GoMax Electronics MX-1010 Manuel utilisateur

MX-1010

Dual-View Video Enhancing Processor

User Manual

Made in Taiwan

Safety and Notice

The MX-1010 Dual-View Video Enhancing Processor has been tested for conformity to safety regulations

and requirements, and has been certified for international use. However, like all electronic equipments, the

MX-1010 should be used with care. Please read and follow the safety instructions to protect yourself from

possible injury and to minimize the risk of damage to the unit.

Follow all instructions and warnings marked on this unit.

Do not attempt to service this unit yourself, except where explained in this manual.

Provide proper ventilation and air circulation and do not use near water.

Keep objects that might damage the device and assure that the placement of this unit is on a stable surface.

Use only the power adapter and power cords and connection cables designed for this unit.

Do not use liquid or aerosol cleaners to clean this unit. Always unplug the power to the device before

cleaning.

Chapter 1

Introduction

General

Features

Specifications

Package Contents

Inputs and Outputs

Chapter 2

Hardware Installation

Safety Precautions

Installation Procedure

Chapter 3

IR Remote Control

On Screen Display Menu

Chapter 4

Software Operation

System Requirement and Precautions

Instruction of Software Connection

Chapter 5

Troubleshooting

Warranty

Appendix

Supported Resolution

Table of Contents

~ 1 ~

Overview

The MX-1010 Dual-View Video Enhancing Processor is an advanced video processor to enhance the video

quality for multimedia presentations. It is an ideal solution for applications where two video signals must be

displayed on a single display. It supports up to nine video inputs, of which two, one digital and one analog, can be

outputted simultaneously in Picture-In-Picture (PIP) or Picture-Aside-Picture (PAP) modes. The MX-1010

combines state-of-the-art technologies, such as video de-interlacer, scaler, color management, format conversion,

and video switch into one box and allows you to manipulate output images, wherever position and whatever sizes

you want for viewing two computers or two video signals or a combination through the control software*.

The embedded scaler converts signals from input sources to match the native resolution of monitors, flat

panel displays, projectors as well as user-selectable output settings up to WUXGA (1920 x 1200). Dual outputs

are provided in both analog (VGA) and digital (DVI) format, one is connected to remote display and the other is

connected to on-site display for real time monitoring.

Software will be available soon.

Figure 1: Configuration Diagram

Introduction

~ 2 ~

Features

Two graphics (DVI / VGA) and six video (two S-Video / two component / two composite) Inputs, from

640x480 to 1920x1200, interlaced or progressive.

Dual outputs (DVI / VGA), 640x480 to 1920x1200 with default resolution 1280x1024.

Support audio inputs from either stereo RCA or PC ear phone.

Dual stereo audio outputs

PIP, PAP, Full screen modes and adjustable size & position through software.

Dynamic scaling to provide better visual experience

Titles, borders and colored backgrounds.

Resize, position, flip, zoom& pan and blend output video.

Can be cascaded to obtain more images.

Image parameters and layouts are automatically saved in flash memory and can be recalled for later use.

Video parameters adjustable (brightness, contrast, color temperature, etc.).

User-selectable output settings, up to 1920x1200.

Also perfectly as a video screen splitter, a video converter and a video switcher.

Firmware upgradable for support of new features and technology enhancements.

IR control and software control through RS-232.

Automatically power-saving mode.

~ 3 ~

Specifications

Model Name

MX-1010

MX-1010P

Technical

Role of usage

Multiplexer / video processor

Dual output support

Yes

HDCP compliance

Yes

Video bandwidth

DVI [Single-link 4.95Gbps] VGA [165MHz]

Component [30MHz] Composite [13.5MHz]

TV tuner support

NTSC or PAL & SECAM [upon request]

Video support

480i / 480p / 720p / 1080i / 1080p60 / 1920x1200@75 / 1600x1200@60

Audio support

Yes

Control

PIP / PAP

Yes

Cascadable

Yes

Input TMDS signal

1.2 Volts [peak-to-peak]

ESD protection

Human body model —±15kV [air-gap discharge] & ±8kV [contact discharge]

PCB stack-up

6-layer board [impedance control —differential 100; single 50]

Input

1x VGA + 1x DVI + 2x component +

2x composite + 2x S-video + 1x RS-232

1x VGA + 1x DVI + 2x component +

2x composite + 2x S-video +

1x RF + 1x RS-232

Output

1x DVI + 1x VGA

IR remote control

Electro-optical characteristics: = 25/ Carrier frequency: 38kHz

DVI connector

DVI-I [29-pin female, digital only]

VGA connector

HD-15 [15-pin D-sub female]

RS-232 connector

DE-9 [9-pin D-sub female]

RCA connector

75female

RF connector [MX-1010P]

F connector [75female for RG-6/U cable]

Mechanical

Housing

Metal case

Dimensions

[L x W x H]

Model

440 x 145 x 44mm [1―5‖x 5.7‖x 1.7‖]

Package

230 x 545 x 110mm [9―1‖x 1―10‖x 4.3‖]

Carton

580 x 570 x 260mm [1―11‖x 1―11‖x 10.2‖]

Weight

Model

1.8kg [4.0 lbs]

Package

3.2kg [7.0 lbs]

Fixedness

1U rack-mount with ears

Power supply

5V 4A DC

Power consumption

12 Watts [max]

Operation temperature

0~40C [32~104F]

Storage temperature

-20~60C [-4~140F]

Relative humidity

20~90% RH [no condensation]

Package Contents

1x MX-1010 or MX-1010P

1x DVI to DVI&VGA breakout cable

1x DVI to HDMI cable

1x DVI to VGA adapter

1x RS-232 to USB adapter

1x IR remote controller

1x 5V 4A power adapter

2x 1U rack mounting-ear

1x User Manual

~ 4 ~

Package Content

1. MX-1010

2. DVI to DVI & VGA breakout cable

(DDVY01)

3. DVI to HDMI cable

4. DVI to VGA adapter (DVA01)

5. RS-232 to USB Adapter

6. IR remote controller

7. 5V 4A DC power adapter

8. 1U rack mounting-ear

9. User Manual

Please visit www.gomax-electronics.com/download.htm to download software

& firmware updates

~ 5 ~

Inputs and Outputs

The MX-1010 has nine inputs and accepts two graphics and seven video signals. There is a concept of main

channel and sub channel for this device. You can pick up two of the nine inputs, one is for main channel and the

other is for sub channel. To display two of them simultaneously on the same screen, the two chosen videos must

be from digital and analog inputs, or the same source. Except DVI, any other video sources are analog. Figure 2

shows the connectors on the rear panel of MX-1010 while Table 1 and 2 list separately the available video and

audio inputs of the MX-1010.

Figure 2: Rear Panel

These IO ports support various resolution from 640x480 up to 1920x1200, for more detail of the

supported modes, please refer to the Appendix for supported resolutions.

Table 1: Input/Output Connectors

Input Connector

Video Input

DVI-IN

DVI

VGA-IN

VGA

S-Video-IN

2x S-video

CVBS-IN

2x composite (yellow)

YPbPr-IN

2x component

Audio Input

Audio-IN

Audio for DVI-IN or VGA-IN

CVBS-IN

Composite & S-video (red & white)

YPbPr-IN-Audio

Component audio

Device Control

RS-232

RS-232 control port

Output Connector

Audio/Video Output

DVI-I-OUT

VGA & DVI dual video output

Audio-OUT (RCA)

Stereo analog output

Audio-OUT (Earphone)

Stereo analog output

~ 6 ~

Safety Precautions

I. To prevent fire or shock hazards, do not expose this device to rain or moisture.

II. When connecting other products such as DVD players, and personal computers, you should turn off the

power of this product for protection against electric shocks.

III. The product should be placed more than one foot away from heat sources such as radiators, heat registers,

stoves, and other products (including amplifiers) that produce heat. In addition, do not cover any material or

devices on the top of the device.

IV. Do not use immediately after moving from a low temperature to high temperature, as this causes

condensation.

V. Do not place this product on an unstable cart, stand, or table. The product may fall, causing serious injury to

a child or adult and serious damage to the product.

VI. Unplug this product from the wall outlet before cleaning. Do not use liquid cleaners or aerosol cleaners. Use a

damp cloth for cleaning.

VII. Do not allow the same still picture to be projected for a long time or an abnormally bright video picture to be

projected. The video image could be burned in to the display device.

Installation Procedures

Unpacking

Remove the MX-1010 from the shipping container and examine it for any signs of shipping damage or

missing items (check with package contents above). All shipping items should be saved if the product is to be

moved or returned for service. Shipping unit back to dealers for service not in the original box may result in

voiding warranty or additional cost.

Placement

The unit uses convection to cool. A fan is not needed, so do not block the sides of this device or stack

another device on the top or bottom of the MX-1010.

Hardware Installation

~ 7 ~

Connections

We recommend the highest quality cables for both input and output connections.

1. Switch off the MX-1010 and all devices that you want to connect.

2. Connect a monitor, a projector or other displays that comes with DVI or VGA inputs by using a male-to-male

DVI (VGA) cable to MX-1010 DVI output (you can connect 2 displays equipped with DVI and VGA respectively

by a DVI to DVI&VGA breakout cable (DDVY01)).

3. Plug in video sources to the desired input connectors.

4. Connect a device equipped with DVI output (such as a PC) to the DVI connector of the breakout cable.

5. Connect a device equipped with VGA output (such as a laptop) to the VGA connector of MX-1010

6. Connect your computer with the MX-1010 by a 9-pin RS-232 adapter and then install the software.

7. Plug in power adapter cable into 5V DC power jack.

8. Switch on all devices connected and then switch on the video processor and then press “menu‖ to display

OSD menu.

9. Press down source key or video hot keys to switch among all the video/graphic sources.

10. Once the Main Channel has a video selected, the corresponding audio is automatically set.

11. In PIP or PAP mode, use hot keys designed for PIP or PAP on the top of IR remote controller.

12. For detailed IR remote control operation, please refer to the On Screen Display menu and IR operating

instruction.
