Gorenje NRK 2000 P2 Manuel utilisateur

Instructions for use

Upright refrigerator -

freezer

Downloaded from Fridge-Manual.com Manuals

133624

Thank you for your conﬁdence in buying our

appliance and congratulations on the excellent

choice. We hope it will successfully serve its

purpose for many years.

Upright refrigerator - freezer (hereinafter: the

appliance) is combined from two parts: top part is

refrigerator and bottom part is upright freezer.

Refrigerator is used in households for storage of

fresh food at temperatures above 0°C).

Freezer is used in households for freezing fresh

food and storage of frozen food for up to one year

(depending on the type of food).

Before ﬁrst operation ....................................... 3

Description of the appliance ............................ 6

Installation and connection.............................. 7

Control panel .................................................... 9

Recommended distribution of food .............. 17

Storing fresh food in the

refrigerator ..................................................... 18

Storing of food in the

ZERO’N’FRESH drawer .................................. 21

Freezing and storage of frozen food ............. 23

Defrosting the appliance................................. 26

Cleaning ........................................................... 27

Troubleshooting guide.................................... 28

Noise level........................................................ 30

Downloaded from Fridge-Manual.com Manuals

133624

•The appliance is manufactured in compliance

with all relevant safety standards; however, it

is recommended that persons with impaired

physical, motional, or mental abilities, or persons

with inadequate experience and knowledge, do

not use the appliance without due supervision.

The same recommendation applies to minors

using the appliance.

• Before connecting the appliance read these

instructions carefully. They describe the appliance

and provide instructions for its safe and correct

use. The instructions are prepared for different

types and models of the appliance so they may

contain descriptions of functions and components

your appliance may not have.

Instructions also contain the NO FROST freezer

version, with integrated fan and automatic defrost.

•Remove the wrapping protecting the appliance

during transport. Door corners are ﬁtted with

protective spacers. Remove the spacers and

replace them with the attached pegs.

•Before connecting the appliance to the mains

supply, leave it in upright position for about 2

hours. This will reduce possibility of malfunctions

in the cooling system resulting from prior transport

and handling.

•The appliance must be connected to the mains

supply in accordance with the standing regulations

and local requirements.

•The appliance must not be used in open air or

exposed to weather precipitation.

•Always disconnect the appliance from power

supply (pull the power cord from wall socket)

before cleaning and before replacing the light bulb.

•If the power supply cord is damaged, in order to

avoid hazard it must be replaced by the service or

by qualiﬁed personnel.

•In case of longer disuse ﬁrst turn the appliance

off with the ON/OFF button and disconnect it from

mains supply. Empty the appliance, clean the

interior and leave the door ajar.

Before ﬁrst operation

Downloaded from Fridge-Manual.com Manuals

133624

•For the protection of environment deliver the

obsolete appliance to the authorized scrap

appliance dealers.

•Wrappings contain environmentally friendly

materials which can be recycled, recovered or

disposed without threat to the environment.

•To prevent any pollution be careful not to damage

the insulation or refrigeration tubes at the rear wall

during the installation, cleaning and disposal of

the appliance.

•When using or cleaning the touch screen control

unit, do not press controls excessively hard to

avoid any damage.

•Never let the children play with the appliance.

•Self closing door hinge pulls the door to the

cabinet just before closing, thereby preventing

the door to remain ajar. Equally it limits the door

opening angle and prevents damage to adjacent

elements.

•Practical longitudinal aluminum handle offers

convenient grip anywhere along its length

(convenient for children).

• Odor ﬁlter removes foul and unpleasant smells

from inside the cabinet and prevents their

absorption by other food stored in the refrigerator.

First remove the protective foil from the ﬁlter, then

remove the aluminum gel protection at the back,

and ﬁnally slip the ﬁlter onto the support from

above, as shown on the sketch.

After approximately 3 months the gel inside the

ﬁlter is used up and needs to be replaced. It can

be purchased from the authorized Gorenje service

centers.

•Rating plate with basic information is located in

the interior of the appliance. If the sticker plate is

not suitable for your language, replace it with the

attached one.

Downloaded from Fridge-Manual.com Manuals

133624

• Warning: Ventilation slots on the appliance or built-in element should always

be kept clean and unobstructed.

• Warning: Do not use any mechanical accessories when thawing the refrigera-

tor, except for those explicitly recommended by the manufacturer.

• Warning: To prevent any pollution be careful not to damage the insulation or

refrigeration tubes at the rear wall during the installation, cleaning and dispo-

sal of the appliance.

• Warning: Do not use any electrical devices inside the appliance, except for

those explicitly recommended by the manufacturer.

The symbol on the product or on its packaging indicates that this

product may not be treated as household waste. Instead it shall be

handed over to the applicable collection point for the recycling of

electrical and electronic equipment. By ensuring this product is

disposed of correctly, you will help prevent potential negative

consequences for the environment and human health, which could

otherwise be caused by inappropriate waste handling of thisproduct.

For more detailed information about recycling of this product, please

contact your local city ofﬁce, your household waste disposal service

or the shop where you purchased the product.

Downloaded from Fridge-Manual.com Manuals

133624

• Interior accessories of the appliance may vary according to the model.

• Pull-out guide drawers (or shelves) are extracted by lifting the rear end and pulling out inclined

under the 45° angle. Reinsert in opposite sequence.

* Certain models only.

A Refrigerator

B Freezer

1 Interior light

2 Shelf (adjustable height)

3 Telescopic guide shelf

(max. 12 kg)

4 Foldable egg rack (closed - six

eggs, open - 12 eggs)

5 Vegetable crisp pan*

6 ZERO’N’FRESH food storage

drawer with pull-out guides (may.

20 kg)

7 Bottle rack*

8 Refrigerator door tray (max. 6 kg)

9 Closed side pan

10 Window

11 Twin row bottle carrier with safety

holder*

12 Tube holder*

13 Fast freeze drawer for small

quantities of food

14 Large BIG’N’FREEZE drawer on

telescopic guides (max. 16 kg)

15 Storage compartment (short)

16 Freezer door shelf*

17 Ice tray*

18 Defrost drain outlet groove*

19 Legs

20 Wheels*

Description of the appliance

Downloaded from Fridge-Manual.com Manuals

133624

•Place the appliance in dry and well aired room.

The appliance operates best at temperature

ranges indicated in the chart below. Relevant

class of the appliance is indicated on the rating

plate.

Class Ambient temperature

SN (subnormal) from +10°C to +32°C

N (normal) from +16°C to +32°C

ST (subtropical) from +16°C to +38°C

T (tropical) from +16°C to +43°C

Positioning the appliance requires two persons in

order to avoid injuries or damage to the appliance.

•Place the appliance ﬂatly and ﬁrmly on a solid

base. The appliance is ﬁtted with adjustable feet

on the front side, used to level the appliance.

Rear side of the appliance is ﬁtted with wheels

facilitating the positioning of the appliance at the

preselected place.

•The element above the appliance must be at

least 5 cm away to allow sufﬁcient cooling of the

condenser.

•Avoid exposing the appliance to direct sunlight

or heat sources. If this is not feasible, install

insulation plate between the appliance and

adjacent heat source.

•Bottom front side of the appliance is ﬁtted with

handles to facilitate relocation. The appliance may

stand independently or adjacent to a furniture

element or wall. Be sure to leave enough space

for the opening of the door, to avoid damage

to the appliance or injuries to persons. Also

leave ample space for extracting shelves (see

installation diagram).

Installation and connection

Selecting the location

Positioning the

appliance

Downloaded from Fridge-Manual.com Manuals

133624

•Use the power cord to connect the appliance to

the mains power. Wall outlet must be ﬁtted with

ground terminal (safety socket). Nominal voltage

and frequency are indicated on the relevant label

or rating plate of the appliance.

•Mains power connection and grounding must be

made in line with standing regulations and local

requirements.

The appliance is able to accommodate minor

temporary voltage tolerances, but they may not

exceed -6% to +6%

Connecting to power

supply

Downloaded from Fridge-Manual.com Manuals

133624

I. Basic controls

1. Setting refrigerator temperature

2. Setting freezer temperature

3. Help

4. Child lock

5. Current time

6. Alarm

7. ECO saving program

8. Vacation program

9. Super frost

10. Super cool

11. Quick bottle cool in the refrigerator

12. Quick bottle cool in the freezer

13. Ilumination ON/OFF

II. Other settings

III. Tips

Control display is located on the outside the door

and is controlled on touch screen principle.

9 10 11 12 13

III

7 8

Master menu

Control panel

Settings

Downloaded from Fridge-Manual.com Manuals

133624

ON/OFF button

First plug the mains power lead into the wall mains

outlet. Screen illuminates, displays gorenje logo for

a moment, and then changes to master menu.

The appliance is switched on/off by keeping the

symbol pressed for at least 3 seconds (separately

for the fridge and for the freezer).

Setting the temperature

To set the refrigerator or freezer temperature press

the relevant temperature setting button for each

appliance.

Temperature is changed by pressing the

arrows .

After 5 seconds the setting is automatically saved.

Help is available by pressing the symbol.

Help

Press the symbol to enter help.

Press the to move through the text.

Pressing the symbol returns you back to the

master menu in all settings.

Child lock

Integrated child lock protects the appliance against

accidental alterations of temperature or even turning

the appliance off.

Switch the child lock ON/OFF by pressing the

symbo for more than 2 seconds. Framed symbol

indicates the function is active.

Illumination ON/OFF

To turn on the interior light for the illumination of

the appliance press the symbol. Stored food

can be viewed through the inspection window

on the appliance door. If you do not turn the light

off manually it will go off automatically after 30

seconds.

I. Basic controls

Downloaded from Fridge-Manual.com Manuals

Table des matières

Autres manuels Gorenje Réfrigérateur

Gorenje

Gorenje NRK6182PS4 Manuel utilisateur

Gorenje

Gorenje RU 5004 Manuel utilisateur

Gorenje

Gorenje NRF8181MX Manuel technique

Gorenje

Gorenje HZOKS 3766 Manuel utilisateur

Gorenje

Gorenje NRS918BCBG Manuel utilisateur

Gorenje

Gorenje NRS918EMB Manuel technique

Gorenje

Gorenje NRK619EAXL4WD Manuel utilisateur

Gorenje

Gorenje RK4172ANX Manuel technique

Gorenje

Gorenje RF60309OC Manuel utilisateur

Gorenje

Gorenje RB4091W Manuel utilisateur

Gorenje

Gorenje nrf7181aw Manuel utilisateur

Gorenje

Gorenje NRS8182KX Manuel technique

Gorenje

Gorenje NRK4182CW4 Manuel utilisateur

Gorenje

Gorenje UKC375XNF Manuel utilisateur

Gorenje

Gorenje R 3145 W Manuel utilisateur

Gorenje

Gorenje NRS85728BK Manuel utilisateur

Gorenje

Gorenje RK6161AW Manuel utilisateur

Gorenje

Gorenje BCD 522 Manuel technique

Gorenje

Gorenje NRS9182MX Manuel utilisateur

Gorenje

Gorenje RF 54234 W Manuel utilisateur

Gorenje

Gorenje ONRK192R Manuel technique

Gorenje

Gorenje Classico NRK611CLI Manuel utilisateur

Gorenje

Gorenje RK4151ANX Manuel technique

Gorenje

Gorenje RK4181PW4 Manuel utilisateur

Manuels Réfrigérateur populaires d'autres marques

Bonnet Neve

Bonnet Neve SKYVIEW PLUS Manuel utilisateur

Zanussi Electrolux

Zanussi Electrolux ZERB 8441 Manuel utilisateur

Sharp

Sharp SJ-BA31IEXW2-EU Manuel utilisateur

CORBERO

CORBERO CC2300MCW Manuel utilisateur

KitchenAid

KitchenAid 2205264 Manuel utilisateur

Stengel

Stengel KU 1101 A++ Manuel utilisateur

NEFF

NEFF KI181 Series Manuel utilisateur

Hoshizaki

Hoshizaki Reach-In Manuel utilisateur

Amana

Amana ASD2524VES00 Manuel utilisateur

BOMANN

BOMANN KGC 213 Manuel utilisateur

Danby

Danby DAR044A1SLDD Instructions de montage

Samsung

Samsung RF323TE Manuel utilisateur

Beko

Beko CSA31022 Manuel utilisateur

IKEA

IKEA FROSTIG C 185 E Manuel utilisateur

Electrolux

Electrolux ER 6821 D Manuel utilisateur

True

True TS-28 Manuel utilisateur

Frigidaire

Frigidaire FSC23R5DW9 Manuel utilisateur

Beko

Beko LSP4579W Manuel utilisateur
