Gooloo GT4000S Manuel utilisateur
TM
SUPERSAFE is a safety protection technology by GOOLOO
TM
R
ENRICH YOUR DRIVING LIFE
User Manual
Jump Starter
Model: GT4000S
series
URBO
4000A
JUMP STARTER
Reg No. 5904374
English 1-20
Deutsch 21-42
Français 43-63
Español 64-84
Italiano 85-105
contents
1
Thank you for choosing gooloo jump starter. To ensure a good user experience, personal
safety, and property security, please read all of the instructions carefully before using this
product, please keep this manual for reference.
Charge It First !
Warning
While reading through the manual, you can start to charge your GT4000S with car charger
provided or wall charger.Please note that the wall adaptor is not supplied for protecting
environment purpose, but you can charge it with the wall adaptor come with your smart
phone.
This unit is for vehicle (equipment) with 12V batteries. It may be dangerous if it is used with
other types of batteries. Read and understand the safety information before using the jump
starter. Failure to follow the safety information may cause damage to the jump starter, and
may also result in electric shock, explosions, fire, property damage, and personal injury.
Product Parts and Functions Description
2
2
3
4
5
6
1
8
1. Display Screen
2. USB-C In/Out Port (PD100W Max)
3. USB1 Out Port (QC3.0, 5V/9V/12V)
4. USB2 Out Port (5V/2.4A)
5. DC Out Port (15V/10A, Max 150W)
6. Power Button: Press 1-2s to power
on the jump starter, press about 10s
to force shutdown.
Product Parts and Functions Description
3
6
8
7
9
7. BOOST Button: Press 1-2s to force
output, and READY will be displayed
on the screen.
8. 12V Battery Clamps Output: DO
NOT press the BOOST button before
connecting the clamps to the vehicle
battery correctly.
9. LED Light: Turn on the unit first by
pressing the power button for 1-2s ,
then press the power button 1-2s
again to turn on the LED light.
4
Display Screen Instructions
123
4
5
6
7
8
1. Battery Power Percentage: Battery percentage of
charge/standby/discharge
2. Low Current Mode: Support charging for the devices
that need light charging current like headphone, smart watch,etc.
Press POWER and BOOST button simultaneously for 2-3s to turn
on this mode.
3. “+” and “-” Poles of Battery Clips Reversed
4. Battery Low Temperature Reminder
5. Battery Pre-heating: GT4000 Unique Function
6. Ready to Start the Vehicle
7. Pre-heating Temperature Display: GT4000 Unique
Function
8. Charging Power
This unit can be charged with car charger provided or quick speed wall charger (Quick
Speed Wall Charger not Included). Only via the PD100W USB-C wall charger or SC100W
car charger can this unit achieve the 100W max input function. PD100W USB-C quick speed
wall charger need to purchase separately.
Support PD100W Max Speed Charging
5
USB-C IN USB-A/USB-C OUT DC OUT
12V BATTERY
CLAMP OUT
(SC100W Car Charger)
6
How to Start a 12V Vehicle (Make sure battery power＞20%)
1. Connect Vehicle Battery 2. READY (Solid) 3. Start Vehicle Engine
START
ENGINE
Note: Do not press the BOOST button before connecting the vehicle battery correctly.
+
-
100
%
READY START
ENGINE
7
Error Message/ Cause/ Solution
Error Message Cause Error Solution
READY (blinks)+Beeping
“1”
“2”
“3”
The temp of jump starter is too low
or high.
Restore the temp of jump starter to
32°F -113°F.
Overcurrent protection Stop starting your vehicle,protection
mode will disappear after 30s.
Non-stop starts vehicles more than
4 times within 10mins, it entered
safe mode.
Stop starting your vehicle,safe mode
will disappear after 10mins.
Reverse connection
Vehicle battery dead Press “BOOST”for 2-3s, when “READY”
icon is solid, start the vehicle within 30s.
Please correct the connection between
jump clamps and battery terminals
+ Beeping
+ Beeping
+ Beeping
+ Beeping
If the problem persists, stop using the jump starter and contact our service team directly
How to Turn On/Off the LED Flashlight
Power on, then press power button for 1-2s to turn on the LED light. There are 3 modes of
LED light (Normal, Strobe, SOS, Off) if you press lightly.
8
15V/10A DC Output (12-16.8V,150W Max)
IP65 Water Resistant
It doesn’t matter when this unit touched with small splashes, you just need to wipe it off. It
can prevent splash water in your daily life, but it is not allowed to be immersed in water.
Connect the 12V devices that need to be powered by cigarette lighter socket (the Cigarette
Lighter Socket Adapter is included).
Pre-heating Technology (Unique features of GT4000)
GT4000 can be used in an environment of -40°C and reach the starting temperature within
100 seconds after connecting the vehicle battery. The jump starter will automatically turn on
the pre-heating function after connecting the vehicle battery or pressing BOOST button 1-2s
in extremely cold environment.
