (on for 1s and off for 4 s)

GPS on

Charging

Green LED -- Indicating GPS status

Off

Device is not ready

Flashing (on for 0.05 s and off for 4.95 s)

GPS fix

Flashing (on for 1 s and off for 4 s)

GPS no fix / GPS power off

Blue LED –Indicating GSM status

Telephone dial/Have a call/Busy/ GPRS transmit

Flashing (on for 0.05 s and off for 4.95 s)

TRACKER is connected to GSM network

Flashing (on for 1 s and off for 4 s)

TRACKER is not connected to the GSM network

Note: When it is power on, but not finding SIM card or showing errors on SIM card, the three LEDs will

be on and off one by one as a circle repeatedly.

Power Button

To turn on/off

SOS Button

Long press SOS button to send an alarm to location

center and make a phone call and/or send an SMS to

the preset phone number.

Short press SOS button to change GSM & GPS LED

enable / disable status.

1 Button

Long press 1 button to make a phone call and/or send

an SMS to the preset phone number.

2 Button

Long press 2 button to make a phone call and/or send

an SMS to the preset phone number.

3 Button

Long press 3 button to make a phone call and/or send

an SMS to the preset phone number.

Gpstracker.net.in

Freedom is lost now…!

4.3 First Use

Ensure that Tracker has a working SIM installed

Check that the SIM has not run out of credit 



Check that the SIM Lock code is turned off 

Use some other mobile phone to confirm that the PIN code Can not been set ,and

that it can dial out and receive telephone calls, and that it can connect to internet by

GPRS. 

Charge the battery for at least 3 hours in power-off status using the wall charger or

car charger. Red light is on during charging and is off when charging is completed. 

4.4 Operation Instructions

(1) Power On/Off

Power On

Step:1

Gpstracker.net.in

Freedom is lost now…!

Step 2.

Step:3

Gpstracker.net.in

Freedom is lost now…!

Note: When it is power on, but not finding SIM card or showing errors on SIM card, the three LEDs

will be on and off one by one as a circle repeatedly.

Power Off:

When it is on, press the power button for 3 seconds to switch off the power;

Power/GPS/GSM LED will shut off right now. By then, the device is turned off.

(2) SOS Emergency Help Function

When SOS button is long pressed, Track will send alarm to location center, and send a

SMS message and make phone call for emergency help. The phone number can be set by

the users.

When 1 2 3 button is long pressed, Track will make normal phone call. The phone

number can be set by users. The phone number list can be set by SMS command.

(3) Conversation Function

Call In: One can make phone call to Track by simply dialing the SIM card number.

To receive the incoming phone call

To refuse the incoming phone call

Call Out: Track has four speed dial; you can long press preset 4 sets of phone

(4) gprs live tracking

Please follow the 4 steps in quick set up file

5 SMS Command

TRACKER will only accept commands from a user with the correct password.

Commands with wrong password are ignored. The default password is 000000.

Gpstracker.net.in

Freedom is lost now…!

5.1 Basic SMS Commands

5.1.1 Return the location of the tracker

Description: To know the location of your Track, send an SMS to Track and it will report

its location by SMS.

Command: W<password>, <000>

Notes: The default password is 000000.

Example:

SMS sent: W000000, 000

SMS received:

W00,000,$GPRMC,034522,662,A,2232,3126,N,11359,3061,E,000.0,000.0,241209,,,A*6

5.1.2 SOS/Call 1/Call 2/Call 3

Description: To authorize a mobile phone number for the SOS, 1, 2 or 3 buttons. When the button is

pressed, a message will be sent and/or simultaneously a call will be made to the authorized number.

Command: W<password>,003,F,P, <telephone number>

Notes:

(a) F =0, cancel this function

=1, set send SMS to the preset number

=2, set call the preset number

=3, set send SMS and also Call the preset number

P =1, set a authorized number for SOS button

=2, set a authorized number for 1 button

=3, set a authorized number for 2 button

=4, set a authorized number for 3 button

(b) When one of the buttons is pressed and a call is made, you can call and talk with the

tracker-holder.

Example:

Gpstracker.net.in

Freedom is lost now…!

SMS sent: W000000,003,3,1,123456789

SMS received: W01,003,Set phone number OK

Meaning: When the SOS button is pressed, Track will send an SMS to telephone number

“123456789” and also make a phone call to it.

When a call is coming in, the blue light is on. Press ACCEPT button to receive the

incoming call and then talk with the caller. To complete the conversation, hang up the call

by pressing END button.

5.2 GPRS Settings by SMS

Tracking via GPRS, you should set APN for Track.

Ensure that your SIM card in Track supports GPRS connection prior to setting.

5.2.1 Set APN

Command: W<Password>,011, <APN>,<APN Name >,<APN Password>,<APN

DNS>,<APN Second DNS>

Note: If no APN name, APN password, APN DNS and APN Second DNS required, input

APN only.

Example: W000000, 011, airtelgprs

TRACK will reply with an SMS (like „W01, 011, Set device APN OK‟) to confirm this

setting.

5.3 Car Safeguard Setting

5.3.1 Opening Function

You can start this function via SMS of your cell phone to set the authorized number for

SOS button. (You can have more reference from setting SOS phone number in 5.1.2 )
