07 08
Manual Recording:
1. In the real-time monitoring status, press the and buttons
to select the camera for video recording as the current camera.
2. Press the recording/stopping button on the device.
The recording icon is displayed on the screen, indicating that
recording starts.
3. Press the button on the device again to stop recording.
Timer Recording:
Set the recording start/stop time through the “Timer Recording”
menu. The device automatically records according to the set
start/stop time. After recording, it automatically saves the video.
Specific steps are as follows:
1. Press the MENU button to enter setting interface;
2. Press the or button to select “Record” and press the OK
button to enter;
3. Press the or button to select “Timer Recording” and press
the OK button to enter;
4. Press the or button to select “New Schedule” and press the
OK button to enter:
● Video recording
1. In the real-time status, press the button to enter playback
interface;
2. Press the or button to select the folder;
3. Press the OK button confirm and enter:
● Playback
/mnt/usb/rec/20121107 2/5
.. (up) <DIR>
065304-1.avi 5MB
065320-2.avi 7MB new
065354-2.avi 5MB new
065417-4.avi 10MB new
'Enter':Play 'Del':Delete
Timer Recording
OK:Options MENU:Quit
Press the or button to select;
Press the or button to adjust;
Press the OK button to confirm and exit;
Camera
End Time
Date
Start Time
All Cameras
11/6/2012 Tue
:
00 :00
0000
5. After setting, the device automatically records according to the
set start/stop time.
6. If you press the recording/stopping button on the device
during the recording process, recording stops.
Remarks:
1. If the video recording time is longer than 5 minutes, a video file
will be automatically saved every 5 minutes.
2. Multiple channels (four channels at most) of recording are
supported at the same time. The recorded video of each channel
is saved in an independent video file.
Not browsed
File size
Camera 1
Camera 2
Camera 4
PIR Recording:
If there is human motion detected by any accessed camera, recording
can be triggered. The specific steps are as follows:
1. Press the MENU button to enter the setting interface;
2. Press the or button to select “Record”, press the OK button
to enter;
3. Press the or button to select “PIR Recording”, press the OK
button to enter;
4. Press the or button to select the camera;
5. Press the or button to select “On”;
6. Press the OK button to confirm and exit.
* When “Off” is set, motion detection function is turned off.
* The infrared sensing distance of PIR is 5 m. If the distance exceeds
5m, sensing may fail.
