GPS167

Portable CD Radio

User Guide

IMPORTANT: Please read all instructions carefully before use and keep for future reference

Introduction

Thank you for choosing this Goodmans Portable CD Radio .

You can listen to your favourite radio stations and CDs

Safety is important

Use of any electrical equipment should be undertaken with care. Please read the safety

section on page 11 and 12 before using your Portable System. This appliance is for

household use only.

What’s in the box?

Contents

Your Portable System ...............4

Get going ..................................6

Daily use ...................................8

Troubleshooting.......................12

Specifications...........................13

Warnings...................................14

Guarantee ................................16

Portable system

This User Guide

GPS167

Portable CD Radio

User Guide

IMPORTANT: Please read all instructions carefully before use and keep for future use

power supply

01 Your Portable System

Mains Power Socket

FM Antenna

LCD Display

CD Door

BATTERY Door

PLAY/PAUSE Button

REPEAT Button

TUNNING Knob

VOLUME Knob

FUNCTION Switch

STOP Button Skip >> Forwards Button

Skip << Backwards Button

Front

Side

Rear

AC POWER CONNECTION

Using the Portable System with Batteries

The Portable System can be powered by 6 “C” types Batteries. This allows the

Portable System to be used outside or away from wall sockets.

To remove the Battery Compartment Cover, press firmly and pull away from the

unit.

Insert 6 “C” type batteries into the battery compartment, following the polarity

diagram on the inside.

Replace the Battery Compartment Cover.

02Get going

Connect one end of the AC cord to the AC INPUT socket on the left side of the unit,

then connect other end to the wall outlet. The unit is now ready to operate.

Disconnect the AC cord from the wall outlet when the unit is not in use.

03 Daily Use

Listening to Radio

DON’T FORGET!

To get the best MW reception, slightly rotate

the unit or move the unit to a different area of

the room until the best reception is obtained.

To obtain the best FM reception, fully extend

the FM antenna. Avoid close proximity to other

electrical appliances.

Switching On

Adjusting the Volume

ANTENNAS

Slide the FUNCTION switch to AM, FM or

CD position to turn the unit ON.

Slide the FUNCTION switch to the OFF

position to turn the unit OFF.

Rotate the volume knob to increase or

decrease the volume level.

MW - This unit has a built-in ferrite rod

antenna, which eliminates the need for

an external antenna, and provides

adequate reception in most areas. If

the signal is weak, turn the unit to

improve reception.

FM - The telescopic antenna on the top

of the unit is for FM reception only. If

the signal is weak, adjust the angle of

the antenna.

Slide the FUNCTION selector to the FM

position.

Tune to a desired station by rotating the

TUNING KNOB(Fig A).

To switch the radio off, slide the

FUNCTION switch to the OFF position.

Fig A

03Daily Use

DON’T FORGET!

Do not open the CD compartment while the

disc is playing or rotating.

First press the STOP button and wait for the

CD to stop.

Listening to a CD

Open the CD compartment by lifting the

door upwards.

Insert a disc into the disc compartment

with the printed side facing upwards.

Close the CD compartment door.

“---” is displayed for a few seconds, then

the total number of tracks will show in the

LCD display.

Press the PLAY/PAUSE button to begin

playback.

Press the SKIP / Forwards or SKIP /

Backwards buttons to skip to the next/

previous track.

Press and hold the SKIP /Forwards or SKIP /

Backwards buttons to search for a desired part

of the current track.

When the CD is playing, press the

PLAY/PAUSE button to pause the CD.

To continue playback, press the PLAY/

PAUSE button again.

To stop playback of a CD press the

STOP button.

After all tracks have been played, the CD

will stop automatically.

Handling CDs

To remove a disc from its storage case,

press down on the centre of the case and

lift the disc out, holding it carefully by the

edges.

Fingerprints and dust should be carefully

wiped off the disc’s recorded surface with

a soft cloth before use.

DON’T FORGET!

Never use chemicals such as record sprays,

antistatic sprays, benzene, or thinners to clean

compact discs.

These chemicals can damage the disc’s

surface.

Slide the FUNCTION switch to the CD position.

Using the repeat function

Daily Use

During CD disc playback, select a

desired track as previously described.

Press the REPEAT button once.

“REPEAT 1” is shown in the display.

The portable system will repeat the

selected track.

Press the REPEAT button twice.

“REPEAT ALL” is shown in the display.

The portable system will repeat all

tracks on the CD.

Programming tracks

Insert a CD into the portable system.

Make sure the CD function is in stop

mode.

Press the PROG button, "PROG 01" and

will flash in the display.

Press the SKIP /Forwards or SKIP /

Backwards buttons until the display

shows the track number that you want

to program.

Press the PROG button to store the

track.

Repeat steps 4 and 5 until you have

entered all the tracks that you want to

program.

To playback the programed track, press

the PLAY/PAUSE button.

After all programmed tracks have been

played, the CD player will stop

automatically.

DON’T FORGET!

A total of 20 tracks can be programmed into

the CD memory.

04 Troubleshooting

Need extra help?

Don’t worry we are just at the other end of the

phone. If you are experiencing problems using

your new product, before returning it to the

retailer, just call 0871 230 1777.

Need a spare part?

In the unlikely event of you needing spare

parts, please contact our spares department

on: 0871 230 0790

Problem

1. Fine tune the station.

2. Reposition the Portable System.

1. Select Tuner mode

2. Adjust the volume level.

Radio sound distorted.

No radio sound.

1. The station is not tuned in.

1. Select CD mode.

2. Load a CD and check it is the

correct way round.

CD Player will not play

2. CD is not installed or

installed in correctly.

1. Wipe the disc with a cloth or use

another disc.

CD skips while playing

2. There is interferrence.

1. The Portable System is not in

tuner mode.

2. The volume has been muted or

is on the minimum setting.

1. Unit not in CD mode.

1. Disc is dirty or scratched.

What to do

Possible Cause

05Specifications

Model Number • GPS167

Power Supply • 230V AC 50Hz OR 6 X 1.5 Volt “C” size batteries

Power Consumption • 12 watts

Power Output • 0.8 x 2 Watts RMS

Radio Frequency Coverage • FM: 87.5 - 108 MHz MW: 540 - 1600KHz

Battery Requirement • 6 X "C" type (not included)

Dimensions • 264mm (L) x 174mm (W) x 90mm (H)

IMPORTANT: Due to continual revision and improvements to our products design,

specifications are subject to change without notice.
